Sida 1/5
English
GREAT BRITAIN • CUSTOMER SERVICE
tel: 0845 3009 799 www.clasohlson.com/ukinternet:
e-mail customerservice@clasohlson.co.uk
24
1
23
22
20
19
21
1
4
3
2
Ver. 20140108
Plug-in Timer
Art. no 18-2024 Model 15UKD/3A
36-2400 15GD/3A
36-2900 15ND/3A
Please read the entire instruction manual before using the product and save it for future reference.
We reserve the right for any errors in text or images and any necessary changes made to technical data.
If you have any questions regarding technical problems please contact our Customer Services.
Safety
• Electrical devices connected to the timer should be
intended for use with a 230 V AC, 50 Hz power supply.
• The timer is only intended for indoor use.
• Make sure that the plug is pressed all the way into
the timer’s socket.
• Do not expose the timer to moisture.
• Ensure that the connected appliance does not pose
a fire hazard.
• If you need to clean the timer, disconnect it from
the mains and wipe it clean with a dry towel.
Do not use water or any other liquid for cleaning.
Product description
Timer with day function. Minimum timer activation time:
30 minutes. Switch for selecting timer control or continuous
wall outlet function.
Setting the timer
Example: If you want the timer to activate at 10 pm
(22:00) and turn off at 11 pm (23:00):
Press in the 2 tappets spanning 22 and 23. The timer
will then activate between 10 pm and 11 pm and then
deactivate and will not reactivate until 10 pm the following
evening.
Setting the current time
1. Set the current time by turning the dial (4) clockwise
until the arrow is aligned with the current time (2).
2. Set the selector switch (3) to the position.¿
Troubleshooting
The connected
device does not
turn on.
• Make sure that the product
works by connecting it to
a standard wall outlet and
test if it works.
• Make sure that the connected
product is turned on.
The product doesn’t
seem to work off the
timer. The product is
on all the time.
Make sure that the timer (3) is in
the position.¿
Disposal
This product should be disposed of in accordance with
local regulations. If you are unsure how to proceed,
contact your local authority.
Specifications
Rated voltage 230 V AC, 50 Hz
Max resistive load 36-2400, 36-2900: 16 A
18-2024: 13 A
inductive load max 460 VA
Operating temperature 0-55 °C
Accuracy ± 5 minutes/day
1. Time segment tappets
2. Current time indication arrow
3. Selector switch
4. Time setting dial
Operating instructions
Use as a standard wall plug
Set the selector switch (3) to the ( | ) position. Connect the
light, appliance, etc. and make sure that it is turned on.
Timer controlled
Note: All time segment tappets (1) are pushed in from
the factory, which means it will be in constant on mode.
Begin by pulling up all the tappets before setting the timer.
The time setting dial (4) is marked with the hours in a day
(1–24 hrs).
