D A L I O P T I C O N
M A N U A L
ENGLISH - DEutScH - DANSK - - - frANçAIS中国 日本語

FIGURE 1A FIGURE 1B FIGURE 1C
TABLE 1

FIGURE 3 FIGURE 4FIGURE 2
FIGURE 6FIGURE 5
FIGURE 7
4 x spad
62,3
340,0
79,7
Recommend
min.100mm

5
UK DE DK CN JP FR
CONTENTS
1.0 INTRODUCTION 6
2.0 UNPACKING 6
3.0 POSITIONING 6
4.0 CONNECTION 8
5.0 RUNNING-IN 8
6.0 CLEANING & MAINTENANCE 9
7.0 DISPOSAL 9
8.0 POWER AND ACOUSTIC PRESSURE 9
9.0 THE LISTENING ROOM 10
10.0 TECHNICAL SPECIFICATIONS 10

7
UK DE DK CN JP FR
NOTE: On some floor surfaces and in some rooms, the use of spikes is a crucial aspect in
obtaining the best result. The spikes (included) should be fastened loosely in the four aluminium
feet, leaving the spike’s nut only slightly tightened. Using the screws, mount the feet in the
threaded holes on the bottom of the speaker. Push the feet against the cabinet before tightening
the screws. Place the loudspeaker upright on its spikes on the floor, so that it stands steadily
without rocking. Tighten the nuts, so that the four spikes sit tightly in the aluminium feet.
These assembly and setup steps ensure stable mechanical coupling to the surface beneath
(see Figure 3).
3.2 DALI OPTICON 2
DALI OPTICON 2 is optimized for stand mounting, but will also work well on a shelf. If positioned
on a stand or shelf, the enclosed bumpers can be placed under the speaker for stable and
vibration-free positioning (see Figure 4).
3.3 DALI OPTICON 1
There are several placement options for DALI OPTICON 1; on a stand, on a shelf, on a table-top
or wall-mounting. For wall-mounting DALI OPTICON, you must use the included wall bracket.
Before mounting the speaker on the wall, position the special bumpers - enclosed in the wall
bracket packaging - on the bottom rear edge of the speaker (See figure 5). These bumpers
ensure the correct distance from the wall and ensure secure mounting. If positioned on a stand
or shelf, the enclosed bumpers can be placed under the speaker for stable and vibration-free
positioning (see figure 4).
3.4 DALI OPTICON VOKAL
DALI OPTICON VOKAL is the dedicated centre channel and has been specially designed to be
positioned close to the large surface of the TV screen. You can place it above or below the
screen, on a stand or on a shelf. We recommend fitting the enclosed bumpers to ensure a
stable, vibration free setup (see figure 6).
3.5 DALI OPTICON LCR
DALI OPTICON LCR is optimized for wall-mounting (see Figure 7), but can be used on a shelf
or TV furniture.
DALI OPTICON LCR can be used as a left, right or centre speaker. If used in the horizontal
position the hybrid tweeter module should be rotated so it stays vertical, which is important to
preserve the wide dispersion and fine detail of the high frequencies. If used in the horizontal
position, you can rotate the DALI logo on the front grille by lifting it up slightly and rotating it into
the desired position (see Figure 8).
The ribbon tweeters are pre-configured for vertical positioning in the factory and if the speaker
is used in the horizontal position, your authorized dealer or service facility can rotate the ribbon
tweeter for you. To remove the ribbon tweeter from the cabinet, use a 3 mm Allen key (not
included) to remove the four screws. When disassembled, rotate the ribbon tweeter 90 degrees.
Insert the rotated ribbon tweeter and install it, using the four screws (Figure 9). Be careful not
to over tighten the screws when assembling the speaker again.
If positioned on a shelf or TV furniture, the enclosed bumpers can be placed under the speaker
(in both the vertical or horizontal position) for stable and vibration-free positioning
(see Figure 4).

10
9.0 THE LISTENING ROOM
Every room has its own distinctive acoustics, which influence the way we experience sound
from a speaker. The sound you hear consists of direct sound from the speakers and reflected
sound from the floor, ceiling and walls. The latter will affect how you experience the sound.
As a basic rule, try to avoid large, hard and reflective areas in the immediate vicinity of your
loudspeakers as it will typically cause strong reflections, which might disturb the precision and
spatial effect of the sound reproduction. Reflection might be suppressed by positioning e.g. a
plant between the speaker and the reflecting surface. Soft items such as carpets, curtains etc.
might help if the sound is too bright. Both the amount and quality of the deep bass depend on
the size and shape of the room, and the position of the speakers. Positioning the speakers near
a side or back wall will accentuate the bass. A corner location will accentuate it even more, but
will also increase the reflections.
10.0 TECHNICAL SPECIFICATIONS
In Table 2 you will find the most common specifications for our speakers. Please have in mind
that there are countless methods for measuring speakers. However, none of them tell you
anything useful about how a speaker really sounds. Only your ears can decide whether one
speaker sounds better than another. Like all our speakers, DALI OPTICON series is designed to
reproduce music as honestly as possible.
Enjoy your new DALI OPTICON!
