OWNER’S M ANUAL
The Alpha·Omega 900 takes the best elements of our most successful distortion
preamplifier ever, combined with state-of-the-art features to make a monstrous 900-watt
amplifier with earth-shattering tone.
While our signature Alpha and Omega drive engines and incredible girth and size to the
overdriven signal, the studio-grade VCA compressor adds an extra layer of control, and the
ultra-quiet 6-band graphic equalizer can help sculpt the tone in any way necessary, as
well as providing a wide variety crystal clear clean sounds.
But that is not everything: the MIDI programmability and impulse response cabinet
simulation with up to three different storable virtual cabinets make the AO900 not only
one of the most complete amplifiers for the touring musician but, combined with the
auxiliary input and headphone output, the ideal tool for silent practicing. OR but also the
ideal tool for silent practicing, when combined with the
auxiliary input and headphone output.
The Alpha·Omega 900 amplifies the best qualities of one of the most powerful and
distinct Darkglass pedals ever made.
The Alpha·Omega 900™ is a 900W amplifier equipped
with an all-analog preamplifier, Class D Power Module
and a digital impulse based cabinet emulator for DI
outputs or headphones. Probably the first thing you
will notice from the Alpha·Omega 900 is its unusual
control layout: On the right side you’ll find the clean
section which is the foundation of your sound.
It features Gain and Master volumes and active 6 band
graphic EQ. Along with the mandatory Low and Treble
controls you will find 250Hz, 500Hz, 1.5KHz, 3KHz
sliders. Character is all in the midrange. Having 4
dedicated Mid controls allows you to cover the whole
mid range (250Hz to 3kHz) to have total control and
flexibility over the amplifier’s character.
On the left side, by the input jack you will find the
Alpha·Omega Engine which acts as an extra channel.
This creation differs greatly from our previous
preamplifiers and overdrives: its operational-amplifier
topology featuring two distinct distortion circuits
(Alpha and Omega), which can be selected or blended
using our Mod knob, make the Alpha · Omega the most
flexible among our designs.
DESCRIPTION
The Alpha·Omega Engine™ can be engaged via the
front panel or via our own digitally controlled ™ (jack
on rear panel). Besides engaging the Alpha·Omega
circuitry you can hold the actuator to Mute the
amplifier.
The Intelligent Footswitch is housed in an elegant,
laser-engraved unibody chassis and requires a
standard ¼” mono cable (not included) for it’s full
operation.
Besides this incredibly versatile preamplifier, we
equipped the power module with some unique control
over the power output and minimum speaker loads:
The standard mode will deliver 900W RMS at 4Ω/500W
at 8 . If you select the 2 Mode via the rear-panel Ω Ω
switch the amplifier will deliver 900W at 2 /500W at 4Ω Ω
and 350W at 8Ω.
This deceivingly simple feature allows for maximum
power adaptability: Regardless of the cabinet
configuration or power requirements, the Alpha· Omega
900 will deliver accordingly.
