Page 1 of 3

CAUTION

·TO AVOID THE RISK OF FIRE OR SHOCK, FIXTURE MUST BE INSTALLED IN COMPLIANCE WITH

ALL APPLICABLE NATIONAL AND LOCAL ELECTRICAL/BUILDING CODES.

·INSTALLATION AND MAINTENANCE OF THIS UNIT REQUIRES AN ELECTRICIAN OR

CERTIFIED FACTORY TRAINED TECHNICIAN.

·If an existing fixture is being replaced, remove it and note to which of the wires in the outlet box the fixture was attached.

DO NOT SEPARATE ANY OTHER WIRES THAT MAY BE IN THE BOX. DO NOT DAMAGE THE INSULATION OF OLDER WIRING.

In regular circumstances the BLACK wire will be the "Hot" lead and the WHITE wire will be the "Neutral" or "Common" lead

A GREEN or BARE COPPER wire is the "Ground". In older buildings it is always good practice to reconfirm the polarity of the wiring.

163-08 8LTS. AMADEUS CHANDELIER INSTALLATION INSTRUCTIONS

WARNING

DISCONNECT POWER BEFORE RE-LAMPING OR WIRING THE FIXTURE

READ ALL INSTRUCTIONS COMPLETELY BEFORE STARTING INSTALLATION.

NOTICE

·The important safeguards and instructions outlined on this sheet cannot cover all possible conditions and situations that

may occur. it must be understood that common sense, caution and care factors that cannot be built into any product.

Caution and care must be supplied by the person(s) installing, operating and caring of this lighting fixture.

·This fixture is designed to be mounted on a correctly installed standard round or octagon box or a through wiring box

with a plaster frame. The box must be securely mounted to the structure of the building. The crossbar and hardware supplied

should be used. directly mounting the fixture to the outlet box may make it impossible to correctly align the fixture.

FIGURE-1

FIXTURE INSTALLATION

1. Attach the SAFETY CABLE to the building structure or brace (See figure-1).

2. Attach the crossbar to the outlet box.

(The green screw should face the floor).

3. Remove the threaded ring from the screw collar loop. Fully thread

the screw collar loop onto the nipple. Thread the hex nut onto the

nipple and the nipple into the crossbar. Place the canopy over the

screw collar and against the ceiling. Adjust the nipple so that 1#4"

of threads on the screw collar loop extend beyond the canopy.

Tighten the hex nut against the crossbar. Using the threaded ring,

install the canopy.

FIXTURE PREPARATION

1. Remove the fixture, shell/crystal strands,

parts and parts bag(s) from the carton.

NOTICE:

Before discarding the carton,

double check to make certain that all parts are found.

Mounting

Parts

Canopy

Nipple

Hex nut

Screwcollar loop

Ring

Chain

Green screw

Structure or Brace

Outlet box

Mounting bar

SAFETY CABLE

WARNING

REFER TO THE ILLUSTRATION FOR CORRECT AND SAFE INSTALLATION OF SAFETY

CABLE. FAILURE TO FOLLOW THIS INSTRUCTION COULD RESULT HARM/DAMAGE TO

THE FIXTURE, PROPERTY AND/OR PERSON(S)!

NOTICE:

THIS LUMINAIRE MUST BE MOUNTED OR

SUPPORTED INDEPENDENTLY OF AN OUTLET BOX.

Lock Washer
