Sida 1/4
OPERATING and MAINTENANCE INSTRUCTIONS
Model: 130 and 131 “D” Series Hot Cabinets
5925 Heisley Road • Mentor, OH 44060-1833
Call Toll-free: 877-CRES COR (273-7267) • Fax: 800-822-0393 • www.crescor.com
Proof/Hot
Cabinets
FL-2309
Rev. 5 (2/13) Page 1 of 4
Model No. Volts Watts Amps Hertz Phase NEMA
1301836D
131UA11D
131UA9D
120 1920 16.6 60 1 5-20P
1301836D208
131UA11D208
131UA9D208
208 2000 9.6 60 1 6-15P
1301836D240
131UA11D240
131UA9D240
240 2000 8.6 60 1 6-15P
All are designed for AC service.
CONTROL PANEL PARTS IDENTIFICATION
1. Switch - Power
2. Yellow Light - Power
3. Thermostat
4. Thermometer
HOW TO INSTALL UNIT:
1. Place cabinet near warm ovens. Do put in NOT
drafty areas or near ventilating systems.
2. Plug cord end into proper wall outlet.
HOW TO START UNIT:
1. Turn the POWER switch on. The light yellow
will turn on.
2. Turn thermostat to #10.
3. Preheat cabinet for 30 minutes.
4. Put food into cabinet.
5. Turn thermostat to #8 and close door.
NOTE: No. 8 setting = approx. 175°F (79°C)
No. 6 setting = approx. 165°F (74°C)
Proper food holing temperature is 140°F (60°C) or
higher. The thermometer shows the temperature inside.
TO TURN OFF UNIT:
1. Turn thermostat off.
2. Turn the POWER switch off.
3. The light will go out.yellow
5925 Heisley Road • Mentor, OH 44060-1833
Call Toll-free: 877-CRES COR (273-7267) • Fax: 800-822-0393 • www.crescor.com
OPERATING and MAINTENANCE INSTRUCTIONS
Model: 130 and 131 “D” Series Hot Cabinets
Proof/Hot
Cabinets
FL-2309
Rev. 5 (2/13) Page 2 of 4
MAINTENANCE
HOT UNIT REMOVAL INSTRUCTIONS:
1. Unplug power cord from wall outlet.
2. Remove screw from back of cabinet located just
above cord. (For Model 1301836D ONLY).
3. Pull entire unit out the front of the cabinet.
WARNING: TO REDUCE THE RISK OF FIRE OR ELECTRIC SHOCK,
DO NOT REMOVE COVER (OR BACK)
NO USER-SERVICEABLE PARTS INSIDE
REPAIR SHOULD BE DONE BY AUTHORIZED SERVICE
PERSONNEL ONLY
RISK OF FIRE OR ELECTRIC SHOCK
DO NOT OPEN
WARNING
Cleaning Notes:
• THIS UNIT IS INTENDED TO BE CLEANED USING HIGH PRESSURE CLEANING METHODS.
• The door and cabinet (inside and outside) is aluminum.
• Wipe up spills as soon as possible and clean cabinet regularly to avoid heavy dirt build-up.
• Detergents will assist in removing dirt, grease and stains. Only use detergents recommended for pressure washers.
1. Allow cabinet to cool.
2. Remove Hot unit from cabinet.
3. Do NOT use abrasives or harsh
chemicals.
HOW TO CLEAN THE CABINET:
WARNING
BEFORE cleaning
the cabinet:
OPERATING and MAINTENANCE INSTRUCTIONS
Model: 130 and 131 “D” Series Hot Cabinets
5925 Heisley Road • Mentor, OH 44060-1833
Call Toll-free: 877-CRES COR (273-7267) • Fax: 800-822-0393 • www.crescor.com
Proof/Hot
Cabinets
FL-2309
Rev. 5 (2/13) Page 3 of 4
TROUBLE-SHOOTING CHART:
FAILURE POSSIBLE CAUSE
1. Yellow light at switch does NOT light
1a. Circuit breaker/fuse to wall outlet is blown.
1b. Cord is unplugged from wall outlet.
1c. Switch is .“OFF”
2. Unit does not heat.
2a. Thermostat set too low or is .“OFF”
2b. Switch is .“OFF”
3. Unit gets too hot or won’t shut off. 3a. Defective electrical parts.
UNPLUG UNIT FROM WALL OUTLET.
4. Blower does not work or make noise. 4a. Defective blower.
NOTE: Optional digital thermometer will ash if cabinet temperature is below 140°F or above 250°F.
Call the factory if you need different settings.
If cause is none of the above, refer to our list of Authorized Service Centers, FL-1400.
REPLACEMENT PARTS:
DESCRIPTION 120 VOLT 208 VOLT 240 VOLT
Hot Unit, Model 131 Series HU1254052 HU1254053 HU1254054
Hot Unit, Model 1301836D HU1254055 HU1254056 HU1254057
Blower Kit 0769-180-K 0769-182-K 0769-182-K
Heater Kit 0811-022-K 0811-185-K 0811-023-K
Terminal Block 0852-091 0852-091 0852-091-K
Thermostat Kit 0848-062-K 0848-062-K 0848-062-K
Thermometer Kit (Analog) 5238-030-K 5238-030-K 5238-030-K
Power Cord 0810-065-1 0810-039 0810-039
Power Switch 0808-116-K 0808-116-K 0808-116-K
Pilot Light 0766-094 0766-095 0766-095
CABINET 1301836D 131UA SERIES
Door Assembly 1200-492-BL 1200-490-BL (-UA-11)
1200-491-BL (-UA-9)
Door Gasket 0861-258-K 0861-256-K (-UA-11)
0861-257-K (-UA-9)
Door Hinge 0519-105-K 0519-104-K
Door Latch 1136-043-K 1006-154-01
Pan Slides N/A 0621-281-K
