DTQ 13P2FC
DTQ 19P2FC
DTQ 13P3FC
DTQ 19P3FC
INSTRUCTION MANUAL
Color Television
CAUTION
RISK OF ELECTRIC SHOCK
DO NOT OPEN
CAUTION : TO REDUCE THE RISK OF ELECTRIC SHOCK,
DO NOT REMOVE COVER ( OR BACK)
NO USER-SERVICEABLE PARTS I NSI DE.
REFER SERVI CING TO QUALIFIED SERVICE PERSONNEL.
The lightning flash with arrowhead symbol, within an equilateral triangle, is
intended to alert the user to the presence of uninsulated “dangerous voltage”
within the product’s enclosure that may be of sufficient magnitude to consti-
tute a risk electric shock.
The exclamation point within an equilateral triangle is intended to alert the
user to the presence of important operating and servicing instructions in the
literature accompanying the appliance.
WARNING
TO PREVENT FIRE OR SHOCK HAZARD, DO NOT EXPOSE THIS APPLIANCE TO RAIN
OR MOISTURE.
CAUTION
CHANGES OR MODIFICATIONS NOT EXPRESSLY APPROVED BY THE MANUFAC-
TURER COULD VOID THE USER’S AUTHORITY TO OPERATE THE EQUIPMENT.
NOTE TO CATV SYSTEM INSTALLER
THIS REMINDER IS PROVIDED TO CALL THE CATV SYSTEM INSTALLER'S ATTEN-
TION TO ARTICLE 820-40 OF THE NEC THAT PROVIDES GUIDELINES FOR PROPER
GROUNDING AND, IN PARTICULAR, SPECIFIES THAT THE CABLE GROUND SHALL
BE CONNECTED TO THE GROUNDING SYSTEM OF THE BUILDING, AS CLOSE TO
THE POINT OF CABLE ENTRY AS PRACTICAL.
CAUTION
The AC power cord provided with this product is polarized (one blade wider than the other).
To provide power to the TV, insert the AC plug into a standard 120V 60Hz polarized outlet.
NOTE
Never connect the plug to an electrical source other than one providing 120V 60Hz power. Use
only the attached power cord. If the polarized AC cord does not fit into a non-polarized outlet,
do not cut or file the blade. You are responsible for having the obsolete outlet replaced with a
polarized outlet.
If you feel a static discharge when touching the unit, and the unit does not function, simply
unplug the unit from the outlet. When you plug the unit back in, it should work normally.
Do not install power cords near any heating element or cooking appliances.
Daewoo Electronics
Corporation of America
120 Chubb Avenue,
Lyndhurst, NJ 07071
1-800-DAEWOO8 (1-800-323-9668)
Fax:201-935-5284
Dear Customer :
Daewoo Electronics Corporation of America would like to thank you for choosing this color
television receiver. It incorporates a host of features designed to give you excellent perfor-
mance for many years to come.
We realize that you’re eager to turn it on and begin enjoying the high-quality pictures it deliv-
ers just as quickly as possible, but we ask you to take a few minutes to read the instructions
in the booklet to familiarize yourself with the receiver, its functions and some features which
may be new to you. If you follow the instructions, this unit should give you many years of
viewing pleasure.
If for any reason it does not, we want to hear about it. Please write to us at the address
above. Daewoo always welcomes comments and suggestions on this or any of our other prod-
ucts.
On the other hand, when you discover the enjoyment, reliability and ease of use that is built
into it, we hope that you will tell your friends, and consider Daewoo when you make your next
purchase of home entertainment equipment.
In addition to TV receivers, Daewoo produces a full line of audiovisual products built to the
same high design, engineering, and manufacturing standards as this unit.
Here are a few tips that will keep your TV receiver looking great and performing for years to
come.
• Avoid putting it in excessively hot locations. Damage to the cabinet or premature compo-
nent failures can result.
• There are ventilation holes in the bottom and rear of the cabinet. Make sure that they
remain unobstructed. Do not place the receiver on top of a thick cloth.
• If you don’t plan to use the receiver for several days, it’s a good idea to unplug it from the
power outlet.
• Many common household cleaning agents, sprays, solvents, and polishes will cause perma-
nent damage to the surface of the cabinet. The best cleaning agents are mild soap and a
damp cloth.
Again, thank you for choosing this Daewoo product. We have employed advanced engineering
techniques in its design, and manufactured it in one of the world’s most up-to-date production
facilities. The result is a TV receiver that we know you will be as proud to own as we were to
create.
Very truly yours,
DAEWOO ELECTRONICS
CORPORATION OF AMERICA
CONTENTS
1
Table of Contents
Table of Contents
Important Safeguards 2
Chapter 1: Overview of Your Equipment 4
Your TV's Front Panel 4
Your TV's Back Panel 4
Your Remote Control 5
Installing your remote control batteries 6
Notes 6
Chapter 2: Connecting an Antenna or Cable to Your TV 7
Connecting an Antenna 7
Connecting a Cable System 8
Connecting Other Pieces of Equipment 9
Safety Note 9
Chapter 3: Operating Your TV 10
Turning your TV On 10
Programming Your TV's Channel Memory 10
Changing Channels 11
Changing the Volume 11
Changing The TV's Channel Memory 12
Adding/Deleting a channel to memory 12
Displaying the Current Channel 12
Adjusting Video Settings 13
Returning to the factory settings 14
Descriptions of video settings 14
Chapter 4: Using Timer Functions 15
Setting the Clock 15
Setting the Wake-up Timer 15
Setting the Off Timer 16
Canceling the Wake-up Timer or Off Timer 16
Setting the Sleep Timer 17
Chapter 5 : Additional Features 18
Changing the Language of the On-Screen Menus 18
Captioning 18
CC on Mute 19
Power Restore 19
Auto Tint(option) 20
Chapter 6 : Troubleshooting 21
Warranty 22
2
Important Safeguards
S A F E T Y
IMPORTANT SAFEGUARDS
PLEASE READ ALL THESE INSTRUCTIONS REGARDING YOUR TELEVISION
EQUIPMENT AND RETAIN FOR FUTURE REFERENCE. FOLLOW ALL WARNINGS
AND INSTRUCTIONS MARKED ON THE TV RECEIVER.
1
Read all of these instructions.
2
Save these instructions for later use.
3
Unplug this television equipment from
the wall outlet before cleaning. Do not
use liquid cleaners or aerosol cleaners.
Use a damp cloth for cleaning.
4
Do not use attachments not recommend-
ed by the television equipment manufac-
turer as they may result in the risk of
fire, electric shock or other personal
injury.
5
Do not use this television equipment
near water, for example, near a bathtub,
washbowl, kitchen sink, or laundry tub,
in a wet basement, or near a swimming
pool, or the like.
6
Do not place this television equipment on
an unstable cart, stand, or table. The
television equipment may fall, causing
serious injury to a child or adult, and
serious damage to the equipment. Use
only with a cart or stand recommended
by the manufacturer, or sold with the
television equipment. Wall or shelf
mounting should follow the manufactur-
er's instructions, and should use a
mounting kit approved by the manufac-
turer.
6A
An appliance and cart combination
should be moved with care. Quick stops,
excessive force, and uneven surfaces may
cause the appliance and cart combina-
tion to overturn.
7
Slots and openings in the cabinet and
the back or bottom are provided for ven-
tilation and to ensure reliable operation
of the television equipment; and to pro-
tect it from overheating, these opening,
must not be blocked or covered. The
opening should never be blocked by plac-
ing the television equipment on a bed,
sofa, rug, or other similar surface. (This
equipment should never be placed near
or over a radiator or heat register.) This
television equipment should not be
placed in a built-in installation such as a
bookcase unless proper ventilation is
provided.
8
This television equipment should be
operated only from the type of power
source indicated on the marking label. If
you are not sure of the type of power
supplied to your home, consult your tele-
vision dealer or local power company.
9
This television equipment is equipped
with a polarized alternating current line
plug (a plug having one blade wider than
the other). This plug will fit into the
power outlet only one way. This is a
safety feature. If you are unable to insert
the plug fully into the outlet, try revers-
ing the plug. If the plug should still fail
to fit, contact your electrician to replace
your obsolete outlet. Do not defeat the
safety purpose of the polarized plug.
10
Do not allow anything to rest on the
power cord. Do not locate this television
equipment where the cord will be abused
by persons walking on it.
11
Follow all warnings and instructions
marked on the television equipment.
12
For added protection for this television
equipment during a lightning storm, or
when it is left unattended and unused
for long periods of time, unplug it from
the wall outlet and disconnect the anten-
na or cable system. This will prevent
damage to the equipment due to light-
ning and power-line surges.
3
Important Safeguards
13
An outside antenna system should not
be located in the vicinity of overhead
power lines or other electric light or
power circuits, or where it can fall into
such power lines or circuits. When
installing an outside antenna system,
extreme care should be taken to keep
from touching such power lines or cir-
cuits as contact with them might be
fatal.
14
Do not overload wall outlets and exten-
sion cords as this can result in fire or
electric shock.
15
Never push objects of any kind into this
television equipment through openings
as they may touch dangerous voltage
points or short-out parts that could
result in a fire or electric shock. Never
spill liquid of any kind on the television
equipment.
16
Do not attempt to service this television
equipment yourself as opening or remov-
ing covers may expose you to dangerous
voltage or other hazards. Refer all servic-
ing to qualified service personnel.
17
Unplug this television equipment from
the wall outlet and refer servicing to
qualified service personnel under the fol-
lowing conditions:
(a) When the power-supply cord or plug
is damaged or frayed.
(b) If liquid has been spilled, or objects
have fallen into the television equip-
ment.
(c) If the television equipment has been
exposed to rain or water.
(d) If the television equipment does not
operate normally by following the
operating instructions. Adjust only
those controls that are covered by the
operating instructions as an improper
adjustment of other controls may
result in damage and will often
require extensive work by a qualified
technician to restore the TV receiver
to its normal operation.
(e) If the television equipment has been
dropped or the cabinet has been dam-
aged.
(f) When the television equipment
exhibits a distinct change in perfor-
mance - this indicates a need for ser-
vice.
18
When replacement parts are required, be
sure the service technician has used
replacement parts specified by the man-
ufacturer that have the same charact-
eristics as the original part. Unauthorized
substitutions may result in fire, electric
shock or other hazards.
19
Upon completion of any service or repairs
to this television equipment, ask the ser-
vice technician to perform safety checks
to determine that the television is in a
safe operating condition.
20
If an outside antenna or cable system is
connected to the television receiver, be
sure the antenna or cable system is
grounded so as to provided some protec-
tion against voltage surges and built-up
static charges.
Section 810 of the National Electrical
Code, ANSI/NFPA N0.70-1984, pro-
vides information with respect to proper
grounding of the mast and supporting
structure, grounding of the lead-in wire
to an antenna discharge unit, size of
grounding conductors, location of anten-
na-discharge unit, connection to ground-
ing electrodes, and requirements for the
grounding electrode.
4
Chapter 1 :
Overview of Your Equipment
C H A P T E R
1
Overview of Your Equipment
Your TV comes with a remote control. The section below summarizes the buttons,
controls, and terminals that you will use with your TV.
Your TV's Front Panel
1 POWER
Use this button to turn your TV on or off.
2 CH▼ ▲
Use these buttons to change channels on your TV, or to select items in the menu
system.
3 VOLC B
Use these buttons to change your TV's volume, to activate selections in the menu
system, or to change audio and video settings.
4 MENU
Use this button to turn the TV's menu system on and off.
5 Remote control receiver
This receiver receives a signal from your remote control. Do not block it.
Your TV's Back Panel
1 Antenna terminal
Use this terminal to attach an antenna or cable
system to your TV.
5
Chapter 1 :
Overview of Your Equipment
Your Remote Control
1. POWER
Use this button to turn your TV on or off.
2. MUTE
Use to turn the TV’s sound on and off.
3. ▼CH▲
Use these buttons to change channels on your TV, or select
items in the menu system.
4. CVOLB
Use these buttons to change your TV's volume, to activate
selections in the menu system, or to change audio and video
settings.
5. MENU
Use this button to turn the TV's menu system on and off.
6. DISPLAY
Use this button to display the channel
number and status.
7. INPUT
Use this button to select the TV’s signal source.
8. VIDEO
Use this button to display video adjustment
items.
9. 0-9
Use these buttons to change channels.
10. SLEEP
Use this button to program the TV to turn off after a certain
time.
11. PREVIOUS
Use this button to return to the previous channel you were
watching.
MUTE POWER
C H
C H
VOL
MENU
DISPLAY
1
2
3
4
3
6
9
10
1
4
5
8
7
11
2 3
456
7 8
0
9
SLEEP PREVIOUS
R-38T01
INPUT VIDEO
VOL
6
Chapter 1 :
Overview of Your Equipment
Installing your remote control batteries
1
Open the battery compartment on the back of the remote control.
2
Install two AAA-size batteries (not included) as shown. Make sure the “+” and “-”
terminals are oriented correctly.
3
Replace the cover.
Notes
Do not mix different types of batteries, or mix an old and a new battery.
Remove and replace weak batteries. Weak batteries can leak and damage your con-
troller. Dispose of batteries properly; never throw them into a fire.
Point your remote at the receiver on the center of the front of the TV. Make sure the
receiver is not blocked.
The remote control can operate up to 30 feet away from the TV, if you are directly
facing the front of the TV. Operating distance diminishes as you move to the sides of
the TV.
8
Chapter 2 :
Connecting an Antenna or Cable to Your TV
Antennas with two sets of leads
You might have two sets of leads from your antenna system, especially if you have
one antenna for VHF signals and one antenna for UHF signals.
If your antenna system has both a coaxial lead and twin 300-ohm leads,
you must obtain a combiner (available at your local electronics store). Press or screw
the coaxial lead onto the combiner; place the twin leads underneath the screws on the
combiner and tighten the screws. Press the cable from combiner onto the antenna ter-
minal on the back of your TV.
If your antenna system has two sets of twin 300-ohm leads,
you
must obtain a combiner (available at your local electronics store). Place one set of
twin leads underneath the screws on the combiner and tighten the screws. Do the
same with the other set of twin leads. Press the cable from the combiner onto antenna
terminal on the back of your TV.
Connecting a cable system
If your cable set-up is not described below, please contact your cable company for
more information.
If your cable system does not
require the use of a cable box,
simply
press or screw the incoming cable onto the
antenna terminal on the back your TV.
11
Chapter 3:
Operating Your TV
Changing Channels
You can change channels in three ways:
1
The CH buttons will take you through all memorized▲ ▼
channels, one by one. The CH buttons will not access▲ ▼
channels that have not been programmed into the TV's
memory. For more information about programming chan-
nels into memory, see the section “Programming your TV's
Channel Memory” on the previous page.
2
The number buttons (0-9) will take you to any channel,
even if it has not been memorized. To change to a channel,
enter its number; the TV will tune to the new channel
when you enter the second digit of the channel.
3
The PREVIOUS button will take you instantly to the last
channel you were watching.
Changing the Volume
1
To change the volume of the TV set, use the VOL but-C B
tons on the remote or on the front panel.
2
To quickly turn off the sound, press the MUTE button on
the remote. The ‘MUTE’ will appear on screen, colored
green. To return the volume to its previous level, press
MUTE again.
1
2
3
1
2
14
Chapter 3:
Operating Your TV
Returning to the factory settings
If you would like to return to the original video settings, as they were calibrated at the
factory, follow these steps :
1
With the TV on, press the MENU button. then “Video” menu will appear.
2
Press the buttons to set the “Settings” to ‘Preset’.CVOLB
The TV will remember the ‘Custom’ settings you had previously chosen. When you
set “Settings” to ‘Custom’ again, your previous custom settings will be restored.
Descriptions of video settings
The contrast setting controls the relation between the light and black areas of the
screen. If the light areas are too bright and are losing details, press the VOL but-C
ton; if the picture is gray and lacks contrast, press the VOL button.B
The brightness settings controls the overall amount of light in the picture. If the pic-
ture is too bright, press the VOL button; if the picture is too dark, press the VOLC
Bbutton.
Sharpness controls how the TV displays edges of objects on-screen. If the TV shows
multiple vertical lines at the edges of an object, press the VOL button; if the verti-C
cal edges of on-screen objects are fuzzy, press the VOL button.B
The color setting controls the intensity of color. If the color is over-saturated, press the
VOL button; if the color is washed out, press the VOL button.B B
The tint setting controls the relationship of red and green in a picture. Tint is espe-
cially noticeable in flesh tones. If flesh tones seem too red or purple, press the VOLB
button; if flesh tones are too green, press the VOL button.B
Select
Video
Settings : Custom
Contrast :
Brightness
Sharpness
Color
Tint
Adjust Next
1
Select
Video
Settings : Preset
Contrast :
Brightness
Sharpness
Color
Tint
Adjust Next
2
16
Chapter 4:
Using Timer Functions
Setting the Off Timer
If you enter a time in the “Off time” setting, your TV will automatically turn off at
that time. Follow these instructions to set the “Off time”.
1
With the TV turned on, press the MENU button until “Time” menu will be dis-
played.
2
Use the CH buttons to select “Off time” item.▲ ▼
3
If you hold down either VOL or VOL button, the corresponding numbers willC B
change more quickly.
4
When the setting is correct, use the CH buttons to select another “Time” func-▲ ▼
tion, or press the MENU button until menu OSD will be disappeared.
Canceling the Wake-up Timer or Off Timer
If you would like to cancel the Wake-up Timer or the Off Timer, Press the VOLC B
buttons until the timer settings return to “- -:- -”.
The Wake-up Timer and Off Timer will not function correctly unless the clock has
been set.
Select
Time
Set Clock : 12 : 00 AM
Wake-up time : 06 : 30 AM
Off time : :
Sleep timer : 0 min
Adjust Next
1
Select
Time
Set Clock : 1 2 : 00 AM
Wake-up time : 06 : 30 AM
Off time : 1 1 : 30 PM
Sleep timer : 0 min
Adjust Next
3
Select
Time
Set Clock : 1 2 : 00 AM
Wake-up time : 06 : 30 AM
Off time : :
Sleep timer : 0 min
Adjust Next
2
20
Chapter 5 :
Additional Features
Auto Tint(option)
This is function for fresh tone compensation.
1
With the TV turned on, press the MENU button until “Special” menu will be dis-
played.
2
Use the CH buttons to select “Auto Tint” item.▲ ▼
3
Use the VOL buttons to select “On” or “Off”.C B
Select
Special
Closed Caption : C 1
CC on Mute : C 1
Power Restore : On
Auto Tint : OFF
Adjust Exit
1
Select
Special
Closed Caption : C 1
OC on Mute : C 1
Power Restore : On
Auto Tint : On
Adjust Exit
3
Select
Special
Closed Caption : C 1
OC on Mute : C 1
Power Restore : On
Auto Tint : OFF
Adjust Exit
2
This instrument is listed by Underwriter’s
Laboratories, Inc. It is designed and
manufactured to meet rigid U.L. safety
standards against X-radiation, fire, casualty
and electrical hazards.
Daewoo Electronics Corporation of America
120 Chubb Avenue
Lyndhurst, NJ 07071
For more information about this or other Daewoo products, please call 1-800-DAEWOO8.
Produktspecifikationer
| Varumärke: | Daewoo |
| Kategori: | TV-apparater |
| Modell: | DTQ-13P2FC |
Behöver du hjälp?
Om du behöver hjälp med Daewoo DTQ-13P2FC ställ en fråga nedan och andra användare kommer att svara dig
TV-apparater Daewoo Manualer
14 Oktober 2024
11 Oktober 2024
29 Juli 2024
28 Juli 2024
28 Juli 2024
TV-apparater Manualer
- Hitachi
- JVC
- Panasonic
- Mitsubishi
- Samsung
- Sylvania
- Sanyo
- Akai
- Aiwa
- Sony
- Clatronic
- Sharp
- Funai
- EKO
- Philips
Nyaste TV-apparater Manualer
21 Oktober 2024
21 Oktober 2024
19 Oktober 2024
18 Oktober 2024
18 Oktober 2024
18 Oktober 2024
17 Oktober 2024
17 Oktober 2024
17 Oktober 2024
16 Oktober 2024
