Cadel Sfera Plus 11 Bruksanvisning
Läs gratis den bruksanvisning för Cadel Sfera Plus 11 (47 sidor) i kategorin element. Guiden har ansetts hjälpsam av 3 personer och har ett genomsnittsbetyg på 4.3 stjärnor baserat på 2 recensioner. Har du en fråga om Cadel Sfera Plus 11 eller vill du ställa frågor till andra användare av produkten? Ställ en fråga
Sida 1/47
EN
©2018 CADEL srl | All rights reserved - Tutti i diritti riservati
INSTALLER MANUAL
Pellet Stove
SFERA
3
11KW - PRINCE
3
11KW- GLOBE AIRTIGHT
SFERA
3
PLUS 11KW - SIRE
3
PLUS 11KW - DOGE
3
PLUS 11KW -
PRINCE
3
PLUS 11KW - ELISE
3
PLUS 11KW - VEGA AIRTIGHT - TREND AIRTIGHT
VENUS
3
PLUS 12,5KW - JOY AIRTIGHT
SFERA3 - PRINCE3 - GLOBE AT - SFERA3 PLUS - SIRE3 PLUS - DOGE3 PLUS - PRINCE3 PLUS - ELISE3 PLUS - VEGA AT - TREND AT - VENUS3 PLUS - JOY AT
2
SUMMARY
1 MANUAL SIMBOLOGY ....................................3
2 PACKAGING AND HANDLING ..........................3
2.1 PACKAGING .............................................................3
2.2 REMOVING THE STOVE FROM THE PALLET ..............3
2.3 STOVE HANDLING....................................................4
3 CHIMNEY FLUE ...........................................4
3.1 INTRODUCTION .......................................................4
3.2 CHIMNEY FLUE ........................................................4
3.3 TECHNICAL FEATURES ............................................. 5
3.4 HEIGHT-DEPRESSION .............................................. 6
3.5 MAINTENANCE ........................................................6
3.6 CHIMNEY POT ..........................................................6
3.7 CHIMNEY COMPONENTS .........................................7
3.8 CHIMNEY FLUE CONNECTION ..................................7
3.9 EXAMPLES OF CORRECT INSTALLATION ..................8
4 COMBUSTION AIR .......................................10
4.1 EXTERNAL AIR INLET .............................................10
4.2 COMBUSTIBLE AIR INLET FOR SEALED-CHAMBER
INSTALLATION .................................................................11
4.3 COMBUSTIBLE AIR INLET FOR SEALED-CHAMBER
INSTALLATION .................................................................12
5 INSTALLATION ............................................12
5.1 INTRODUCTION .....................................................12
5.2 OVERALL DIMENSIONS .........................................13
5.3 GENERAL INSTALLATION ....................................... 21
5.4 FRONTAL PANEL ASSEMBLY (VEGA/TREND/PRINCE
3
/
PRINCE
3
PLUS MODELS) ...................................................21
5.5
FRONTAL PANEL ASSEMBLY (VEGA STONE MODEL) .......
21
5.6 TILE ASSEMBLY (SIRE
3
PLUS MODEL) .................... 22
5.7
PANELS ASSEMBLY (SFERA
3
/SFERA
3
PLUS MODELS)
.....23
5.8 PANELS ASSEMBLY (VENUS
3
PLUS MODEL) ..........23
5.9
FRONT PANEL ADJUSTMENTS (ELISE
3
PLUS MODEL) ......
25
5.10 STOVE DOOR REMOVAL/INSTALLATION ................25
5.11 CONNECTION TO THE EXTERNAL THERMOSTAT .....26
5.12 ELECTRIC CONNECTION .........................................26
5.13
STOVE CALIBRATION AND DEPRESSION MEASUREMENT
...27
5.14 HOT AIR DUCTING SYSTEM (VEGA/TREND/SIRE
3
PLUS/DOGE
3
PLUS/SFERA
3
PLUS/ELISE
3
PLUS/PRINCE
3
PLUS
MODELS) .......................................................................... 28
5.15 HOT AIR DUCTING SYSTEM (VENUS
3
PLUS / JOY
AIRTIGHT) ........................................................................29
5.16 USING THE STOVE WITHOUT DUCTING ..................32
6 SPECIAL MAINTENANCE ..............................32
6.1 INTRODUCTION .....................................................32
6.2 FEED SCREW MAINTENANCE.................................32
6.3
FUME CHAMBER AND FUME PASSAGES CLEANING .....
33
6.4 FUME CONDUIT CLEANING .................................... 37
6.5 FUME FAN CLEANING ............................................38
6.6 ROOM FAN CLEANING ...........................................38
7 IN CASE OF ANOMALY ..................................39
7.1 PROBLEM SOLVING ...............................................39
8 TECHNICAL DATAS ......................................42
8.1 FUSE REPLACEMENT .............................................42
8.2 FEATURES ..............................................................43
