TECHNICAL DATA
Veritas 1100BH
smart mixer amplier
BoseProfessional.com 1 OF 5
For additional specications and application information, visit BoseProfessional.com. Specifications are subject to change. 09/2025
Product Overview
The award-winning Veritas series from Bose Professional delivers superior background/foreground music, paging and
multimedia for commercial applications.
Bluetooth
®
5.0 wireless input and user-intuitive OLED screen with quick-start
QR code simplify setup—whether you’re a pro installer or a DIYer. With four models to choose from, Veritas ampliers
offer the perfect combination of power, performance and exibility.
Compact and powerful, the 1100BH is suited for smaller distributed audio systems, background music, and paging
applications. Designed for 70V/100V high-impedance systems, it efciently powers multiple wall or ceiling loudspeakers
to deliver broad coverage. Perfect for smaller venues, ofces, and retail spaces, the 1100BH features a smaller half-rack
size and front XLR/¼-inch input for convenient mic or audio source connection.
Applications
Retail stores
Restaurants and bars
Hospitality venues
Conference centers
Schools
Auxiliary zones
Key Features
Premium amplication with advanced DSP for optimized performance
Bluetooth
connectivity and RCA connectivity—no wire splicing required
Intuitive front-panel OLED screen for easy setup and control
Included bracket accessory for mount-anywhere exibility
Embedded quick-start QR code in the OLED screen simplies installation
Supports high-impedance (70/100V) applications
Remote level control with Bose Professional or third-party wall controllers
Dynamic EQ adjusts bass levels to achieve a fuller sound even at low volumes
Up to 30 selectable EQ presets ensure Bose Professional signature sound
performance and long-term reliability
Opti-Voice paging feature ensures clear speech intelligibility
Convection cooling for fanless operation in quiet installs such as ofces and
conference rooms
TECHNICAL DATA
Veritas 1100BH
smart mixer amplier
BoseProfessional.com 2 OF 5
For additional specications and application information, visit BoseProfessional.com. Specifications are subject to change. 09/2025
Technical Specications
POWER RATING
1 × 100 W at 70V/100V
AUDIO PERFORMANCE
Frequency Response 70 Hz – 18 kHz (+0/-4 dB, @ 1 W reference 1 kHz)
THD+N 0.3 % (at full rated power)
Dynamic Range 88 dB
INTEGRATED DSP
A/D & D/A Converters 24-bit, 48 kHz
Processing Functions Volume, tone controls, Opti-Voice paging, loudspeaker EQ, Dynamic EQ
Loudspeaker Presets
Audio Latency
AUDIO INPUTS Line Inputs Page Inputs
Input Channels
Connectors
Input Range -10 dBV to +10 dBV -60 dBV to +10 dBV
Adjustment Range -20 dB to +20 dB 0 dB to +50 dB
Input Impedance
+10 dBV +10 dBV
Sensitivity -10 dBV -58 dBV
Nominal Input Level 0 dBV -40 dBV
AUDIO OUTPUTS Loudspeaker Outputs Auxiliary Outputs
Output Channels
Connectors
Output Impedance n/a
Nominal Output Level 1 × 100 W at 70V/100 V
INDICATORS & CONTROLS
Power LED Solid blue (powered on)
Input Clip LED Green (-34 dBu to +10 dBu), red (> +10 dBu). Input gain level set to 5.
Bluetooth
LED
Off (no
Bluetooth
device connected), blinking blue (ready to pair to a
Bluetooth
device),
solid blue (connected to a
Bluetooth
device)
Display OLED, 16-bit grayscale, 96 × 96 resolution
Controls, Front Panel
Power on/off switch, input select switch (A/
Bluetooth
rotary encoder
Controls, Rear Panel Input gain knobs (A, B, page), mute connector, ControlCenter port
