Sida 1/8

DAB Radio Signal

Please notice that DAB signal can be weaken MUCH depending on the type of

building you are living in. (fx. It can be hard to catch proper signal when being in

a concrete building.)

Signal can also be different in different areas of the country. Please check your

local transmitter to get the best signal in your area.

Vær opmærksom på at det kan påvirke DAB signalet MEGET hvilken type

bygning man bor i. Det kan f.eks. være svært at få et ordentligt signal hvis man

bor i beton byggeri.

Der er også forskel på hvor god dækningen er i forskellige områder. Tjek nyeste

dækningskort på www.dabradio.dk under ”hvad er digital radio”.

DAB-35MK2

Instruction manual

ENG-1 ENG-2

BASIC OPERATION - GETTING STARTED

Press the button to turn the unit on, it will automatically enter into the DAB mode and STANDY

perform auto scan function. During the scan, the display show “Scanning…” together with a slide bar

that indicates the progress of the scan and the amount of stations that have been found so far. (F.2)

Once the scan has finished, the radio will select the first alphanumerically found station. You can

select listening to the stations.

Note: If there is no stations found after auto scan, the radio will display "Full Scan", you can now

finally confirm.

F.1 F.2

MENU Tree as below:

Mode Mode

DAB

DAB Menu

Full Scan

Manual Tune

Prune

System

Menu Menu

System Menu

Time

Sleep

Backlight

Factory Reset

SW version

Backlight Menu

Backlight Low/ Medium/ High

Time Menu

Set Time/Date hh:mm/DD-MM-YYYY

Auto Update Update from Any/Update from DAB/Update from FM/ No Update

Set 12/24 hour 12/24

Set Date Format DD-MM-YYYY/MM-DD-YYYY

Sleep Menu

Sleep Off /10/20/30/60/70/80/90minutes

FM Menu

Scan Setting All station/Strong stations only

Audio Setting Stereo Allowed/Forced mono

System

PARTS

Front view Rear view

SWITCHING YOUR RADIO ON FOR THE FIRST TIME

AC Operation

1. Insert the DC power jack of AC/DC adaptor to the DC input socket located at the rear of the

radio.

2. Plug the AC/DC Adaptor to the AC mains outlet.

3. Press the to turn the radio on.STANDBY

Remarks: If the AC Adaptor voltage is over than 6V, it will possible make the line damage.

DC (battery) operation

1. Ensure the AC/DC adaptor is disconnected from the radio and AC mains.

2. Installed the batteries (4×1.5V UM3/AA battery) into the battery compartment.

3. Press the to turn the radio on.STANDBY

Remarks: To obtain the best performance in DC operation, the use of alkaline batteries is highly

recommended.

Menus:

The following controls are used to move about the menu tree to choose and select the required

settings:

button to navigate the desire option, then press button to confirm.SELECT

1. SPEAKER

2. STANDBY BUTTON

3. MODE BUTTON

4. LCD DISPLAY

5. TUN/CH▼ BUTTON

6. TUN/CH▲ BUTTON

7. ALARM/SNOOZE BUTTON

8. MENU/INFO BUTTON

9. VOLUME CONTROL

10. SELECT BUTTON

11. PRESET BUTTON

12. ROD ANTENNA

13. DC INPUT SOCKET

14. RATING LABEL

15. HEADPHONE JACK

16. BATTERY DOOR

17. AC/DC ADAPTOR

No function

DENVER DAB-35MK2

ENG-3 ENG-4

FM radio

1. To select FM, press the button, the display will show FM and the frequency.MODE

starts to scan the frequency band, the display will show ‘Scanning …‘(F6), and it will stop

automatically once a station has been found.

0.05MHz. If reception is still poor adjust the position of the antenna or try moving the radio to

another location.

Scan setting

“All stations/Strong stations only”, and then press the button to confirm the setting. SELECT

USING HEADPHONES (not included)

A stereo headphone jack has been provided so that the radio can be used without disturbing others.

Plug in the headphones at the point marked ‘ ’ and adjust the listening volume to your chosen

level. Excessive sound pressure from earphones and headphones can cause hearing loss. The

speakers will not operate when earphones are fitted.

TECHNICAL SPECIFICATION

Rated voltage (adaptor)

Adaptor output

Rated voltage (radio)

Power consumption

Audio output

Radio

Operating conditions Temperature:

Unit dimension :

Weight :

***SPECIFICATION SUBJECT TO CHANGE WITHOUT FURTHER NOTICE.***

RESET

1. If moving the radio to another location in the country the pre-tuned and stored DAB stations

may no longer be available and it will be necessary to reset the radio back to the factory settings.

the button. (F.7), (F.8)SELECT

3. The radio will display “Restarting….” and will then go into standby mode.

Note 1: All stored programmed stations will be lost during reset.

Note 2: Use the battery status without reset function.

DAB Auto Scan

The auto scan will search for the entire DAB Band III channels, After the scan has finished, the first

alphanumerically found stations will be automatically selected.

Menu to select “Full scan”, finally press the button to confirm. The display will show SELECT

“Scanning…” and a pressing slide bar.(F.3)

explore the stations that have been found. When you find a station that you would like to listen,

press the button to confirm.SELECT

DAB Manual tune

select “Manual tune”(F.4). And press the button to confirm. SELECT

their associated frequencies. (F.5)

3. When your desired frequency appears in the display, press the button to listen, the SELECT

name of the station group (ensemble/multiplex) will be displayed.

Manual tune

< 5A 174.928MHz >

F.5

DAB

< Manual tune >

F.4

DAB

< Full scan >

F.3

92.75MHz

Scanning . . .

F.6

System

< Factory Reset >

Factory Reset ?

< No > Yes

F.7

F.8

AC 100 – 240V~ 50/60Hz, 0.2A

DC 6V 1A

DC 6V (1.5V x 4 AA)

6 W

2 W RMS

DAB 174-240MHz

FM 87.5-108MHz

5°C to 35°C

Humidity 5% to 90%

190 (L) × 110(W) × 115 (H) mm

0.8kg

DENVER DAB-35MK2 DENVER DAB-35MK2
