Solid construction and easy operation make the PS3000-LCD Floor Scale the ideal solution for weighing large
animals and veterinary usage, as well as freight operations.
This scale has a 6.5 x 3.3 ft / 2 x 1 m platform with rubber mat as standard that reduces noise and risk of
animals/goods slipping while weighing.
Simple to-operate, the indicator oers all the weighing functions needed for a wide range of applications as
well as the display-hold function that retains results on the screen, while you tend to the animal.
AC and battery powered means this scale can easily be installed in remote locations where power sockets
are not available.
Durable design for rigorous applications. The PS3000-LCD is tted with four waterproof IP67 load cells for
easy clean-up between weighing sessions.
Display
Six large,easy-to-read 1.5" / 38 mm
high digits. large seven segment LCD
with white backlight
Operator Keys
On/O/Zero, Tare, Unit, Print, Hold,
Accumulate/Total
Capacity
3000 lb x 1.0 lb / 1500 kg x 0.5 kg
Accuracy
Within 0.1%
Power
9V 600mA universal power supply with
USA/UK/EU adapters (incuded) or six AA
batteries (not included)
Construction
Mild steel construction, heavy duty
welded channel and powder coated
surface finish. Robust ABS plastic
indicator with bench or pole brackets
for mounting.
PS3000-LCD
Floor Scale
Shown with optional indicator stand
SBI 210 Indicator SpecicationsSBI 210 Indicator Specications
PS3000-LCD Floor SpecicationsPS3000-LCD Floor Specications
PS3000-LCD Floor Scale
Construction: Robust ABS housing
Annunciators: -0-, motion, gross, net, tare, hold, pcs,
%, HI/OK/LOW, battery, accumulation
Units: kg, lb, pcs, %
Tare: 100% subtractive
Check Weighing: Used when packing or lling to a set
weight. This provides the operator a fast & simple
visual to let them know the product is within the ac-
cepted weight window.
Counting: Used for stock control or to quickly work out
the quantity of items within a box
Accumulation: Used when packing multiple items into
one consignment to get the nal consignment weight
total
Hold: Allows a stable weight to be easily held once the
goods have been removed from the scale
Animal Averaging Hold: Allows the animal weight to
be correctly calculated even when it slightly moves
around. Allows the animal to be weighed by a single
person. This easy-to-use hold feature allows the
scale to capture the weight and retain it while you
tend to the animal.
Percentage: Allows the operator to easily carry out
weightments on % basis
Mounting Brackets: Can be desk mounted or pole
mounted either vertical or horizontally
Display: Large, easy-to-read six digit 1.5" / 38 mm high
digit LCD with backlight
Power: 9V 600mA, 110-230V switch mode external
power supply with USA/UK/EU interchangeable plug
adapters or six AA batteries (not included)
Connection: 250 mm / 9.8" cable is xed to indicator
side with quick release connector. An additional 3 m /
10' of cable is connected to the oor scale junction box.
Built-in Power Saving Features: Subject to how the
scale is to be used, there are a number of ways to
prolong the battery life of this scale. From turning o
the backlight to setting the auto o to engage when the
scale is not in use.
Communication: One USB (VCP) and one RS-232
bi-directional full duplex port. Optional COM cables.
Calibration: Front panel calibration
Indicator Packing: Comes packed in a separate box
along with the oor scale base
Operating Temperature:
14º F to 104º F / -10º C to 40º C
PS300HD-LCD_L_100069.indd
V4 AWT35-100069
Brecknell is part of Avery Weigh-Tronix. Avery Weigh-Tronix is a trademark of Illinois Tool Works group of companies whose ultimate
parent company is Illinois Tool Works Inc (
“Illinois Tool Works”
). Copyright © 2024 Illinois Tool Works. All rights reserved. This
publication is issued to provide outline information only and may not be regarded as a representation relating to the products or
services concerned. This publication was correct at the time of going to print, however Avery Weigh-Tronix reserves the right to alter
without notice the specication, design, price or conditions of supply of any product or service at any time.
www.brecknellscales.com
www.brecknellscales.co.uk
Part of Avery Weigh-Tronix
Capacity: 3000 lb x 1.0 lb / 1500 kg x 0.5 kg
Construction: Powder coat paint for corrosion
protection. 3/52" thick mild steel construction with
safety tread plate surface and rubber mat.
Load Cells: Four OIML C3 waterproof IP67 350 Ohm
shear beam load cells
J-Box: Weatherproof IP65 ABS junction box with oor
scale top access for ease of installation and service
Anti-slip Rubber Mat: Easy on animal hooves,
reduces noise and risk of slipping (included)
150% Overload Protection
Platform Dimension (L x W x H):
78.75" x 39.37" x 3.93"
2000 mm x 1000 mm x 100 mm
Platform Weight: 264 lb / 120 kg
Packaging Dimension (L x W x H):
81" x 42" x 7.1" / 2050 mm x 1050 mm x 180 mm
Shipping Weight (platform + indicator):
275 + 4.4 lb / 125 + 2 kg
Certications: FCC compliant, Prop 65, ETL power
adapter, UKCA, CE, RoHS 3, WEEE
Options: Indicator oor stand, platform foot, RS-232,
USB cables
