Sida 1/25

User manual

SCO-85351 THOR

facebook.com/denverelectronics

Before operating this vehicle, read all the instructions for safe assembly and operations. User’s manual can guide you

through the functions and usage of Electric scooter. Before using this Electric scooter, familiarize yourself with how to

operate, so that you can keep the Electric scooter in the best condition possible.

This appliance can be used by children aged from 14 years and above and persons with reduced physical, sensory or mental

capabilities or lack of experience and knowledge if they have been given supervision or instruction concerning use of the

appliance in a safe way and understand the hazards involved.

Children shall not play with the appliance.

Cleaning and user maintenance shall not be made by children without supervision.

Version 1.0




Table of Contents

About the product .................................................................................................................................. 3
Product and Accessories ......................................................................................................................... 5
Unfolding and folding the scooter .......................................................................................................... 6
Assembling the device ............................................................................................................................ 8
Charging the scooter ............................................................................................................................... 8
Intended Use ........................................................................................................................................... 9
Safety Instruction .................................................................................................................................... 9
Maintenance ......................................................................................................................................... 10
Operational control .............................................................................................................................. 13
Electric scooter riding ........................................................................................................................ 14
List of parameters ............................................................................................................................. 16
Electric scooter safe parking ............................................................................................................. 17
Safe transportation ........................................................................................................................... 17
Warnings ........................................................................................................................................... 17






1 About the product

Important!

This electric scooter must be charged and stored in a safe way.

For safety reason and protect battery life, never charge the electric scooter in temperatures below 5°C

or above 45°C. Equally, always disconnect the electric scooter with the power cable once fully charged.

Always use the supplied power adapter to charge the electric scooter.

Make sure that all screws are properly tightened to avoid unsafe situations.

In case you ride in rain or wet conditions then make sure to dry the wooden pedal board with a cloth

top and bottom when done riding.

WARNING

● Please make sure to check that the steering system is correctly adjusted and that all connection

components are firmly secured and not broken before riding, refer to handlebar assembly and

safety instruction.

● Please read operation guide and warnings of correct techniques for use and braking

● Always wear shoes.

● When self-locking nuts and other self- locking fixings may lose their effectiveness.

● All parts and materials of electric scooter cannot be changed, modifications are not allowed.

1.1 Technical modifications

Avoid removal of components or any kind of technical modification to the scooter in order to preserve

the vehicle in approved condition. Specifically avoid modification of the following technical systems of

the scooter:

- Powertrain system

- Battery system

- Braking system

- Steering system

- Lightning system

- Electrical system

- Wheel equipment

- Tyre equipment

- Anti-slip equipment

- Frame structure

Produktspecifikationer

Varumärke:	Denver
Kategori:	Skoter
Modell:	THOR SCO-85351
Inbyggd display:	Ja
Vikt:	14000 g
Bredd:	580 mm
Djup:	1150 mm
Höjd:	1250 mm
Förpackningens bredd:	1175 mm
Laddningstid:	4 h
Batterikapacitet:	7.5 Ah
Rekommenderad ålder (min):	- År
Ursprungsland:	Kina
Modell:	Klassisk sparkcykel
Hopfällbar:	Ja
Hjulmaterial:	Gummi
Rekommenderat kön:	Alla
Produkter per intermodal container (40 fot):	370 styck
Antal hjul:	2 hjul
Batteristorlek:	18650
Produktens färg:	Black, Orange
Produkter per intermodal container (40 fot, HC):	396 styck
Nedfällbarthandtag:	Ja
Låddjup:	240 mm
Vikt inkl. förpackning:	17840 g
Ytterförpackningens bruttovikt:	17900 g
Ytterförpackningens höjd:	565 mm
Produkter per ytterförpackning:	1 styck
Ytterförpackningens längd:	242 mm
Ytterkartong GTIN (EAN/UPC):	5706751046544
Produkter per lastpall:	9 styck
Produkter per lastpallslager:	3 styck
Lastpallens totalhöjd:	1840 mm
Lastpallens totallängd:	1200 mm
Lager per lastpall:	3 styck
Lastpallens bruttovikt:	176000 g
Ytterförpackningens bredd:	1175 mm
Ytterförpackningar per lastpall:	1 styck
Lastpallens nettobredd:	800 mm
Lastpallens nettodjup:	1200 mm
Lastpallens nettohöjd:	1840 mm
Skyddsfunktioner:	Stänkskyddad
AC-inspänning:	230 V
Internationellt skydd (IP) kod:	IPX4
laddningsbart batteri:	Ja
Batterispänning:	36 V
Maximal lastvikt:	120 kg
Ram material:	Gjuten aluminium
Pallens nettovikt:	161000 g
Maximal hastighet:	20 km/t
Hjul typ:	Uppblåsbara däck
Sträcka per batteriladdning (max):	20 km
Sits inkluderad:	Nej
Bakbromsar:	Trumbroms
Maximalt antal staplade kartonger:	3 styck
Stötabsorberande:	Ja
Framhjulets storlek (imperial):	8.5 "
Bakhjulets storlek (imperial):	8.5 "
