HX SERIES

High Performance ATX Power Supply

HX750 HX850

HX SERIES

ENGLISH ....................................................... 1

FRANÇAIS ..................................................... 7

DEUTSCH ................................................... 13

NEDERLANDS ............................................ 19

DANSK ........................................................ 25

SUOMI ......................................................... 31

SVENSKA .................................................... 37

NORSK ........................................................ 43

ITALIANO ..................................................... 49

ESPAÑOL .................................................... 55

PORTUGUÊS .............................................. 61

POLSKI ........................................................ 67

PУССКИЙ ..................................................... 73

简体中文 ...................................................... 79

繁體中文 ...................................................... 85

ةيبرعلا ............................................................ 91

1 2

ENGLISH ENGLISH

TABLE OF CONTENTS

SAFETY AND PROTECTION

INTRODUCTION

Congratulations on the purchase of your new CORSAIR HX Series ATX Power Supply!

CORSAIR HX Series fully modular power supplies deliver reliable 80 PLUS Platinum efcient power to your

system combined with a high performance 140mm Fluid Dynamic Bearing (FDB) fan.

> Over-Voltage Protection (OVP)

Over-voltage protection for the 12V, 5V, and 3.3V DC outputs is required to comply with the ATX specication.

OVP shuts down the PSU in the event that the DC outputs exceed a set level, determined by

the PSU manufacturer.

> Over-Current Protection (OCP)

The HX Series features OCP on the 3.3V, 5V, and 12V rails. OCP ensures that the output of the DC voltage rails

remains within safe operating limits.

> Over-Temperature Protection (OTP)

OTP ensures that the PSU will shut down when the internal temperature reaches a set point. This is usually as

a result of internal current overloading or a fan failure.

> Short-Circuit Protection (SCP)

A short-circuit is dened as any output impedance of less than 0.1 ohms. Amongst other things, SCP ensures

that the PSU shuts down should the 3.3V, 5V, and 12V rails short to any other rail, or to ground. It also ensures

that no damage should occur to the unit, or your PC’s components in the event of a short.

HX750 ........................................................................................................................................................................ 3

HX850 ........................................................................................................................................................................ 5

Installation .................................................................................................................................................................9
