DCSB Floor Scale Systems
Calibrated with SBI 240 LCD Indicator
This robust DCSB Floor Scale, calibrated with SBI 240 Indicator, is the ideal weighing solution for a wide
variety of industries where palletized goods are constantly being weighed or moved around by pallet
jacks or forklifts.
The platform deck, available in a wide range of capacities and dimensions, has 1/4" / 6 mm thick
hard-wearing checker plate with powder coat surface nish and waterproof IP67 load cells.
Simple to operate, the SBI 240 indicator with LCD display oers all the functions and features needed
to improve eciency and increase productivity in most warehouse and manufacturing environments.
Accuracy
NTEP at 5000d, Class III,
Legal-for-Trade
Power
9V 600mA power supply with
USA/UK/EU adapters (included)
and four AA batteries (not included)
Display
6½ digits 1” / 25 mm high, large seven
segment LCD with white backlight
Construction
Carbon steel fabrication with ¼" / 6 mm
thick safety tread top plate & heavy duty
welded channel under structure,150%
overload protection
Indicator
Comes fully calibrated with
the robust aluminum SBI 240 LCD
multi-function indicator
Operator Keys
Setup, Print/Func, Acc/Total, Unit/Data,
Tare/Preset, Zero/On/O
Warranty
Includes three year parts on DCSB deck
as standard
Capacity
2500 lb x 0.5 lb / 1250 kg x 0.2 kg
5000 lb x 1 lb / 2500 kg x 0.5 kg
10,000 lb x 2 lb / 5000 kg x 1 kg
DCSB SpecicationsDCSB Specications
DCSB Floor Scale Systems Calibrated with SBI 240 LCD Indicator
Deck Construction: Fabricated from high quality
mild steel with a 1/4" / 6 mm hard wearing
checker plate top deck structure and specially
designed folded channel understructure to help
maximize strength where needed
Finish: Powder coated surface finish
Load Cell: Four waterproof-IP67, NTEP approved,
350 Ohm ± 3.5 load cells
Load Cell Rated Output: 3 mV/V
J-Box: Weatherproof IP65, ABS housing with oor
scale top access for ease of installation/service
Interface Cable Length: 14.76 ft / 4.5 m
Leveling Feet: Four adjustable leveling feet with top
hole access for quick installation
Threaded Eye Bolts: Four threaded top access
eye-bolt holes for easy mobility and pit service
Corner Protection: Closed corner protection to
prevent damage to leveling feet
Overload Protection: 150% of rated capacity
Floor Scale Height Adjustment:
min 3.1" / 79 mm; max 4.1" / 104 mm
Capacity and Resolution:
Model Capacity Dimension
(in)
Dimension (mm)
DCSB3636-2.5 2500 lb x 0.5 lb
1250 kg x 0.2 kg
36 x 36 x 3.1 915 x 915 x 79
DCSB4848-05 5000 lb x 1 lb
2500 kg x 0.5 kg
48 x 48 x 3.1 1220 x 1220 x 79
DCSB5959-05 5000 lb x 1 lb
2500 kg x 0.5 kg
59 x 59 x 3.1 1500 x 1500 x 79
DCSB4848-10 10,000 lb x 2 lb
5000 kg x 1 kg
48 x 48 x 3.1 1220 x 1220 x 79
DCSB5959-10 10,000 lb x 2 lb
5000 kg x 1 kg
59 x 59 x 3.1 1500 x 1500 x 79
Shipping Weight (Indicator in the J-Box cavity):
DCSB3636: 143 lb/ 66 kg
DCSB4848: 253 lb / 116 kg
DCSB5959: 403 lb / 184 kg
Options: End ramps and brackets, pit frame, oor
mount plates, SBI240 oor stand, COM cables
Warranty: Includes three year parts on DCSB deck
from time of purchase. Consult factory.
SBI 240 SpecicationsSBI 240 Specications
Indicator Construction: Die cast aluminum indicator
housing with adjustable steel desk/wall bracket
Display: 6½ digits 1" / 25 mm high, large seven
segment LCD with white backlight
Operator Keys: Setup, Print/Func, Acc/Total, Unit/
Data, Tare/Preset, Zero/On/O
Functions: Weighing, check weighing and
accumulation
Unit: lb, oz, lb/oz, kg, g, pcs, %
Communication: One USB (VCP) and one RS-232
bi-directional full duplex port
Print Format: Congurable
Load Cell Capability: Up to four 350 ohm
load cells
Excitation: 5 VDC up to 55mA
Filtering Setting: Adjustable
Display Resolution: 100-100,000d primary units /
100-125,000d second units
Floor Scale Connection: 9.8" / 250 mm cable is xed
to indicator side with quick release connector. An
additional 14.76 ft / 4.5 m interface cable is
connected to the oor scale junction box.
Annunciators: -0-, motion, gross, net, tare, total,
lo-ok-hi, lb, kg, print
Calibration: Front panel accessible, multi-point
Power: 9V 600mA, 110-230V switch mode external
power supply and comes standard with USA/UK/EU
interchangeable plug adapters or four AA batteries
Battery Life: 32 hrs with backlight, 45 hrs without
Operating Temperature:
14° F to 104° F / -10° C to 40° C
Dimensions (L x W x H):
9.5" x 4.9" x 2.5" / 241 mm x 125 mm x 64 mm
Certications: NTEP CC #15-084, Class III,
Measurement Canada AM-6006 (indicator) and CC
#02-070 (base), FCC, Prop 65, ETL power adapter,
UKCA, CE, RoHS 3, WEEE
DCSBSystemSBI240_L_500114.indd
V8 AWT35-500114
Brecknell is part of Avery Weigh-Tronix. Avery Weigh-Tronix is a trademark of Illinois Tool Works group of companies whose ultimate
parent company is Illinois Tool Works Inc (
“Illinois Tool Works”
). Copyright © 2023 Illinois Tool Works. All rights reserved. This
publication is issued to provide outline information only and may not be regarded as a representation relating to the products or
services concerned. This publication was correct at the time of going to print, however Avery Weigh-Tronix reserves the right to alter
without notice the specication, design, price or conditions of supply of any product or service at any time.
brecknellscales.com
brecknellscales.co.uk
Part of Avery Weigh-Tronix
®
