Crux Interfacing Solutions • Chatsworth, CA 91311
phone: (818) 609-9299 • fax: (818) 996-8188 • www.cruxinterfacing.com
- Integrates wired/wireless Android Auto & CarPlay, smartphone mirroring.
- Smart-Play integration system allows connection of Android and other smartphones to the Audi non-MMI system
- Control Apps using the smartphone’s voice control feature or touch panel provided.
- Retains functionality of the OEM back-up camera, if present.
- Includes AMI to RCA auxiliary adapter cable.
PRODUCT FEATURES:
ACPAD-01W
Smart-Play Smartphone Connectivity Interface for
Audi Vehicles with Concert / Symphony Non MMI Radios
R
INTERFACING SOLUTIONS
NOTES:
on the steering wheel controls
or part will NOT
function.
ACPAD-01W ModulePower/Video HarnessLVDS In/Out Cable
Touch Panel 6.5 inches included
Smart-Play Interface Module
* = Please measure your infotainment display
to match CRUX touch panel.
Email [email protected]
with issues.
**= Please make sure AMI port or 3.5 mm AUX port is
present in vehicle
Microphone
OSD Controller
4K HDMI Cable
Smart-Play Module Power Harness
PARTS INCLUDED:
Vehicle MUST have the MMI
controls on the radio.
rev.0908211 of 12
AMI to 3.5mm Aux Adapter Cable**
(Optional, sold seperately)*
NOTE: Vehicle must have AUX Input port or AMI port
