1A. Option 1. Clamp Mount Installation1B. Option 2. Grommet Mount Installation

2. Mounting Arm to Pole3. Mounting Laptop Holder to VESA Plate

Adjusting Arm

INSTALLATION:

5A. Find the integral USB cable below.5B. Plug into your laptop for power.

4A. Extend

the holder

brackets.

5. Powering Up Cooling Fan4. How to Setup your Holder

4C. Once

laptop is

securely in

place,

tighten four

knobs as

shown until

securily

fastened.

Cable RoutingAdjusting Tilt

4B. Adjust

the holder

to your

laptop by

sliding the

brackets

towards it.

**Laptop only

shown for

illustration

purposes, not

included.

T

B

x1

x1

K

x1

L

x3

M6x16

M

x3

M6x12

N

x2

M6x10

O

x4

P

x1

Q

x1

4mm

R

x1

5mm

S

x1

U

x4

V

x4

C

DEF

G

HIJ

x1

x1x1x1

x1

x1x1x1

A

x1

CONTENTS:

Articulating Desk Mount Clamp for Laptops with Built-In Cooling Fan

LT-DMCGCF

INSTALLATION - MANUAL

1AA. Rotate in the (3) screws (L) through the base (C) and pole (B)

using the allen key tool (Q). Then, rotate in the (3) screws (M)

through the component (D) and base (C). At last, adhere the (4)

rubber pads (O) to the base (C) as shown by removing the covers.

1AB. If clamping to a 10-55mm surface, rotate in the (2) screws (N)

in the top holes of component (D) using the allen key tool (Q). If

clamping to a 50-85mm surface, rotate in the (2) screws (N) in the

bottom holes of component (D) using the allen key tool (Q). At last,

attach the tool holder (F) to component (E) from the back to cover

the holes as shown above.

1BA. Rotate in the (3) screws (M) through the grommet component

(H) and base (C) using the allen key tool (Q). Then, adhere the (4)

rubber pads (O) to the base (C) as shown by removing the covers.

3A. Insert component (P) and (A) through the pole (B). Once in the

desired position, rotate the hex screw on component (A) base using

the included allen key tool (R) until securely tightened.

1BB. Use a pre-dilled surface or drill a hole on the surface as shown

above. Insert the grommet component (H) inside the hole. Then,

insert through the rod the component (I), then the washer (K) and at

last the hex nut (J), and use the included wrench (S) to securely

tighten the assembly to the desired surface.

3B. Install the laptop holder (T) to VESA plate (A) by aligning the

holes and rotating in the provided screws (U) using the included

allen key tool (H) as shown above.

U

T

A

Using the

provided

clips, route

the wire from

your device

to the power

source as

illustrated to

the left.

Adjust to the

desired angle,

then tighten the

screws using

the allen key

(R) as shown,

alternating from

each screw as

you tighten

them.
