QuickScan™ I QD24XX

Product Reference Guide

General Purpose Handheld

Area Imager Bar Code Reader

Datalogic ADC, Inc.

959 Terry Street

Eugene, OR 97402

USA

Telephone: (541) 683-5700

Fax: (541) 345-7140

procedures described therein may be reproduced or transmitted in any form or by any means

without prior written permission of Datalogic ADC, Inc. or its subsidiaries or affiliates ("Datalogic"

or “Datalogic ADC”). Owners of Datalogic products are hereby granted a non-exclusive, revocable

license to reproduce and transmit this documentation for the purchaser's own internal business

purposes. Purchaser shall not remove or alter any proprietary notices, including copyright

notices, contained in this documentation and shall ensure that all notices appear on any repro-

ductions of the documentation.

Should future revisions of this manual be published, you can acquire printed versions by contact-

ing your Datalogic representative. Electronic versions may either be downloadable from the Dat-

alogic website (www.datalogic.com) or provided on appropriate media. If you visit our website

and would like to make comments or suggestions about this or other Datalogic publications,

please let us know via the "Contact Datalogic" page.

Disclaimer

Datalogic has taken reasonable measures to provide information in this manual that is complete

and accurate, however, Datalogic reserves the right to change any specification at any time with-

out prior notice.

Datalogic and the Datalogic logo are registered trademarks of Datalogic S.p.A. in many countries,

including the U.S.A. and the E.U. All other brand and product names may be trademarks of their

respective owners.

Patents

This product may be covered by one or more of the following patents:

EP996284; EP997760; EP999514; EP1128315; EP1396811; EP1413971; EP1828957; JP4435343B2;

US5481098; US6478224; US6512218; US6513714; US6561427; US6808114; US6997385;

US7053954; US7075663; US7234641; US7387246; US7721966.

Additional patents pending.

Product Reference Guide 1

Table of Contents

INTRODUCTION ................................................................................................................................................................................ 1

About this Manual .......................................................................................................................................................................................... 1

Overview .................................................................................................................................................................................................................................................... 1

Manual Conventions ............................................................................................................................................................................................................................. 2

Technical Support .......................................................................................................................................................................................... 2

Datalogic Website Support ................................................................................................................................................................................................................. 2

Reseller Technical Support .................................................................................................................................................................................................................. 2

Telephone Technical Support ............................................................................................................................................................................................................ 2

About the Reader ........................................................................................................................................................................................... 3

Programming the Reader .............................................................................................................................................................................. 4

Configuration Methods ........................................................................................................................................................................................................................ 4

SETUP ................................................................................................................................................................................................ 5

Unpacking ....................................................................................................................................................................................................... 5

Setting Up the Reader .................................................................................................................................................................................... 5

Installing the Interface Cable ........................................................................................................................................................................ 6

Interface Selection ......................................................................................................................................................................................... 8

Setting the Interface .............................................................................................................................................................................................................................. 9

Customizing Configuration Settings .......................................................................................................................................................... 12

Configure Interface Settings ............................................................................................................................................................................................................12

Global Interface Features ...................................................................................................................................................................................................................12

Configuring Other Features ..............................................................................................................................................................................................................12

Software Version Transmission .......................................................................................................................................................................................................12

Resetting the Product Configuration to Defaults .....................................................................................................................................................................13

CONFIGURATION USING BAR CODES............................................................................................................................................ 15

Configuration Parameters .................................................................................................................................................................................................................15

GLOBAL INTERFACE FEATURES .................................................................................................................................................. 17

Host Commands — Obey/Ignore .............................................................................................................................................................................17

USB Suspend Mode ........................................................................................................................................................................................................17

RS-232 Interface...................................................................................................................................................................... 19

Baud Rate ...........................................................................................................................................................................................................................20

Data Bits .............................................................................................................................................................................................................................21

Stop Bits ..............................................................................................................................................................................................................................21

Parity ....................................................................................................................................................................................................................................22

Handshaking Control ....................................................................................................................................................................................................23

RS-232/USB-Com Interfaces................................................................................................................................................... 24

Intercharacter Delay .......................................................................................................................................................................................................25

Beep On ASCII BEL ..........................................................................................................................................................................................................25

Beep On Not on File .......................................................................................................................................................................................................26

ACK NAK Options ............................................................................................................................................................................................................27

ACK Character ..................................................................................................................................................................................................................28

NAK Character ..................................................................................................................................................................................................................28

ACK NAK Timeout Value ...............................................................................................................................................................................................29

ACK NAK Retry Count ....................................................................................................................................................................................................29

ACK NAK Error Handling ...............................................................................................................................................................................................30

Indicate Transmission Failure .....................................................................................................................................................................................30

Disable Character ............................................................................................................................................................................................................31

Enable Character .............................................................................................................................................................................................................31

Keyboard Settings .................................................................................................................................................................. 33

Country Mode ..................................................................................................................................................................................................................34

Send Control Characters ..............................................................................................................................................................................................38

Wedge Quiet Interval ....................................................................................................................................................................................................39

Intercode Delay ...............................................................................................................................................................................................................39

Caps Lock State ................................................................................................................................................................................................................40

Numlock .............................................................................................................................................................................................................................40

Contents

2QuickScan™ I QD24XX

USB Keyboard Speed .....................................................................................................................................................................................................41

USB Keyboard Numeric Keypad ................................................................................................................................................................................42

USB-OEM Interface ................................................................................................................................................................. 43

USB-OEM Device Usage ................................................................................................................................................................................................44

USB Interface Options ...................................................................................................................................................................................................44

Transmit Labels in Code 39 Format ..........................................................................................................................................................................45

Interface Options ............................................................................................................................................................................................................46

Data Format ............................................................................................................................................................................ 47

Global Prefix/Suffix ...................................................................................................................................................................................... 48

Global AIM ID ................................................................................................................................................................................................ 49

Set AIM ID Individually for GS1-128 ...............................................................................................................................................................................................51

Label ID .......................................................................................................................................................................................................... 52

Label ID: Pre-Loaded Sets ..................................................................................................................................................................................................................52

Individually Set Label ID .....................................................................................................................................................................................................................53

Label ID Control ...............................................................................................................................................................................................................53

Label ID Symbology Selection − 1D Symbologies ..............................................................................................................................................54

Advanced Formatting: User Label Edit ...................................................................................................................................................................59

Case Conversion ..............................................................................................................................................................................................................59

Character Conversion ....................................................................................................................................................................................................60

Reading Parameters ............................................................................................................................................................. 61

Double Read Timeout ...................................................................................................................................................................................................62

LED AND BEEPER INDICATORS ................................................................................................................................................... 64

Power On Alert .................................................................................................................................................................................................................64

Good Read: When to Indicate .....................................................................................................................................................................................64

Good Read Beep Type ...................................................................................................................................................................................................65

Good Read Beep Frequency .......................................................................................................................................................................................65

Good Read Beep Length ..............................................................................................................................................................................................66

Good Read Beep Volume .............................................................................................................................................................................................67

Good Read LED Duration .............................................................................................................................................................................................68

SCANNING FEATURES ................................................................................................................................................................. 69

Scan Mode .........................................................................................................................................................................................................................69

Stand Mode Indication ..................................................................................................................................................................................................70

Stand Operation ..............................................................................................................................................................................................................71

Pick Mode ..........................................................................................................................................................................................................................72

Stand Mode Sensitivity .................................................................................................................................................................................................72

Stand Mode Illumination Off Time ...........................................................................................................................................................................73

Scanning Active Time ....................................................................................................................................................................................................73

Stand Illumination Control ..........................................................................................................................................................................................74

Flash On Time ...................................................................................................................................................................................................................74

Flash Off Time ...................................................................................................................................................................................................................75

Aiming Pointer .................................................................................................................................................................................................................75

Aiming Duration Timer .................................................................................................................................................................................................76

Green Spot Duration ......................................................................................................................................................................................................77

Mobile Phone Mode ......................................................................................................................................................................................................77

Partial Label Reading Control .....................................................................................................................................................................................78

Decode Negative Image ...............................................................................................................................................................................................78

Image Capture .................................................................................................................................................................................................................78

MULTIPLE LABEL READING ......................................................................................................................................................... 79

Multiple Labels per Frame ...........................................................................................................................................................................................79

Multiple Labels Ordering by Code Symbology ....................................................................................................................................................80

Multiple Labels Ordering by Code Length ............................................................................................................................................................80

1D Symbologies...................................................................................................................................................................... 81

1D Code Selection ........................................................................................................................................................................................ 81

DISABLE ALL SYMBOLOGIES ...................................................................................................................................................... 82

CODE EAN/UPC ............................................................................................................................................................................ 83

Coupon Control ...............................................................................................................................................................................................................83

UPC-A ..................................................................................................................................................................................................................................84

UPC-A Enable/Disable ...................................................................................................................................................................................................84

UPC-A Check Character Transmission .....................................................................................................................................................................84

Expand UPC-A to EAN-13 .............................................................................................................................................................................................85

UPC-A Number System Character Transmission .................................................................................................................................................85

UPC-A 2D Component ..................................................................................................................................................................................................86

Contents

Product Reference Guide 3

UPC-E ............................................................................................................................................................................................ 86

UPC-E Enable/Disable ....................................................................................................................................................................................................86

UPC-E Check Character Transmission ......................................................................................................................................................................87

UPC-E 2D Component ...................................................................................................................................................................................................87

Expand UPC-E to EAN-13 .............................................................................................................................................................................................88

Expand UPC-E to UPC-A ...............................................................................................................................................................................................88

UPC-E Number System Character Transmission ..................................................................................................................................................89

GTIN FORMATTING ...................................................................................................................................................................... 89

EAN 13 (JAN 13) ........................................................................................................................................................................... 90

EAN 13 Enable/Disable .................................................................................................................................................................................................90

EAN 13 Check Character Transmission ...................................................................................................................................................................90

EAN-13 Flag 1 Character ...............................................................................................................................................................................................91

EAN-13 ISBN Conversion ..............................................................................................................................................................................................91

EAN-13 2D Component ................................................................................................................................................................................................92

ISSN .............................................................................................................................................................................................. 92

ISSN Enable/Disable .......................................................................................................................................................................................................92

EAN 8 (JAN 8) ............................................................................................................................................................................... 93

EAN 8 Enable/Disable ....................................................................................................................................................................................................93

EAN 8 Check Character Transmission ......................................................................................................................................................................93

Expand EAN 8 to EAN 13 ..............................................................................................................................................................................................94

EAN 8 2D Component ...................................................................................................................................................................................................94

UPC/EAN GLOBAL SETTINGS ...................................................................................................................................................... 95

UPC/EAN Price Weight Check .....................................................................................................................................................................................95

UPC/EAN Quiet Zones ...................................................................................................................................................................................................96

ADD-ONS ...................................................................................................................................................................................... 97

Optional Add-ons ...........................................................................................................................................................................................................97

Optional Add-On Timer ................................................................................................................................................................................................98

Optional GS1-128 Add-On Timer ........................................................................................................................................................................... 101

CODE 39 ......................................................................................................................................................................................104

Code 39 Enable/Disable ............................................................................................................................................................................................ 104

Code 39 Check Character Calculation .................................................................................................................................................................. 104

Code 39 Check Character Transmission .............................................................................................................................................................. 105

Code 39 Start/Stop Character Transmission ...................................................................................................................................................... 106

Code 39 Full ASCII ........................................................................................................................................................................................................ 106

Code 39 Quiet Zones .................................................................................................................................................................................................. 107

Code 39 Length Control ............................................................................................................................................................................................ 107

Code 39 Set Length 1 ................................................................................................................................................................................................. 108

Code 39 Set Length 2 ................................................................................................................................................................................................. 109

TRIOPTIC CODE ..........................................................................................................................................................................110

Trioptic Code Enable/Disable .................................................................................................................................................................................. 110

CODE 32 (ITAL PHARMACEUTICAL CODE) ...............................................................................................................................110

Code 32 Enable/Disable ............................................................................................................................................................................................ 110

Code 32 Feature Setting Exceptions ..................................................................................................................................................................... 111

Code 32 Check Char Transmission ........................................................................................................................................................................ 111

Code 32 Start/Stop Character Transmission ...................................................................................................................................................... 111

CODE 39 CIP (FRENCH PHARMACEUTICAL) .............................................................................................................................112

Code 39 CIP Enable/Disable ..................................................................................................................................................................................... 112

CODE 39 DANISH PPT ................................................................................................................................................................112

Code 39 Danish PPT Enable/Disable ..................................................................................................................................................................... 112

CODE 39 LAPOSTE .....................................................................................................................................................................113

Code 39 LaPoste Enable/Disable ............................................................................................................................................................................ 113

CODE 39 PZN ..............................................................................................................................................................................113

Code 39 PZN Enable/Disable ................................................................................................................................................................................... 113

CODE 128 ...................................................................................................................................................................................114

Code 128 Enable/Disable .......................................................................................................................................................................................... 114

Expand Code 128 to Code 39 .................................................................................................................................................................................. 114

Code 128 Check Character Transmission ............................................................................................................................................................ 115

Code 128 Function Character Transmission ...................................................................................................................................................... 115

Code 128 Quiet Zones ................................................................................................................................................................................................ 116

Code 128 Length Control .......................................................................................................................................................................................... 116

Code 128 Set Length 1 ............................................................................................................................................................................................... 117

Code 128 Set Length 2 ............................................................................................................................................................................................... 118

Contents

4QuickScan™ I QD24XX

GS1-128 ......................................................................................................................................................................................119

GS1-128 Enable ............................................................................................................................................................................................................. 119

GS1-128 2D Component ........................................................................................................................................................................................... 119

CODE ISBT 128 ...........................................................................................................................................................................120

ISBT 128 Concatenation ............................................................................................................................................................................................ 120

ISBT 128 Force Concatenation ................................................................................................................................................................................ 120

ISBT 128 Concatenation Mode ................................................................................................................................................................................ 121

ISBT 128 Dynamic Concatenation Timeout ........................................................................................................................................................ 122

ISBT 128 Advanced Concatenation Options ...................................................................................................................................................... 123

INTERLEAVED 2 OF 5 (I 2 OF 5) .................................................................................................................................................123

I 2 of 5 Enable/Disable ................................................................................................................................................................................................ 123

I 2 of 5 Check Character Calculation ..................................................................................................................................................................... 124

I 2 of 5 Check Character Transmission .................................................................................................................................................................. 125

I 2 of 5 Length Control ............................................................................................................................................................................................... 125

I 2 of 5 Set Length 1 ..................................................................................................................................................................................................... 126

I 2 of 5 Set Length 2 ..................................................................................................................................................................................................... 127

INTERLEAVED 2 OF 5 CIP HR .....................................................................................................................................................128

Interleaved 2 of 5 CIP HR Enable/Disable ............................................................................................................................................................ 128

FOLLETT 2 OF 5 ..........................................................................................................................................................................128

Follett 2 of 5 Enable/Disable .................................................................................................................................................................................... 128

STANDARD 2 OF 5 .....................................................................................................................................................................129

Standard 2 of 5 Enable/Disable .............................................................................................................................................................................. 129

Standard 2 of 5 Check Character Calculation .................................................................................................................................................... 129

Standard 2 of 5 Check Character Transmission ................................................................................................................................................. 130

Standard 2 of 5 Length Control .............................................................................................................................................................................. 130

Standard 2 of 5 Set Length 1 ................................................................................................................................................................................... 131

Standard 2 of 5 Set Length 2 ................................................................................................................................................................................... 132

INDUSTRIAL 2 OF 5 ....................................................................................................................................................................133

Industrial 2 of 5 Enable/Disable .............................................................................................................................................................................. 133

Industrial 2 of 5 Check Character Calculation .................................................................................................................................................... 133

Industrial 2 of 5 Check Character Transmission ................................................................................................................................................ 134

Industrial 2 of 5 Length Control .............................................................................................................................................................................. 134

Industrial 2 of 5 Set Length 1 ................................................................................................................................................................................... 135

Industrial 2 of 5 Set Length 2 ................................................................................................................................................................................... 136

CODE IATA ..................................................................................................................................................................................137

IATA Enable/Disable ................................................................................................................................................................................................... 137

IATA Check Character Transmission ..................................................................................................................................................................... 137

CODABAR ...................................................................................................................................................................................138

Codabar Enable/Disable ............................................................................................................................................................................................ 138

Codabar Check Character Calculation .................................................................................................................................................................. 138

Codabar Check Character Transmission .............................................................................................................................................................. 139

Codabar Start/Stop Character Transmission ...................................................................................................................................................... 139

Codabar Start/Stop Character Set .......................................................................................................................................................................... 140

Codabar Start/Stop Character Match ................................................................................................................................................................... 140

Codabar Quiet Zones .................................................................................................................................................................................................. 141

Codabar Length Control ............................................................................................................................................................................................ 141

Codabar Set Length 1 ................................................................................................................................................................................................. 142

Codabar Set Length 2 ................................................................................................................................................................................................. 143

ABC CODABAR ...........................................................................................................................................................................144

ABC Codabar Enable/Disable .................................................................................................................................................................................. 144

ABC Codabar Concatenation Mode ...................................................................................................................................................................... 144

ABC Codabar Dynamic Concatenation Timeout .............................................................................................................................................. 145

ABC Codabar Force Concatenation ....................................................................................................................................................................... 146

CODE 11 ......................................................................................................................................................................................147

Code 11 Enable/Disable ............................................................................................................................................................................................ 147

Code 11 Check Character Calculation .................................................................................................................................................................. 147

Code 11 Check Character Transmission .............................................................................................................................................................. 148

Code 11 Length Control ............................................................................................................................................................................................ 148

Code 11 Set Length 1 ................................................................................................................................................................................................. 149

Code 11 Set Length 2 ................................................................................................................................................................................................. 150

GS1 DATABAR™ OMNIDIRECTIONAL .......................................................................................................................................151

GS1 DataBar™ Omnidirectional Enable/Disable ............................................................................................................................................... 151

Contents

Product Reference Guide 5

GS1 DataBar™ Omnidirectional GS1-128 Emulation ....................................................................................................................................... 151

GS1 DataBar™ Omnidirectional 2D Component .............................................................................................................................................. 152

GS1 DATABAR™ EXPANDED .....................................................................................................................................................152

GS1 DataBar™ Expanded Enable/Disable ............................................................................................................................................................ 152

GS1 DataBar™ Expanded GS1-128 Emulation ................................................................................................................................................... 153

GS1 DataBar™ Expanded 2D Component ........................................................................................................................................................... 153

GS1 DataBar™ Expanded Length Control ........................................................................................................................................................... 154

GS1 DataBar™ Expanded Set Length 1 ................................................................................................................................................................. 155

GS1 DataBar™ Expanded Set Length 2 ................................................................................................................................................................. 156

GS1 DATABAR™ LIMITED ..........................................................................................................................................................157

GS1 DataBar™ Limited Enable/Disable ................................................................................................................................................................. 157

GS1 DataBar™ Limited GS1-128 Emulation ........................................................................................................................................................ 157

GS1 DataBar™ Limited 2D Component ................................................................................................................................................................ 158

CODE 93 ......................................................................................................................................................................................158

Code 93 Enable/Disable ............................................................................................................................................................................................ 158

Code 93 Check Character Calculation .................................................................................................................................................................. 159

Code 93 Check Character Transmission .............................................................................................................................................................. 159

Code 93 Length Control ............................................................................................................................................................................................ 160

Code 93 Set Length 1 ................................................................................................................................................................................................. 161

Code 93 Set Length 2 ................................................................................................................................................................................................. 162

Code 93 Quiet Zones .................................................................................................................................................................................................. 163

MSI ..............................................................................................................................................................................................163

MSI Enable/Disable ...................................................................................................................................................................................................... 163

MSI Check Character Calculation ........................................................................................................................................................................... 164

MSI Check Character Transmission ........................................................................................................................................................................ 164

MSI Length Control ..................................................................................................................................................................................................... 165

MSI Set Length 1 .......................................................................................................................................................................................................... 166

MSI Set Length 2 .......................................................................................................................................................................................................... 167

PLESSEY ......................................................................................................................................................................................168

Plessey Enable/Disable .............................................................................................................................................................................................. 168

Plessey Check Character Calculation .................................................................................................................................................................... 168

Plessey Check Character Transmission ................................................................................................................................................................ 169

Plessey Length Control .............................................................................................................................................................................................. 169

Plessey Set Length 1 ................................................................................................................................................................................................... 170

Plessey Set Length 2 ................................................................................................................................................................................................... 171

2D Symbologies.................................................................................................................................................................... 173

2D Global Features .....................................................................................................................................................................................173

2D Maximum Decoding Time ....................................................................................................................................................................................................... 174

2D Structured Append .................................................................................................................................................................................................................... 175

2D Normal/Inverse Symbol Control ............................................................................................................................................................................................ 175

Aztec Code ..................................................................................................................................................................................................176

Aztec Code Enable / Disable .......................................................................................................................................................................................................... 176

Aztec Code Length Control ........................................................................................................................................................................................................... 176

Aztec Code Set Length 1 ........................................................................................................................................................................................... 177

Aztec Code Set Length 2 ........................................................................................................................................................................................... 178

China Sensible Code ...................................................................................................................................................................................179

China Sensible Code Enable / Disable ....................................................................................................................................................................................... 179

China Sensible Code Length Control ......................................................................................................................................................................................... 179

China Sensible Code Set Length 1 ......................................................................................................................................................................... 180

China Sensible Code Set Length 2 ......................................................................................................................................................................... 181

Data Matrix .................................................................................................................................................................................................182

Data Matrix Enable / Disable ......................................................................................................................................................................................................... 182

Data Matrix Square/Rectangular Style ....................................................................................................................................................................................... 182

Data Matrix Length Control ........................................................................................................................................................................................................... 183

Data Matrix Set Length 1 ........................................................................................................................................................................................... 183

Data Matrix Set Length 2 ........................................................................................................................................................................................... 184

Maxicode .....................................................................................................................................................................................................185

Maxicode Enable / Disable ............................................................................................................................................................................................................. 185

Maxicode Primary Message Transmission ................................................................................................................................................................................ 185

Maxicode Length Control ............................................................................................................................................................................................................... 186

Maxicode Set Length 1 .............................................................................................................................................................................................. 186

Maxicode Set Length 2 .............................................................................................................................................................................................. 187

Contents

6QuickScan™ I QD24XX

PDF417 ........................................................................................................................................................................................................188

PDF417 Enable / Disable ................................................................................................................................................................................................................. 188

PDF417 Length Control ................................................................................................................................................................................................................... 188

PDF417 Set Length 1 .................................................................................................................................................................................................. 189

PDF417 Set Length 2 .................................................................................................................................................................................................. 190

Micro PDF417 ..............................................................................................................................................................................................191

Micro PDF417 Enable / Disable .................................................................................................................................................................................................... 191

Micro PDF417 Code 128 GS1-128 Emulation .......................................................................................................................................................................... 191

Micro PDF417 Length Control ...................................................................................................................................................................................................... 192

Micro PDF417 Set Length 1 ...................................................................................................................................................................................... 192

Micro PDF417 Set Length 2 ...................................................................................................................................................................................... 193

QR Code .......................................................................................................................................................................................................194

QR Code Enable / Disable ............................................................................................................................................................................................................... 194

QR Code Length Control ................................................................................................................................................................................................................. 194

QR Code Set Length 1 ................................................................................................................................................................................................ 195

QR Code Set Length 2 ................................................................................................................................................................................................ 196

Micro QR Code ............................................................................................................................................................................................197

Micro QR Code Enable/Disable .................................................................................................................................................................................................... 197

Micro QR Code Length Control .................................................................................................................................................................................................... 197

Micro QR Code Set Length 1 .................................................................................................................................................................................... 198

Micro QR Code Set Length 2 .................................................................................................................................................................................... 199

UCC Composite ...........................................................................................................................................................................................200

UCC Composite Enable / Disable ................................................................................................................................................................................................. 200

UCC Optional Composite Timer ................................................................................................................................................................................................... 201

Postal Code Selection .................................................................................................................................................................................202

Postnet BB Control ............................................................................................................................................................................................................................ 203

REFERENCES................................................................................................................................................................................. 205

RS-232 Parameters .....................................................................................................................................................................................206

RS-232 .................................................................................................................................................................................................................................................... 206

RS-232/USB COM Parameters ....................................................................................................................................................................................................... 207

Keyboard Interface .....................................................................................................................................................................................214

Symbologies ...............................................................................................................................................................................................217

Set Length ............................................................................................................................................................................................................................................ 217

Data Editing ................................................................................................................................................................................................218

Reading Parameters ...................................................................................................................................................................................227

Scanning Features ......................................................................................................................................................................................228

Stand Mode Off Time ....................................................................................................................................................................................................................... 229

Aiming Duration Time ..................................................................................................................................................................................................................... 231

Multiple Labels Ordering by Code Symbology ...................................................................................................................................................................... 234

TECHNICAL SPECIFICATIONS...................................................................................................................................................... 237

Imager Labeling ..........................................................................................................................................................................................241

Standard Cable Pinouts .............................................................................................................................................................................242

LED and Beeper Indications .......................................................................................................................................................................243

Error Codes ..................................................................................................................................................................................................244

Contents

Product Reference Guide 7

STANDARD DEFAULTS................................................................................................................................................................ 245

SAMPLE BAR CODES.................................................................................................................................................................... 255

KEYPAD ........................................................................................................................................................................................ 259

SCANCODE TABLES ..................................................................................................................................................................... 261

Control Character Emulation .....................................................................................................................................................................261

Single Press and Release Keys ....................................................................................................................................................................................................... 261

Interface Type PC AT PS/2, USB-Keyboard or USB-Keyboard for APPLE ...............................................................................................262

Interface type PC AT PS/2 Alt Mode or USB-Keyboard Alt Mode ...........................................................................................................264

Digital Interface ..........................................................................................................................................................................................266

IBM31xx 102-key ........................................................................................................................................................................................267

IBM XT ..........................................................................................................................................................................................................268

Microsoft Windows Codepage 1252 .........................................................................................................................................................269

Contents

8QuickScan™ I QD24XX

NOTES

Product Reference Guide 1

Chapter 1

Introduction

About this Manual

This Product Reference Guide (PRG) is provided for users seeking advanced technical information, including

connection, programming, maintenance and specifications. The Quick Reference Guide (QRG) and other

publications associated with this product are downloadable free of charge from the website listed on the back cover

of this manual.

Overview

Chapter 1, (this chapter) presents information about manual conventions, and an overview of the reader, its

features and operation.

Chapter 2, Setup presents information about unpacking, cable connection information and setting up the reader.

Chapter 3, Configuration Using Bar Codes provides instructions and bar code labels for customizing your reader.

There are different sections for interface types, general features, data formatting, symbology-specific and model-

specific features.

Chapter 4, References contains additional information and examples for selected bar code features.

Appendix A, Technical Specifications lists physical and performance characteristics, as well as environmental and

regulatory specifications. It also provides standard cable pinouts and LED/Beeper functions.

Appendix B, Standard Defaults references common factory default settings for reader features and options.

Appendix C, Sample Bar Codes offers sample bar codes for several common symbologies.

Appendix D, Keypad includes numeric bar codes to be scanned for certain parameter settings.

Appendix E, Scancode Tables lists control character emulation information for Wedge and USB Keyboard

interfaces.

Technical Support

2QuickScan™ I QD24XX

Manual Conventions

The following conventions are used in this document:

The symbols listed below are used in this manual to notify the reader of key issues or procedures that must be

observed when using the reader:

Notes contain information necessary for properly diagnosing, repairing and operating the

reader.

CAUTION

The CAUTION symbol advises you of actions that could damage equipment or property.

Current versions of this Product Reference Guide (PRG), Quick Reference Guide (QRG), the Datalogic

Aladdin™ Configuration application, and any other manuals, instruction sheets and utilities for this product can

be downloaded from the website listed below. Alternatively, printed copies or product support CDs for most

products can be purchased through your Datalogic reseller.

Technical Support

Datalogic Website Support

The Datalogic website (www.datalogic.com) is the complete source for technical support and information for

Datalogic products. The site offers product support, warranty information, product manuals, product tech notes,

software updates, demos, and instructions for returning products for repair.

Reseller Technical Support

An excellent source for technical assistance and information is an authorized Datalogic reseller. A reseller is

acquainted with specific types of businesses, application software, and computer systems and can provide

individualized assistance.

Telephone Technical Support

If you do not have internet or email access, you may contact Datalogic technical support at (541) 349-8283 or

check the back cover of your manual for more contact information.

About the Reader

Product Reference Guide 3

About the Reader

The QuickScan™ QD2400 2D Imager was specifically created to address the needs of retailers and meet the

market demand with outstanding omni-directional reading performance on virtually all codes at an affordable

price. Elegant design details are incorporated into a smaller, balanced lightweight enclosure without sacrificing

Datalogic’s well-known durability.

Ideally suited for applications at the point of-sale (POS), the QuickScan QD2400 imager features a new

illumination and aiming system developed with the unique intent to reduce visual stress of the operator during the

daily scanning activities. It consists of a soft, dark red illumination combined with two blue LED triangles pointing

at the targeted bar code.

The result is a precise aiming system which contributes to low eye fatigue, yet still allows top operator efficiency.

The QuickScan QD2400 imager reads typical printed linear bar codes as well as complex 2D bar codes displayed

on the screen of a mobile device or loyalty cards. The QD2400 imager provides a fast, reliable scan from an elegant

and robust 2D imager.

Imaging technology meets or exceeds the productivity compared to laser scanners and provides the additional

advantages of a lower cost-of-ownership and greater product reliability over the long term.

Programming the Reader

4QuickScan™ I QD24XX

Programming the Reader

Configuration Methods

Programming Bar Codes

The reader is factory-configured with a standard set of default features. After scanning the interface bar code, you

can select other options and customize your reader through use of the instructions and programming bar code

labels available in the corresponding features section for your interface. Customizable settings for many features are

found in "Configuration Parameters" starting on page 15.

Some programming labels, like "Restore Custom Defaults" on page 13, require only the scan of the single label to

enact the change. Most, however, require the reader to be placed in Programming Mode prior to scanning them.

Scan an ENTER/EXIT bar code once to enter Programming Mode. Once the reader is in Programming Mode,

scan a number of parameter settings before scanning the ENTER/EXIT bar code a second time, which will then

accept your changes, exit Programming Mode and return the reader to normal operation.

There are some exceptions to the typical programming sequence described above. Please read the

description and setting instructions carefully when configuring each programmable feature.

Datalogic Aladdin™

Datalogic Aladdin™ is a multi-platform utility program providing a quick and user-friendly configuration method

via the RS-232/USB-COM interface. Aladdin is available for download free of charge on the Datalogic website.

Aladdin allows you to program the reader by selecting configuration commands through a user-friendly graphical

interface running on a PC. These commands are sent to the reader over the selected communication interface, or

they can be printed as bar codes to be scanned.

Aladdin also provides the ability to perform a software upgrade for the connected device (see the Datalogic

Aladdin™ Help On-Line for more details).

Product Reference Guide 5

Chapter 2

Setup

Unpacking

Check carefully to ensure the reader and any accessories ordered are present and undamaged. If any damage

occurred during shipment, contact Datalogic Technical Support. Information is shown on page 2.

KEEP THE PACKAGING. Should the unit ever require service, it should be returned in its original shipping

container.

Setting Up the Reader

ollow the steps provided in this section to connect and get your reader up and communicating with its host.

1. Begin by Installing the Interface Cable

2. Go to Interface Selection and set the desired interface.

3. Configure Interface Settings (only if not using factory settings for that interface).

4. Go to Configuring Other Features (if modifications are needed from factory settings).

Setup

6QuickScan™ I QD24XX

Installing the Interface Cable

onnect the reader cable by inserting the cable into the handle as shown in Figure 1. To remove it, insert a paper clip

into the release aperture, then unplug the cable.

Figure 1. Connect/disconnect the cable

RS-232 Serial Connection

Turn off power to the terminal/PC and connect the reader to the terminal/PC serial port via the RS-232 cable as

shown in Figure 2. If the terminal will not support POT (Power Off the Terminal) to supply reader power, use the

approved power supply (AC Adapter). Plug the AC Adapter barrel connector into the socket on the RS-232 cable

connector and the AC Adapter plug into a standard power outlet.

Figure 2. RS-232 Connection

Installing the Interface Cable

Product Reference Guide 7

Keyboard Wedge Connection

The Keyboard Wedge cable has a ‘Y’ connection from the reader. Connect the female to the male end from the

keyboard and the remaining end at the keyboard port at the terminal/PC. Reference Figure 3.

Figure 3. Keyboard Wedge Interface connection

USB Connection

Connect the reader to a USB port on the terminal/PC using the correct USB cable for the interface type you

ordered. Reference Figure 4.

Figure 4. USB connection

Other connection types are described below and illustrated in Figure 5.

Setup

8QuickScan™ I QD24XX

Figure 5. Other Interface Connections

or... or...

Specific cables are required for connection to different hosts. The connectors illustrated

above are examples only. Actual connectors may vary from those illustrated, but the steps to

connect the reader remain the same.

Interface Selection

Upon completing the physical connection between the reader and its host, proceed to Table 1 starting on page 9 to

select the interface type the reader is connected to (for example: RS-232, Keyboard Wedge, USB, etc.). Scan the

appropriate bar code in that section to configure your system’s correct interface type.

Each reader model will support one of the following sets of host interfaces:

General Purpose Models Retail Point of Sale Models

•RS-232

• RS-232 OPOS

•USB-COM

• Keyboard Wedge

•RS-232

• RS-232 OPOS

•USB

Interface Selection

Product Reference Guide 9

Setting the Interface

Scan the programming bar code from this section which selects the appropriate interface type matching the system

the reader will be connected to. Next, proceed to the corresponding section in this manual (also listed in Table 1 on

page 9) to configure any desired settings and features associated with that interface.

Unlike some programming features and options, interface selections require that you

scan only one programming bar code label. DO NOT scan an ENTER/EXIT bar code prior to

scanning an interface selection bar code.

Some interfaces require the scanner to start in the disabled state when powered up. If

additional scanner configuration is desired while in this state, pull the trigger and hold it

for five seconds. The scanner will change to a state that allows programming with bar

codes.

Table 1. Available Interfaces

RS-232 FEATURES

RS-232 standard interface

Select RS232-STD

Set RS-232

Interface

Features

starting on

page 19

$P,HA12,P(CR)

Select RS232-WN

RS-232 Wincor-Nixdorf

RS-232 for use with OPOS/UPOS/JavaPOS

$P,HA13,P(CR)

Select RS-232 OPOS

$P,HA47,P(CR)

Select USB-COM-STDa

a. Download the correct USB Com driver from www.datalogic.com

USB Com to simulate RS-232 standard interface

USB-OEM FEATURES

$P,HA45,P(CR)

Select USB-OEM

USB-OEM

(can be used for OPOS/UPOS/JavaPOS)

Set USB-OEM

Interface

Features

starting on

page 43

KEYBOARD FEATURES

$P,HA2B,P(CR)

Select USB Alternate Keyboard

USB Keyboard with alternate key encoding

AT, PS/2 25-286, 30-286, 50, 50Z, 60, 70,

80, 90 & 95 w/Standard Key Encoding

$P,HA29,P(CR)

Select KBD-AT

Set KEYBOARD

WEDGE

Interface

Features

starting on

page 33

$P,HA11,P(CR)

Select KBD-AT-NK

Keyboard Wedge for IBM AT PS2 with

standard key encoding but without

external keyboard

AT, PS/2 25-286, 30-286, 50, 50Z, 60, 70,

80, 90 & 95 w/Alternate Key

$P,HA26,P(CR)

Select KBD-AT-ALT

$P,HA10,P(CR)

Select KBD-AT-ALT-NK

Keyboard Wedge for IBM AT PS2 with

alternate key encoding but without

external keyboard

PC/XT w/Standard Key Encoding

$P,HA28,P(CR)

Select KBD-XT

$P,HA14,P(CR)

Select KBD-IBM-3153

Keyboard Wedge for IBM Terminal 3153

Setup

10 QuickScan™ I QD24XX

KEYBOARD (continued) FEATURES

Keyboard Wedge for IBM Terminals

31xx, 32xx, 34xx, 37xx make only key-

board

$P,HA15,P(CR)

Select KBD-IBM-M

Set KEYBOARD

WEDGE

Interface

Features

starting on page

$P,HA16,P(CR)

Select KBD-IBM-MB

Keyboard Wedge for IBM Terminals

31xx, 32xx, 34xx, 37xx make break key-

board

Keyboard Wedge for DIGITAL 

Terminals VT2xx, VT3xx, VT4xx

$P,HA1B,P(CR)

Select KBD-DIG-VT

$P,HA35,P(CR)

Select USB Keyboard

USB Keyboard with standard key encoding

USB Keyboard for Apple computers

$P,HA2C,P(CR)

Select USB-KBD-APPLE

Interface Selection

Product Reference Guide 11

Setup

12 QuickScan™ I QD24XX

Customizing Configuration Settings

Configure Interface Settings

If after scanning the interface bar code from the previous table, your installation requires you to select options to

further customize your reader, turn to the appropriate section for your interface type in "Configuration

Parameters" starting on page 15.

•"RS-232 Interface" on page 19

•"RS-232/USB-Com Interfaces" on page 24

•"Keyboard Settings" on page 33

Global Interface Features

See "Global Interface Features" on page 17 for settings configurable by all interface types.

Configuring Other Features

If your installation requires different programming than the standard factory default settings, the following sections

of this manual allow configuration of non-interface-specific settings you might require:

Data Format

Data Format offers options to control the messages sent to the Host system.

Reading Parameters

Reading Parameters include programming for scanning, beeper and LED indicators and other

universal settings.

Symbology-Specific Parameters

1D Symbologies

Includes options concerning the bar code label types (symbologies). These settings allow you to

enable/disable symbologies, set label lengths, require check digit, etc.

2D Symbologies

Includes options concerning the bar code label types (symbologies). These settings allow you to

enable/disable symbologies, set label lengths, require check digit, etc.

Software Version Transmission

The software version of the device can be transmitted over the RS-232 and Keyboard interfaces by scanning the

following label.

Transmit Software Version

RevA

Customizing Configuration Settings

Product Reference Guide 13

Resetting the Product Configuration to Defaults

Restore Custom Defaults

If you aren’t sure what programming options are in your imager, or you’ve changed some options and want to

restore the Custom Default Configuration that may have been saved in the scanner, scan the Restore Custom

Default Configuration bar code below. This will restore the custom configuration for the currently active interface.

Restore Custom Default Configuration

$P,HA00,P(CR)

Custom defaults are based on the interface type. Configure the imager for the correct

interface before scanning this label.

Restore Factory Configuration

If you want to restore the Factory Configuration for your imager, scan either the Restore USA Factory

Configuration bar code or the Restore EU Factory Configuration bar code below. Both labels restore the scanner

configuration to the factory settings, including the interface type. The USA label restores Label IDs to those

historically used in the USA. The EU label restores Label IDs to those historically used in Europe. The Label ID

sets for USA and EU are shown in the “Label ID Control” section on page 53 of this manual.

$P,AE,P(CR)

Restore USA Factory Configuration

$P,Ae,P(CR)

Restore EU Factory Configuration

The programming items listed in the following sections show the factory default settings for each of the menu

commands.

Setup

14 QuickScan™ I QD24XX

NOTES

Product Reference Guide 15

Chapter 3

Configuration Using Bar Codes

This and following sections provide programming bar codes to configure your reader by changing the default

settings. For details about additional methods of programming, see "Configuration Methods" on page 4.

You must first enable your reader to read bar codes in order to use this section. If you have not

done this, go to

Setup, starting on page 5

and complete the appropriate procedure.

Configuration Parameters

Once the reader is set up, you can change the default parameters to meet your application needs. Refer to "Standard

Defaults" starting on page 245 for initial configuration in order to set the default values and select the interface for

your application.

The following configuration parameters are divided into logical groups, making it easy to find the desired function

based on its reference group.

Interface Configuration:

•"RS-232/USB-Com Interfaces" on page 24

•"Keyboard Settings" on page 33

Parameters common to all interface applications:

•"Data Format" on page 47 gives options to control the messages sent to the Host system.

•"Reading Parameters" on page 61 control various operating modes and indicators status functioning.

Symbology-specific parameters:

•"1D Symbologies" on page 81 provides configuration of a personalized mix of 1D codes, code families and

their options.

•"2D Symbologies" on page 173 provides configuration of a personalized mix of 2D codes, code families and

their options.

You must first enable your reader to read bar codes in order to use this section. If you have not

done this, go to

Setup, starting on page 5

and complete the appropriate procedure.

To program features:

1. Scan the ENTER/EXIT PROGRAMMING bar code, available at the top of each programming page, when

applicable.

2. Scan the bar code to set the desired programming feature. You may need to cover unused bar codes on the

page, and possibly the facing page, to ensure that the reader reads only the bar code you intend to scan.

Enter/Exit Programming Mode

16 QuickScan™ I QD24XX

3. If additional input parameters are needed, go to Appendix D, Keypad, and scan the appropriate characters

from the keypad.

Additional information about many features can be found in the “References” chapter.

If you make a mistake before the last character, scan the CANCEL bar code to abort and not

save the entry string. You can then start again at the beginning.

4. Complete the programming sequence by scanning the ENTER/EXIT PROGRAMMING bar code to exit

Programming Mode.

For more detailed descriptions, programming information and examples for setting selected configuration items,

see References, starting on page 205.

By default, the handheld will decode bar code labels only when they are close to the center

of the aiming pattern. This allows the handheld to accurately target labels when they are

placed close together, such as on a pick sheet. See

Pick Mode, starting on page 72.

Enter/Exit Programming Mode

Product Reference Guide 17

GLOBAL INTERFACE FEATURES

The following interface features are configurable by all interface types.

Host Commands — Obey/Ignore

This option specifies whether the reader will obey or ignore host commands. When set to ignore, the reader will

ignore all host commands except for those necessary for:

•service mode

• flash programming mode

• keeping the interface active

• transmission of labels.

DEFAULT

$CIFIH00(CR)

Host Commands = Obey

(Do Not Ignore Host Commands)

$CIFIH01(CR)

Host Commands = Ignore

USB Suspend Mode

This setting enables/disables the ability of USB interfaces to enter suspend mode.

DEFAULT

$CUSSE00(CR)

USB Suspend Mode = Disable

$CUSSE01(CR)

USB Suspend Mode = Enable

Enter/Exit Programming Mode

18 QuickScan™ I QD24XX

NOTES

Product Reference Guide 19

RS-232 INTERFACE

BAUD RATE on page 20

DATA BITS on page 21

STOP BITS on page 21

PARITY on page 22

HANDSHAKING CONTROL on page 23

Use the programming bar codes in this section if modifications to the standard RS-232 interface settings are

necessary to meet your system’s requirements. Additional settings which apply to both the RS-232 and USB

interfaces are available in the next section, "RS-232/USB-Com Interfaces" starting on page 24.

Reference Appendix B, Standard Defaults for a listing of standard factory settings.

Enter/Exit Programming Mode

20 QuickScan™ I QD24XX

Baud Rate

See page 206 for information on this feature.

$CR2BA00(CR)

Baud Rate = 1200

$CR2BA01(CR)

Baud Rate = 2400

$CR2BA02(CR)

Baud Rate = 4800

$CR2BA03(CR)

Baud Rate = 9600

DEFAULT

$CR2BA04(CR)

Baud Rate = 19,200

$CR2BA05(CR)

Baud Rate = 38,400

$CR2BA06(CR)

Baud Rate = 57,600

$CR2BA07(CR)

Baud Rate = 115,200

Enter/Exit Programming Mode

Product Reference Guide 21

Data Bits

This parameter allows the reader to interface with devices requiring a 7-bit or 8-bit ASCII protocol for sending and

receiving data.

$CR2DA00(CR)

7 Data Bits

$CR2DA01(CR)

8 Data Bits

DEFAULT

Stop Bits

Set the number of stop bits to match host device requirements. See page 206 for more information on this feature.

DEFAULT

$CR2ST00(CR)

1 Stop Bit

$CR2ST01(CR)

2 Stop Bits

Enter/Exit Programming Mode

22 QuickScan™ I QD24XX

Parity

This feature specifies parity required for sending and receiving data. Select the parity type according to host device

requirements. See page 206 for more information.

DEFAULT

$CR2PA00(CR)

Parity = None

$CR2PA01(CR)

Parity = Even

$CR2PA02(CR)

Parity = Odd

Enter/Exit Programming Mode

Product Reference Guide 23

Handshaking Control

DEFAULT

$CR2HC00(CR)

Handshaking Control = RTS

$CR2HC01(CR)

Handshaking Control = RTS/CTS

$CR2HC02(CR)

Handshaking Control = RTS/XON/XOFF

$CR2HC03(CR)

Handshaking Control = RTS On/CTS

$CR2HC04(CR)

Handshaking Control = RTS/CTS Scan Control

See page 206 for more information about this feature.

Product Reference Guide 24

RS-232/USB-COM INTERFACES

INTERCHARACTER DELAY on page 25

BEEP ON ASCII BEL on page 25

BEEP ON NOT ON FILE on page 26

ACK NAK OPTIONS on page 27

ACK CHARACTER on page 28

NAK CHARACTER on page 28

ACK NAK TIMEOUT VALUE on page 29

ACK NAK RETRY COUNT on page 29

ACK NAK ERROR HANDLING on page 30

INDICATE TRANSMISSION FAILURE on page 30

DISABLE CHARACTER on page 31

ENABLE CHARACTER on page 31

The programming bar codes in this chapter allow modifications to the standard RS-232 and USB-Com interfaces.

Reference Appendix B, Standard Defaults for a listing of standard factory settings.

Enter/Exit Programming Mode

Product Reference Guide 25

Intercharacter Delay

This parameter specifies the intercharacter delay between the end of one character and the beginning of the next.

The delay can be set within a range of zero (0) to 990 milliseconds in 10ms increments. A setting of zero specifies

no delay.

See page 215 for more information.

$CR2IC00(CR)

Intercharacter Delay = No Delay

$CR2IC

Select Intercharacter Delay Setting

To configure this feature, scan the ENTER/EXIT

PROGRAMMING MODE bar code above, then the

bar code at left followed by the digits from the

Alphanumeric characters in Appendix D, Keypad

representing your desired character(s). End by

scanning the ENTER/EXIT bar code again.

Make a mistake? Scan the CANCEL bar code to abort

and not save the entry string. You can then start again at

the beginning.

CANCEL

DEFAULT

00 = No Intercharacter Delay

Beep On ASCII BEL

When this parameter is enabled, the reader issues a beep when a <BEL> character is detected on the RS-232 serial

line. <BEL> is issued to gain a user's attention to an illegal entry or other important event.

$CR2BB00(CR)

Beep On ASCII BEL = Disable

DEFAULT

$CR2BB01(CR)

Beep On ASCII BEL = Enable

Enter/Exit Programming Mode

26 QuickScan™ I QD24XX

Beep On Not on File

This option enables/disables the action of the reader to sound a three beep sequence upon receiving a Not-On-File

(NOF) host command.

$CBPNF00(CR)

Beep On Not On File = Disable

DEFAULT

$CBPNF01(CR)

Beep On Not On File = Enable

Enter/Exit Programming Mode

Product Reference Guide 27

ACK NAK Options

This enables/disables the ability of the reader to support the RS-232 ACK/NAK protocol. 

See page 208 for more information.

DEFAULT

$CR2AE00(CR)

ACK/NAK Protocol = Disable ACK/NAK

$CR2AE01(CR)

ACK/NAK Protocol = Enable for label transmission

$CR2AE02(CR)

ACK/NAK Protocol = Enable for host-command

acknowledge

$CR2AE03(CR)

ACK/NAK Protocol = Enable for label transmission and

host-command acknowledge

Enter/Exit Programming Mode

28 QuickScan™ I QD24XX

ACK Character

This setting specifies an ASCII character or hex value to be used as the ACK character. ASCII characters or any hex

value from 0 to 0xFF can be selected. See page 208 for more information.

$CR2AC

Select ACK Character Setting

DEFAULT

0x06 ‘ACK’ Character

Setting to previously defined characters such as XON, XOFF, or host commands conflicts with normal

operation of these characters. 8-bit data is not recognized when the option

Data Bits

has been set as

7 Data Bits.

NAK Character

This setting specifies an ASCII character or hex value to be used as the NAK character. ASCII characters or any hex

value from 0 to 0xFF can be selected.

Setting to previously defined characters such as XON, XOFF, or host commands conflicts with normal

operation of these characters. 8-bit data is not recognized when the option

Data Bits

has been set as

7 Data Bits.

See page 209 for more information.

$CR2NA

Select NAK Character Setting

DEFAULT

0x15 ‘NAK’ Character

Enter/Exit Programming Mode

Product Reference Guide 29

ACK NAK Timeout Value

This option specifies the amount of time the reader waits for an ACK character from the host following label

transmission. The selectable timeout range is 200 milliseconds to 15,000ms (15 seconds) in 200ms increments. A

selection of 0 disables the timeout.

See page 210 for more information on setting this feature.

$CR2AT

Select ACK NAK Timeout Value Setting

To configure this feature, scan the ENTER/EXIT

PROGRAMMING MODE bar code above, then the

bar code at left followed by the digits from the

Alphanumeric characters in Appendix D, Keypad

representing your desired character(s). End by

scanning the ENTER/EXIT bar code again.

Make a mistake? Scan the CANCEL bar code to abort and

not save the entry string. You can then start again at the

beginning.

CANCEL

DEFAULT

01 ACK NAK Timeout value is 200ms

ACK NAK Retry Count

This feature specifies the number of times the reader retries a label transmission due to a retry condition. The

selectable range is from 1 to 254 retries. A selection of 0 disables the count, and a selection of 255 specifies

unlimited retries. See page 211 for more information.

$CR2AR

Select ACK NAK Retry Count Setting

To configure this feature, scan the ENTER/EXIT

PROGRAMMING MODE bar code above, then the

bar code at left followed by the digits from the

Alphanumeric characters in Appendix D, Keypad

representing your desired character(s). End by

scanning the ENTER/EXIT bar code again.

Make a mistake? Scan the CANCEL bar code to abort and

not save the entry string. You can then start again at the

beginning.

CANCEL

DEFAULT

003 = 3 Retries

Enter/Exit Programming Mode

30 QuickScan™ I QD24XX

ACK NAK Error Handling

This feature specifies the method the reader uses to handle receive errors detected while waiting for an ACK

character from the host.

DEFAULT

$CR2EH00(CR)

ACK NAK Error Handling = Ignore Errors Detected

$CR2EH01(CR)

ACK NAK Error Handling = Process Error as Valid ACK

Character

$CR2EH02(CR)

ACK NAK Error Handling = Process Error as

Valid NAK Character

Indicate Transmission Failure

This option enables/disables the reader’s ability to sound an error beep to indicate a transmission failure while in

ACK/NAK mode

$CR2TF00(CR)

Indicate Transmission Failure = Disable Indication

$CR2TF01(CR)

Indicate Transmission Failure = Enable Indication

DEFAULT

Enter/Exit Programming Mode

Product Reference Guide 31

Disable Character

Specifies the value of the RS-232 host command used to disable the reader.

ASCII characters or any hex value from 0 to 0xFF can be selected.

Setting to previously defined characters such as XON, XOFF, or host commands conflicts with

normal operation of these characters. 8-bit data is not recognized when the option

Data Bits

has been set as 7 Data Bits.

See page 212 for more information on setting this feature.

$CR2DC

Select Disable Character Setting

DEFAULT

0x44 = Disable Character is ‘D’

Enable Character

Specifies the value of the RS-232 host command used to enable the reader.

ASCII characters or any hex value from 0 to 0xFF can be selected.

Setting to previously defined characters such as XON, XOFF, or host commands conflicts with

normal operation of these characters. 8-bit data is not recognized when the option

Data Bits

has been set as 7 Data Bits.

See page 213 in “References” for more information on setting this feature.

$CR2EC

Select Enable Character Setting

DEFAULT

0x45 = Enable Character is ‘E’

Enter/Exit Programming Mode

32 QuickScan™ I QD24XX

NOTES

Product Reference Guide 33

KEYBOARD SETTINGS

COUNTRY MODE on page 34

SEND CONTROL CHARACTERS on page 38

WEDGE QUIET INTERVAL on page 39

INTERCODE DELAY on page 39

CAPS LOCK STATE on page 40

NUMLOCK on page 40

USB KEYBOARD SPEED on page 41

USB KEYBOARD NUMERIC KEYPAD on page 42

Use the programming bar codes in this chapter to select options for USB Keyboard and Wedge Interfaces.

Reference Appendix B, Standard Defaults for a listing of standard factory settings.

Information about control character emulation which applies to keyboard interfaces is listed in Appendix E,

Scancode Tables.

Enter/Exit Programming Mode

34 QuickScan™ I QD24XX

Country Mode

This feature specifies the country/language supported by the keyboard. Several languages are supported:

DEFAULT

$CKBCO00(CR)

Country Mode = U.S.

$CKBCO01(CR)

Country Mode = Belgium

$CKBCO02(CR)

Country Mode = Britain

$CKBCO11(CR)

Country Mode = Croatia

Supports only the interfaces listed in the Country

Mode feature description.

Supports only the interfaces listed in the Country

Mode feature description.

$CKBCO0E(CR)

Country Mode = Czech Republic

$CKBCO03(CR)

Country Mode = Denmark

Supports only the interfaces listed in the Country Mode

feature description.

Enter/Exit Programming Mode

Product Reference Guide 35

Country Mode (continued)

$CKBCO04(CR)

Country Mode = France

Supports only the interfaces listed in the Country Mode fea-

ture description.

$CKBCO13(CR)

Country Mode = French Canadian

$CKBCO05(CR)

Country Mode = Germany

Supports only the interfaces listed in the Country Mode fea-

ture description.

$CKBCO0D(CR)

Country Mode = Hungary

$CKBCO06(CR)

Country Mode = Italy

Supports only the interfaces listed in the Country Mode fea-

ture description.

$CKBCO0C(CR)

Country Mode = Japanese 106-key

Enter/Exit Programming Mode

36 QuickScan™ I QD24XX

Country Mode (continued)

$CKBCO14(CR)

Country Mode = Lithuanian

Supports only the interfaces listed in the Country Mode

feature description.

$CKBCO07(CR)

Country Mode = Norway

$CKBCO12(CR)

Country Mode = Poland

Supports only the interfaces listed in the Country Mode

feature description.

Supports only the interfaces listed in the Country Mode fea-

ture description.

$CKBCO08(CR)

Country Mode = Portugal

$CKBCO10(CR)

Country Mode = Romania

Supports only the interfaces listed in the Country

Mode feature description.

Supports only the interfaces listed in the Country Mode fea-

ture description.

$CKBCO0F(CR)

Country Mode = Slovakia

Enter/Exit Programming Mode

Product Reference Guide 37

Country Mode (continued)

$CKBCO09(CR)

Country Mode = Spain

$KBCO0A(CR)

Country Mode = Sweden

$CKBCO0B(CR)

Country Mode = Switzerland

Supports only the interfaces listed in the Country

Mode feature description.

Enter/Exit Programming Mode

38 QuickScan™ I QD24XX

Send Control Characters

This feature specifies how the reader transmits ASCII control characters to the host. Reference Appendix E,

Scancode Tables for more information about control characters.

Options are as follows:

Control Character 00 :

Characters from 00 to 0x1F are sent as control character Ctrl+Keys, special keys are located

from 0x80 to 0xA1.

Control Character 01 :

Characters from 00 to 0x1F are sent as control character Ctrl+Shift, special keys are located

from 0x80 to 0xA1.

Control Character 02 :

Special keys are located from 00 to 0x1F and characters from 0x80 to 0xFE are intended as

an extended ASCII table (see "Microsoft Windows Codepage 1252" on page 269).

DEFAULT

$CKBSC00(CR)

Wedge Send Control Characters = 00

$CKBSC01(CR)

Wedge Send Control Characters = 01

$CKBSC02(CR)

Wedge Send Control Characters = 02

Enter/Exit Programming Mode

Product Reference Guide 39

Wedge Quiet Interval

Specifies amount of time to look for keyboard activity before scanner breaks keyboard connection in order to

transmit data to host. The selectable range for this setting is 00 to 990 milliseconds (00-0x63 by 01) in increments

of ten milliseconds. See page 214 in “References” for detailed information and examples for setting this feature.

$CKBQI

Set Wedge Quiet Interval

To configure this feature, scan the ENTER/EXIT PROGRAM-

MING MODE bar code above, then the bar code at left fol-

lowed by the digits from the Alphanumeric characters in

Appendix D, Keypad representing your desired charac-

ter(s). End by scanning the ENTER/EXIT bar code again.

Make a mistake? Scan the CANCEL bar code to abort and

not save the entry string. You can then start again at the

beginning.

CANCEL

DEFAULT

0A = Quiet Interval is

100 milliseconds

Intercode Delay

Specifies the delay between labels transmitted to the host for this interface. The selectable range for this feature is

from 0 to 99 seconds.

See page 216 in “References” for detailed information and examples for setting this feature.

$CKBID

Set Intercode Delay

To configure this feature, scan the ENTER/EXIT PROGRAM-

MING MODE bar code above, then the bar code at left fol-

lowed by the digits from the Alphanumeric characters in

Appendix D, Keypad representing your desired charac-

ter(s). End by scanning the ENTER/EXIT bar code again.

Make a mistake? Scan the CANCEL bar code to abort and

not save the entry string. You can then start again at the

beginning.

CANCEL

DEFAULT

00 = No Wedge Intercode Delay

Enter/Exit Programming Mode

40 QuickScan™ I QD24XX

Caps Lock State

This option specifies the format in which the reader sends character data. This does not apply when an alternate

key encoding keyboard is selected.

DEFAULT

$CKBCL00(CR)

Caps Lock State = Caps Lock OFF

$CKBCL01(CR)

Caps Lock State = Caps Lock ON

$CKBCL02(CR)

Caps Lock State = AUTO Caps Lock Enable

Numlock

This option specifies the setting of the NUMLOCK key in the Keyboard Wedge interface.

DEFAULT

$CKBNL00(CR)

Numlock = NUMLOCK key unchanged

$CKBNL01(CR)

Numlock = Numlock key toggled

Enter/Exit Programming Mode

Product Reference Guide 41

USB Keyboard Speed

This option specifies the USB poll rate for a USB keyboard.

DEFAULT

$CKBSP01(CR)

USB Keyboard Speed = 1ms

$CKBSP02(CR)

USB Keyboard Speed = 2ms

$CKBSP03(CR)

USB Keyboard Speed = 3ms

$CKBSP04(CR)

USB Keyboard Speed = 4ms

$CKBSP05(CR)

USB Keyboard Speed = 5ms

$CKBSP06(CR)

USB Keyboard Speed = 6ms

This feature applies ONLY to the USB Keyboard interface.

$CKBSP07(CR)

USB Keyboard Speed = 7ms

$CKBSP08(CR)

USB Keyboard Speed = 8ms

$CKBSP09(CR)

USB Keyboard Speed = 9ms

$CKBSP0A(CR)

USB Keyboard Speed = 10ms

Enter/Exit Programming Mode

42 QuickScan™ I QD24XX

USB Keyboard Speed (continued)

USB Keyboard Numeric Keypad

This option Controls whether numeric characters will be sent using standard keys or the numeric keypad.

DEFAULT

$CKBKP00(CR)

Standard Keys

$CKBKP01(CR)

Numeric Keypad

Product Reference Guide 43

USB-OEM INTERFACE

USB-OEM DEVICE USAGE on page 44

USB INTERFACE OPTIONS on page 44

Feature settings for USB interfaces differ depending upon which host type the reader will be connected with. Use

the feature settings in this chapter to specifically configure for the USB-OEM interface. Other USB interfaces are

included in the appropriate chapter for their host type.

Reference Appendix B for a listing of standard factory settings.

Enter/Exit Programming Mode

44 QuickScan™ I QD24XX

USB-OEM Device Usage

The USB-OEM protocol allows for the reader to be identified as one of two different types of bar code scanners.

Depending on what other scanners you may already have connected to a USB-OEM POS, you may need to change

this setting to enable all devices to communicate.

Options are:

• Table Top Scanner

• Handheld Scanner

$CIBUT00(CR)

USB-OEM Device Usage = Table Top Scanner

$CIBUT01(CR)

USB-OEM Device Usage = Handheld Scanner

DEFAULT

It may be necessary to switch device usage when connecting two readers/scanners of the same

type to a POS system.

USB Interface Options

DEFAULT

$CIFIH00(CR)

Obey Scanner Configuration Host Commands

$CIFIH01(CR)

Ignore Scanner Configuration Host Commands

This feature provides for an interface-specific control mechanism.

Enter/Exit Programming Mode

Product Reference Guide 45

Transmit Labels in Code 39 Format

This feature enable/disables translation to Code 39 before transmitting label data to a USB-OEM host. Only the

symbology identifier is modified for the translation. The data is not converted to Code 39 or verified to be valid

for Code 39.

Options are:

IBM Standard Format:

Send labels in standard IBM format.

Mixed IBM Standard and Code 39 Format:

Code 39 Format:

Translate the following symbologies to Code 39:

• USB-OEM: Code128, Code 93, and Codabar

DEFAULT

$CIBC300(CR)

Transmit Labels in Code 39 Format =

IBM Standard Format

$CIBC301(CR)

Transmit Labels in Code 39 Format =

Mixed IBM Standard and Code 39 format

$CIBC302(CR)

Transmit Labels in Code 39 Format =

All Code 39 Format

Enter/Exit Programming Mode

46 QuickScan™ I QD24XX

Interface Options

DEFAULT

$CIFO101(CR)

Obey Scanner Configuration Host Commands

$CIFO102(CR)

Ignore Scanner Configuration Host Commands

This feature provides for an interface-specific control mechanism.

Enter/Exit Programming Mode

50 QuickScan™ I QD24XX

DATABAR EXPANDED

COMPOSITE e 65

DATABAR LIMITED e 65

DATABAR LIMITED COMPOSITE e 65

DATA MATRIX d 64

EAN128 C 43

EAN128 COMPOSITE C 43

EAN13 E 45

EAN13 P2 E 45

EAN13 P5 E 45

EAN13 COMPOSITE E 45

EAN8 E 45

EAN8 P2 E 45

EAN8 P5 E 45

EAN8 COMPOSITE E 45

FOLLET 2OF5 X 58

I2OF5 I 49

IATA INDUSTRIAL 2OF5 X 58

INDUSTRIAL 2OF5 X 58

ISBN X 58

ISBT128 CONCAT X 58

ISSN X 58

MAXICODE U 55

MICRO QR Q 51

MICRO PDF L 4C

MSI M 4D

PDF417 L 4C

PLESSEY P 50

POSTAL AUSTRALIAN X 58

POSTAL IMB X 58

POSTAL JAPANESE X 58

POSTAL KIX X 58

POSTAL PLANET X 58

POSTAL PORTUGAL X 58

POSTAL POSTNET BB X 58

POSTAL ROYAL MAIL X 58

POSTAL SWEDISH X 58

POSTNET X 58

QR CODE Q 51

S25 S 53

TRIOPTIC X 58

UPCA E 45

UPCA P2 E 45

UPCA P5 E 45

UPCA COMPOSITE E 45

UPCE E 45

UPCE P2 E 45

UPCE P5 E 45

UPCE COMPOSITE E 45

Enter/Exit Programming Mode

Product Reference Guide 53

Individually Set Label ID

This feature configures a Label ID individually for a single symbology. To set, first define whether you want it as a

prefix or suffix by scanning a label below. Then turn to Label ID Symbology Selection • 1D Symbologies, starting

on page 54 to select the symbology you want to set, followed by up to 3 characters from the ASCII Chart at the

back of this manual. See "Label ID: Set Individually Per Symbology" on page 224 for detailed instructions on

setting this feature.

Label ID Control

This option controls whether a Label ID is disabled, or sent as a prefix or suffix for a given symbology type.

DEFAULT

$CIDCO00(CR)

Label ID Transmission = Disable

$CIDCO01(CR)

Label ID Transmission = Enable as Prefix

$CIDCO02(CR)

Label ID Transmission = Enable as Suffix

$CAZID

Set Aztec Label ID Character(s)

$CMXID

Set Maxicode Label ID Character(s)

$CCSID

Set China Sensible Label ID Character(s)

$CP4ID

Set PDF 417 Label ID Character(s)

$CDMID

Set Data Matrix Label ID Character(s)

$CMIID

Set Micro PDF 417 Label ID Character(s)

$CMQID

Set Micro QR Label ID Character(s)

$CQRID

Set QR Code Label ID Character(s)

Enter/Exit Programming Mode

58 QuickScan™ I QD24XX

Label ID Symbology Selection − 2D Symbologies

Product Reference Guide 61

READING PARAMETERS

DOUBLE READ TIMEOUT starting on page 62

LED AND BEEPER INDICATORS starting on page 64

•Power On Alert

•Good Read: When to Indicate

•Good Read Beep Type

•Good Read Beep Frequency

•Good Read Beep Length

•Good Read Beep Volume

•Good Read LED Duration

SCANNING FEATURES starting on page 69

•Scan Mode

•Stand Mode Indication

•Stand Operation

•Pick Mode

•Stand Mode Sensitivity

•Stand Mode Illumination Off Time

•Scanning Active Time

•Stand Illumination Control

•Flash On Time

•Flash Off Time

•Aiming Pointer

•Aiming Duration Timer

•Green Spot Duration

•Mobile Phone Mode

•Partial Label Reading Control

•Decode Negative Image

•Image Capture

MULTIPLE LABEL READING starting on page 79

•Multiple Labels per Frame

•Multiple Labels Ordering by Code Symbology

•Multiple Labels Ordering by Code Length

Enter/Exit Programming Mode

66 QuickScan™ I QD24XX

Good Read Beep Length

$CBPLE06(CR)

Good Read Beep Length = 60 msec

$CBPLE08(CR)

Good Read Beep Length = 80 msec

DEFAULT

$CBPLE0A(CR)

Good Read Beep Length = 100 msec

$CBPLE0C(CR)

Good Read Beep Length = 120 msec

$CBPLE0E(CR)

Good Read Beep Length = 140 msec

$CBPLE10(CR)

Good Read Beep Length = 160 msec

$CBPLE12(CR)

Good Read Beep Length = 180 msec

$CBPLE14(CR)

Good Read Beep Length = 200 msec

Enter/Exit Programming Mode

Product Reference Guide 77

Green Spot Duration

Specifies the duration of the good read pointer beam after a good read.

$CLSSP00(CR)

Green Spot Duration = Disable (Green Spot is Off)

$CLSSP01(CR)

Green Spot Duration = Short (300 msec)

DEFAULT

$CLSSP02(CR)

Green Spot Duration = Medium (500 msec)

$CLSSP03(CR)

Green Spot Duration = Long (800 msec)

Mobile Phone Mode

This mode is useful for scanning bar codes displayed on a mobile phone. Other options for this feature can be

configured using the Datalogic Aladdin application.

$CSNPE00(CR)

Mobile Phone Mode = Disable

$CSNPE01(CR)

Mobile Phone Mode = Enable

DEFAULT

Enter/Exit Programming Mode

84 QuickScan™ I QD24XX

UPC-A

The following options apply to the UPC-A symbology.

UPC-A Enable/Disable

When disabled, the reader will not read UPC-A bar codes.

$CABEN00(CR)

UPC-A = Disable

$CABEN01(CR)

UPC-A = Enable

DEFAULT

UPC-A Check Character Transmission

Enable this option to transmit the check character along with UPC-A bar code data.

$CABCT00(CR)

UPC-A Check Character Transmission = Don’t Send

$CABCT01(CR)

UPC-A Check Character Transmission = Send

DEFAULT

Enter/Exit Programming Mode

Product Reference Guide 101

Optional GS1-128 Add-On Timer

This option sets the timer expiration value to read the added part after reading the linear EAN/UPC part. For

UPC/EAN add-ons other than those of that type, see "Optional Add-On Timer" on page 98.

DEFAULT

$CADUT00(CR)

Optional GS1-128 Add-On Timer = Disable

$CADUT01(CR)

Optional GS1-128 Add-On Timer = 10ms

$CADUT02(CR)

Optional GS1-128 Add-On Timer = 20ms

$CADUT03(CR)

Optional GS1-128 Add-On Timer = 30ms

$CADUT04(CR)

Optional GS1-128 Add-On Timer = 40ms

$CADUT05(CR)

Optional GS1-128 Add-On Timer = 50ms

$CADUT06(CR)

Optional GS1-128 Add-On Timer = 60ms

$CADUT07(CR)

Optional GS1-128 Add-On Timer = 70ms

$CADUT0A(CR)

Optional GS1-128 Add-On Timer = 100ms

$CADUT0C(CR)

Optional GS1-128 Add-On Timer = 120ms

$CADUT0E(CR)

Optional GS1-128 Add-On Timer = 140ms

$CADUT10(CR)

Optional GS1-128 Add-On Timer = 160ms

Enter/Exit Programming Mode

102 QuickScan™ I QD24XX

Optional GS1-128 Add-On Timer (continued)
