Operation Guide 5345

MA1212-EA

#!3)/#/-054%2#/,4$

To change the day indicator setting

To adjust the time setting

Pull the out to Click 1. Crown

Push the back in. Crown

Rotate the to change the Crown

time setting.

When the second hand is at

12 o’clock, pull the Crown out to

Click 2.

Rotate the to set the day. Crown

Note

Take care that you set the correct AM

or PM time.

When changing the time, move the

minute hand four or ﬁ ve minutes past

your ﬁ nal setting, and then back it up

to the setting you want.

Note

The day indicator setting uses a 31-

day month. Make adjustments for

months of shorter lengths.

Avoid changing the day indicator

setting between the hours of 9

p.m. and 1 a.m. Otherwise, the day

indicator may not change correctly at

midnight.

Speciﬁ cations

Accuracy: ±20 seconds average per month

Stopwatch: Measuring Capacity: 59'59.9" (60 minutes)

Measuring Unit: 1/10 second

Measurements: Elapsed time; split time; two ﬁ nishes

Battery: One silver oxide battery (Type: SR920SW)

Battery Life: Approximately 2 years (60 minutes stopwatch operation per day)

Stopwatch functions

Crown Operations

Some water-resistant models (100 meters, 200 meters)

have a screw-in crown. When you need to perform a crown

operation, rotate it towards you to unscrew it. Then pull

the crown out. Avoid applying undue force when pulling.

The watch loses its water resistance while the crown is

unscrewed. After performing a crown operation, fully screw

the crown back in.

Crown

Loosen

If your watch has a rotary bezel...

You can rotate the bezel to align its ▼ mark with the

minute hand. Then you will be able to tell how much

time has elapsed since aligning the ▼ mark.

Start

Elapsed time

Current

Your watch may differ somewhat from the one shown in the illustration. x

Some models may use a combination of hands and rotating disks to indicate x

information. The word “hand” in this section is used to mean both analog hands

and rotating disks.

Using the Stopwatch

Elapsed time

A A A A B

Start Stop Re-start Stop Reset

Split time

A B B A B

Start Split Split release Stop Reset

Two ﬁ nishes

A B A B B

Start Split

First runner

ﬁ nishes.

Display time of ﬁ rst

runner.

Stop

Second runner

ﬁ nishes.

Split release

Display time of

second runner.

Reset

Important!

Do not operate the stopwatch with the crown pulled out.

Note

An elapsed time operation will stop automatically at the end of 60 minutes.

The stopwatch measures elapsed time in 1/10-second increments up to 59 minutes,

59.9 seconds.

Perform the following procedure if the stopwatch hands do not return to their 0 (zero)

positions when you reset the stopwatch.

Correcting the 0 Positions of the Hands

Pull the out to Click 2. Crown

Press to move the A Stopwatch 1/10-Second Hand clockwise.

Holding down xA will move the hand at high speed.

Press to move the B Stopwatch Second Hand clockwise.

Holding down

xB will move the hand at high speed.

The x Stopwatch Minute Hand is synchronized with the Stopwatch Second Hand .

After all of the hands are the way you want, push the back in. Crown

Important!

Timekeeping stops while the crown is pulled out. Correct the current time setting

after performing the above operation.



Second Hand

Day Indicator

Click 2

Click 1

Hour Hand Minute Hand

Crown

Stopwatch Minute Hand

Stopwatch 1/10-Second Hand

Stopwatch Second Hand
