Sida 1/2

Steel-based Minimalist Headband Design

Extra-large Foam Ear Pad

Microphone

Separate Line In/out

Volume Control Unit

PRODUCT PARTS AND PACKAGE CONTENTS

B B

DEUTSCH

●

Ausgezeichneter Stereoton: 40-mm-Treiber

●

Komfort und Isolation: Extragroßes Schaumstoff-Ohrpolster

●

Beständigkeit und Stil: Stahlbasierter Bügel

●

Perfekte Klarheit: Mikrofon mit Rauschunterdrückung

●

Bequemlichkeit: Lautstärkeregler und Mikrofonsteuerung

●

SUPERB STEREO AUDIO

PHONTUM Essential's 40mm Driver will bring you all the audio details you need to

enjoy your games and make sure you don't miss any in-game nuance or signal.

●

EXTRA LARGE FOAM EAR PAD

For extra comfort, we have made PHONTUM Essential's earpads extra large.

They will comfortably cover your ear, ensuring both an agreeable experience and

excellent isolation.

●

STEEL HEADBAND

PHONTUM Essential's backbone is a steel headband that delivers both durability

and flexibility.

This headset will serve you for a long, long time!

●

NOISE CANCELLATION MICROPHONE

To allow you to communicate easily with your teammates, PHONTUM Essential's

microphone includes noise cancellation technology. This ensures that background

noises do not interfere with your in-game coordination.

●

VOLUME AND MICROPHONE MUTE CONTROLS

It couldn't be more convenient: the incorporated control system allows you to adjust

on-the-go the volume and to mute the microphone, if needed.

FEATURES

ENGLISH

●

Soberbo Áudio Estéreo: 40mm Driver

●

Conforto e Isolamento: Almofada de orelha de espuma extra grande

●

Durabilidade e Estilo: Faixa de Cabeça com Base de Aço

●

Claridade Perfeita: Microfone com Cancelamento de Ruído

●

Conveniência: Controle de Volume e Controle de Troca de Microfone

PORTUGUÊS

www.cougargaming.com

●

Качественный стерео звук: 40-мм драйвер

●

Комфорт и изоляция: Увеличенные амбушюры

●

Надежность и стиль: изголовье из стали

●

Чистый звук: микрофон с технологией шумоподавления

●

Удобство: регулировка громкости и переключатель микрофона

РУССКИЙ

ESPAÑOL

●

Increíble Sonido: Altavoz de 40 mm

●

Confort y Aislamiento: Almohadillas Extragrandes

●

Estilo y Durabilidad: Diadema de Acero

●

Total Claridad: Micrófono con Cancelación de Ruido

●

Conveniencia Total: Control de Volumen y de Silenciado de Micrófono

FRANÇAIS

●

Superbe son stéréo : Haut-parleur 40 mm

●

Confort et isolation : Coussinets en mousse de très grande taille

●

Durabilité et style : Arceau à base en acier

●

Clarté parfaite : Micro à annulation de bruit

●

Commodité : Contrôle du volume et commutateur de micro

POLISH

●

Doskonała jakość dźwięku stereo: przetwornik 40 mm

●

Wysoki komfort i izolacja: bardzo duże poduszki z pianki

●

Trwałość i styl: stalowy pałąk

●

Idealna czystość dźwięku: mikrofon do eliminacji szumu

●

Wygoda: regulacja głośności i przełącznik mikrofonu

ESSENTIAL

REAL GEAR FOR REAL GAMERS

USER MANUAL

MANUFACTURER CONTACT

Compucase Enterprise Co.,Ltd.

No. 225, Lane 54, An Ho Road Sec. 2 Tainan,

Taiwan, R.O.C

Tel:+886-6-356-0606

More information you will find at cougargaming.com

Compucase Enterprise Co.,Ltd.

Made in China

LEGAL NOTICES

This manual was created by Compucase Enterprise and may not be completely

or partially copied, passed on, distributed or stored without written consent by

Compucase Enterprise.

COUGAR® is a registered brand of Compucase Enterprise Other product and

company names mentioned in this documentation may be brands or trademarks

of their respective owners.

Compucase Enterprise reserves the right to make changes concerning the

contents of the manual and the technical data of the product without previous

announcement.

All other registered trademarks belong

to their respective companies.

DISCLAIMERS

●

COUGAR product is not authorized for use as critical components in life support

device or for incorrect application software or malfunction of the product.

●

COUGAR is not liable for the death or damage of person or loss of property when

product is using as, including but not limited to, medical equipment, military

equipment, traffic equipment and disaster prevention system.

●

COUGAR is not liable for any damages, expenses, lost data, lost revenues, lost

savings, lost profits, or any incidental or consequential damages due to using

defect product of COUGAR.

If you have any question about the warranty, please feel free to contact us.

Customer support: https://cougargaming.com/support/contact/upload/

CONDITIONS WHERE FREE MAINTENANCE IS NOT PROVIDED

●

Any fault or damage caused by natural disasters (including storm, fire, flood,

thunder, earthquake, etc).

●

Any fault or damage caused by accidental factors and man-made reasons

(including hit, scrape, crash, moving, compression, stain, corrosion, use of

incurred on unsuitable voltage, computer virus, riot, misuse, malicious damage, etc).

●

Use in an improper operating environment (including high temperature, high

humidity, water inflow, etc).

●

Inability to provide the product warranty card, purchase receipt or invoice to

prove the product is still within the warranty period and the shipping date of the

product is out of warranty.

●

The warranty card or product serial number has been altered or its number is

hard to identify.

●

The warranty period has expired.

●

Any fault or damage caused by non-compliance with regulations stated on the

user manual or improper, rough and careless treatment.

●

Any fault or damage caused by use of parts not certified by COUGAR original

manufacturer.

●

The problem is caused by improper repair or adjustment by the buyer or any

manufacturer without authorization from COUGAR.

●

The product is not acquired from an authorized distributor of the company or is

acquired from illicit sources.

●

Paper carton, instruction and other accessories are not warranted.

WARRANTY AGREEMENT

●

If the product has defects in material or manufacture, COUGAR will provide

product repair and replacement service within the warranty period.

●

Our warranty service is based on the date of the invoice or warranty card

(must be affixed with the store stamp).

If you lose the aforementioned evidence, we will apply the original shipping date

of the product as the beginning date of warranty period. The shipping date will

be identified by the product serial number(S/N).

GLOBAL WARRANT Y POLICY

WARRANTY PERIODS OF COUGAR GAMING DEVICES

Product : COUGAR PHONTUM ESSENTIAL gaming headset

Warranty : 1 Year

This warranty gives you specific legal rights. You may also have other rights

granted under local law. These rights may vary.

HEADPHONES

Drivers

Sensitivity at 1KHz

Impedance at 1KHz

Frequency response

Cable Length

40mm

20Hz - 20KHz

32Ω +/- 15%

101dB ± 3dB

COUGAR PHONTUM ESSENTIAL

Gaming Headset

User Manual

1.9m

The above specifications may vary by country or region

SPECIFICATIONS

Type

Frequency

Sensitivity at 1KHz

Noise Cancelling

Condenser

MICROPHONE

100Hz to 10KHz

Impedance 2.2kΩ

-40dB ± 3dB

PACKAGE CONTAINS

HARDWARE REQUIREMENTS

Dual Jack Devices ( for usage with the audio/mic )

●

Audio + Microphone: Separate 3.5 mm audio and microphone jacks

Warning! In order to avoid permanent

hearing damage, please always use your

headset at safe volume levels. Exposure

to high sound levels for extended periods

of time may cause permanent hearing

damage and even loss.

中文

●

卓越立体音效: 40m m单体驱动器

●

兼具舒适度并隔绝外界噪音: 特大版记忆棉耳罩

●

高耐用度及独特设计: 钢制头条

●

音质完美清晰:降噪电容式麦克风音头

●

便利性佳 : 调整音量与切换麦克风功能

한국어

●

슈퍼 스테레오 오디오 : 40mm 드라이버

●

편안함과 소음차단 : 초대형 폼 Earpad

●

내구성과 스타일 : 스틸 기반 헤드밴드

●

완벽한 선명도 : 잡음 제거 마이크

●

편리성 : 볼륨 제어 및 마이크 스위치 제어

日本語

●

優れたステレオオーディオ性能：40mm径のドライバーを採用

●

メモリーフォーム素材を採用した大型イヤーパッド、長時間の使用でも快適です。

●

スタイリッシュな外観と耐久性を両立したスチール製ヘッドバンド

●

音をクリアに伝えるノイズキャンセリングマイクを搭載

●

マイクのミュートとボリューム調節機能付き

HUNGARIAN

●

Kiváló sztereó hangminőség: 40 mm-es meghajtó

●

Kényelem és szigetelés: Rendkívül nagy, habból készült fülpárna

●

Tartósság és stílusos külső: Acél alapú fejpánt

●

Tökéletes hangtisztaság: Zajszűrő mikrofon

●

Kényelem: Hangerő-szabályozás és mikrofonváltó vezérlő

●

Audio in Stereo di qualità superba: Driver da 40 mm

●

Comodità e isolamento: Cuscinetto auricolare in gommapiuma di grandi dimensioni

●

Longevità e stile: Stringitesta in acciaio

●

Chiarezza perfetta: Microfono cancella-rumore

●

Convenienza: Controllo del volume e controllo attivazione microfono

ITALIANO

COUGAR USA Technical Service

Tel: (833) 256-3778

Mail: rma@compucaseusa.com

Service email : https://cougargaming.com/support/contact/upload/

год и месяц изготовления продукции указаны в серийном номере

продукта.(существует 2 способа определения даты изготовления,

оба способа описаны ниже)

После S/N: первые две цифры означают год, вторые две –

месяц изготовления.

Например, S/N: H 000001 означает, что товар был 1702

произведен в феврале 2017 года.

После S/N: если указаны буквы, то две буквы представляют

цифры из таблицы ниже, и означают год,

последующие две цифры – месяц изготовления.

Например, S/N: D REVI000001 означает, что товар был AG02

произведен в феврале 2017 года.

●

Например, AG = 17 = 2017 год

ДАТА ИЗГОТОВЛЕНИЯ ПРОДУКЦИИ

A B C D E F G H I J

1 3 4 5 6 8 9 02 7

Produktspecifikationer

Varumärke:	Cougar
Kategori:	Headset
Modell:	Phontum Essential
Produkttyp:	Headset
Färg på produkten:	Zwart
Bredd:	150 mm
Djup:	140 mm
Höjd:	86 mm
Ljudnivå:	- dB
Förpackningens bredd:	266 mm
Djuppackning:	194 mm
Förpackningshöjd:	192 mm
Användarmanual:	Ja
Nuvarande:	4.5 - 9 A
På / Av knapp:	Ja
Volymkontroll:	Rotations-
Certifiering:	CE/TUV/FCC/CCC/BSMI/KCC/RCM/EAC/UL
Avsedd för:	PC
Rekommenderad användning:	Spela
Impedans:	32 Ω
USB-anslutning:	Nej
Antal fans:	1 ventilator(en)
Kabelfärg:	Svart
Strömspänningsskydd:	Over current, Over power, Over voltage, Short circuit, Under voltage
80 PLUS certifiering:	80 PLUS Gold
Medeltid mellan fel (MTBF):	100000 uur
Totala tillgångar:	650 W
Mikrofonfrekvens:	100 - 10000 hz
Effektivitet:	90 procent
AC-ingångsspänning:	90 - 264 V
AC-ingångsfrekvens:	50 - 60 Hz
Drifttemperatur (TT):	0 - 40 °C
Ventilator diameter:	120 mm
Brusreducerande mikrofon:	Ja
Anslutning för diskettstation:	Ja
Moderkorts strömkontakt:	20+4 pin ATX
Perifera (Molex) strömkontakter (4-stift):	6
Strömförsörjningsformfaktor (PSU):	ATX
Power Factor Correction (PFC) typ:	Actief
Kombinerad effekt (+3,3V):	120 W
Kombinerad effekt (+12V):	648 W
Kombinerad effekt (+5V):	120 W
Max aktuell utgång (+3,3V):	25 A
Max strömutgång (+12V):	54 A
Max aktuell utgång (+5V):	22 A
Max strömutgång (-12V):	0.3 A
Max strömutgång (+5Vsb):	2.5 A
Kombinerad effekt (-12V):	3.6 W
Kombinerad effekt (+5Vsb):	12.5 W
Antal SATA-strömkontakter:	8
Kabeltyp:	Semi-modulair
ATX version:	2.31
Håll tid:	16 ms
CPU-strömkontakt (4+4-stift):	Ja
ATX-strömkontakt (20+4-stift):	Ja
Fläktplats:	Boven
PCI Express-kontakt:	Ja
Drivenhet:	40 mm
Kabellängd:	1.9 m
Produktens färg:	Svart
Bärstil:	Huvudband
3,5 mm kontakt:	Nej
Headset-typ:	Binaural
2,5 mm kontakt:	Nej
Anslutningsteknologi:	Kabel
Bluetooth:	Nej
Plug & Play-kompatibel:	Ja
Mikrofondämpning:	Ja
Mikrofon känslighet (utnivå):	40 dB
Antal:	1
Typ av örondel:	Omslutande
Hörlurarnas frekvens:	20 - 20000 hz
Hörlurarkänslighet:	101 dB
2 x 3,5 mm kontakter:	Ja
Mikrofon:	3,5 mm
Mikrofon ingångsimpedans:	2200 Ω
