Sida 1/7
1
D U 5WEBELL 342
1. Disassembly Procedures
S1 Turn off power
S2
To remove the stand:
Place the monitor on the curve cushion
in original packaging
Press and hold the stand release button
at the back of the display
Lift the stand assembly up and away
from the monitor
S3
Unlock 4 screws on “R Cear over”
(Screw Torque:8-10Kgf)
S4
Use hands or Bar Scraper to
disassemble Middle “ ” “Rear Cover from
Frame”
Notice the disassembly order:
Left Side=>Top Side =>Right Side
=>Bottom Side
S5
Pull out “C FFC” from ontrol board
“Interface board ” to take off “Rear
Cover”
S6
Tear off 2 tapes from “Rear Cover”
Tear off “Control board FFC” from “Rear
Cover”
Unlock 3 screws to disassemble
“C “ ” ontrol board” from Rear Cover
(Screw Torque: 2.0+0.5 Kgf)
2
D U 5WEBELL 342
S7
Unplug “Control board FFC” from
“C ” ontrol board
Tear off “MYLAR LENS” from “Control
board”
S8
Unplug “Backlight w “ire” from LED
Driver b ” oard (See pink mark)
Unplug “Speaker wire” from “Interface
board” (See red mark)
Tear off 4 tapes from “Speaker wire”
and Panel“ ” (See blue Mark)
Unlock 6 screws to disassemble
“ ” Speaker from “ ” Middle Frame
(See yellow mark)
(Screw Torque: 5~6 Kgf)
S9
Tear off below mylars from “Main
S ” hielding
a. MYLAR BL
b. MYLAR USB
c. MYLAR SPK
d. MYLAR ALS
S10
Unplug “Ambient Light Sensor FFC”
from “Interface board ”
Tear off “Ambient Light Sensor FFC”
from “Main Shielding”
Disassemble “Sensor board” from
“ ” Middle Frame
S11
Unplug FFC”“Ambient Light Sensor
from “Sensor board”
3
D U 5WEBELL 342
S12
Tear off an acetate tape from “USB
board Panel wire” and “ ”
Unplug 2 “USB board FFC” and “USB
B w ” oard ire” from “Interface board
Unlock 1 screw to disassemble “USB
board” from “Middle Frame”
(Screw Torque: 4.5±0.5 Kgf)
S13
Unplug boardall cables from “USB ”
S14
Disassemble a “ ” GASKET from “ ” Panel
S15
Unlock 4 screws to disassemble “Main
Shielding Panel” “from ”
(Screw Torque: 4.5-5.5 Kgf)
S16
Tear off an acetate tape from “FFC
EDP” and “Panel”
Tear off a yellow tape from “FFC EDP”
connector
S17 Unplug “FF “PC EDP” from anel”
