WS300
Light Capacity Platform Scales
The WS300 light capacity platform scales provide a low cost solution for general purpose weighing of any
item up to 300 kg capacity.
With 1 part in 6000 resolution these platform scales give a weighing performance of 300 kg x 50 g.
This well designed low prole scale incorporates four full load bridge load cells with self leveling, anti-slip
feet to give a solid base in use.
The generous size weigh platforms are available in either WS300-55 (550 mm x 550 mm) or WS300-90
(900 mm x 550 mm with green rubber mat).
Five metres of cable connects the base to the stainless steel indicator which features clear 17 mm high
LCD display digits. A plastic display bracket is included to enable the indicator to be wall or bench mounted.
Key display features are: on/o, push button tare to enable container weights to be removed and net weight
only displayed; kg/lb switching to give readings in either metric or imperial measures and hold/print, which
allows the weight to be either frozen even when the item being weighed is removed or the weight to be
transmitted to a printer or other peripheral device via the RS-232 port (cable not included).
The scales feature auto zero tracking to automatically compensate for small uctuations in zero such as
a build up of material on the platform. To extend battery life an auto-o feature is standard, with the scale
switching itself o after two minutes of inactivity.
Capacity
300 kg x 50 g
Accuracy
Within 0.1% of full capacity
Power
Four AAA batteries (not included)
or 9 VDC, 600mA adapter
Display
Five digit 17 mm / 0.625" high
with seven segment LCD
Construction
Low prole stainless steel
platform with mild steel understructure,
stainless steel/ABS indicator will wall
bracket and desk mount included
Operating Keys
On/O/Zero, Tare, Units,
Hold/Print
WS300 Light Capacity Platform Scales
Unit: kg, lb, lb/oz
Overload Capacity: Capable of withstanding 150%
capacity of weight without damaging scale
COMM Port: RS-232, bi-directional, full duplex (cable
not included)
Annunciators: Zero, net, hold, kg/lb
Calibration: Front panel accessible
Battery Life: 20 hours
Operating Temperature:
5° C to 35° C / 41° F to 95° F
Platform Dimension (L x W x H):
WS300–55: 550 mm x 550 mm x 60 mm
21.6" x 21.6" x 2.3"
WS300–90: 900 mm x 550 mm x 60 mm
35.4" x 35.4" x 2.3"
Indicator Dimension (L x W x H):
165 mm x 30 mm x 81 mm
6.5" x 1.2" x 3.2"
Product Weight:
WS300-55: 15 kg / 33 lb
WS300-90: 17 kg / 37 lb
Packaging Dimension (L x W x H):
WS300-55: 690 mm x 690 mm x 140 mm
WS300-90: 1030 mm x 690 mm x 140 mm
Shipping Weight:
WS300-55: 17 kg / 37 lb
WS300-90: 19 kg / 41 lb (includes rubber mat)
Certications: FCC compliant, Prop 65, UL /CUL
power adapter, UKCA, CE, RoHS 3, WEEE
SpecicationsSpecications
WS300_RoW_L_100141.indd
V6 AWT35-100141
Brecknell is part of Avery Weigh-Tronix. Avery Weigh-Tronix is a trademark of Illinois Tool Works group of companies whose ultimate
parent company is Illinois Tool Works Inc (“Illinois Tool Works:). Copyright © 2024 Illinois Tool Works. All rights reserved. This
publication is issued to provide outline information only and may not be regarded as a representation relating to the products or
services concerned. This publication was correct at the time of going to print, however Avery Weigh-Tronix reserves the right to alter
without notice the specication, design, price or conditions of supply of any product or service at any time.
www.brecknellscales.com
www.brecknellscales.co.uk
Part of Avery Weigh-Tronix
