SAFETYREVERSINGSENSORREPLACEMENT
041-0136&041-0155
BesurepowerisNOTconnectedtothegaragedooropenerBEFOREinstallingthe
safetyreversingsensor.
TopreventSERIOUSINJURYorDEATHfromclosinggaragedoor:
•Correctlyconnectandalignthesafetyreversingsensor.Thisrequiredsafety
deviceMUSTNOTbedisabled.
•InstallthesafetyreversingsensorsobeamisNOHIGHERthan6"(15cm)
abovegaragefloor.
WARNING:Thisproductcanexposeyoutochemicalsincludinglead,whichare
knowntotheStateofCaliforniatocausecancerorbirthdefectsorother
reproductiveharm.Formoreinformationgotowww.P65Warnings.ca.gov
Theimagesthroughoutthismanualareforreferenceonlyandyourproductmaylook
different.
INSTALLTHESAFETYREVERSINGSENSORS
Disconnectpowertothegaragedooropenerbeforeyoubegin.
Thesafetyreversingsensorsaredesignedtoclipontothedoortrackwiththeprovided
sensorbrackets.Ifthedoortrackwillnotsupportthesensorbracketawallinstallationis
recommended.ThesensorbeamshouldbeNOHIGHERthan6"(15cm)abovethefloor.
DOORTRACKINSTALLATION
1.Slidethecurvedarmsofthesensorbracketaroundtheedgeofthedoortrack.
Snapintoplacesothatthesensorbracketisflushagainstthetrack.
2.Slidethehexscrewthroughthesensor.
3.Attachthesensortothebracketwiththewingnut.Makesurethelensisnot
obstructedbythebracket.
Repeatthestepswiththeothersensorontheoppositedoortrack.Bothlensesmust
faceeachother.
6" (15 cm) max.
Door track
1
23
Garage door
Wing nut
WALLOPTION
Makesurethebracketsoneachsideareclearofthedoortrackandhavethesame
amountofclearancesothesensorswillaligncorrectly.Ifadditionalclearanceisneeded,
useextensionbrackets041A5281-1(notprovided)orwoodblocks.
1.Attachthesensorbracketagainstthewallwithtwolagscrews(notprovided).
2.Slidethehexscrewthroughthesensor.
3.Attachthesensortothebracketwiththewingnut.Makesurethelensisnot
obstructedbythebracket.
Repeatthestepswiththeothersensorontheoppositesideofthegaragedoor.Both
lensesmustfaceeachother.
OR
1
Wing Nut
OPTIONAL
23
Door track
Inside
garage wall
6" (15 cm)
max.
Not provided
FLOOROPTION
1.Measurethepositionofbothsensorbracketssotheywillbethesamedistance
fromthewallandunobstructed.
2.Attachthebrackettothefloorwithconcreteanchors(notprovided).
3.Slidethehexscrewthroughthesensor.
4.Attachthesensortothebracketwiththewingnut.Makesurethelensisnot
obstructedbythebracket.
Repeatthestepswiththeothersensorontheoppositesideofthegaragedoor.Both
lensesmustfaceeachother.
1
34
2
Inside
garage wall
Not provided
Door track
6" (15 cm) max.
Wingnut
