Sida 1/29

dLAN®

duo

While the information in this manual has been compiled with great care, it may not be deemed an assurance of product char-

acteristics. devolo shall be liable only to the degree specified in the terms of sale and delivery.

The reproduction and distribution of the documentation and software supplied with this product and the use of its contents is

subject to written authorization from devolo. We reserve the right to make any alterations that arise as the result of technical

development.

You can find all declarations and certifications of compliance for the products, as long as they were available at the time of

publication, in the appendix of this documentation.

Trademarks

Windows® and Microsoft® are registered trademarks of Microsoft, Corp.

Mac® is a registered trademark of Apple Computer, Inc.

Linux® is a registered trademark of Linus Torvalds.

HomePlug® is a registered trademark of HomePlug Power Alliance.

dLAN

® is a registered trademark of devolo AG.

devolo and the devolo logo are registered trademarks of devolo AG. All other names mentioned may be trademarks or regis-

tered trademarks of their respective owners.

Subject to change without notice. No liability for technical errors or omissions.

devolo AG

Sonnenweg 11

52070 Aachen

Germany

www.devolo.com

Aachen, May 2006

| devolo dLAN duo |

Preface

Thank you for placing your trust in this devolo product.

The devolo dLAN duo is a HomePlug adapter for data communications over the

household electrical power supply network. With its Ethernet and USB ports, the

dLAN adapter lets you set up or expand a home network easily and economi-

cally. Functions such as copying or moving files, using shared printers or access

ing the Internet are all realized via existing power lines in your home. With the

dLAN duo, any electrical socket in your home can be used as a network connec-

tion—from the basement to the attic.

About this manual

This manual contains all the information you need about your dLAN duo from

devolo. It tells you how to set up and install your dLAN adapter. The 'All about

the home network' chapter also contains examples of applications for the dLAN

duo and general information on networks.

Exacting manufacturing standards and stringent quality control are the basis for

high product standards and consistent quality to ensure your fullest satisfaction

with this dLAN duo.

This documentation was compiled by several members of our staff from a variety

of departments in order to ensure you the best possible support when using your

product.

Additional information in the Internet at 'www.devolo.com'

Our online services (www.devolo.com) is available to you around the clock

should you have any queries or require any further support.

Package contents

Please ensure that the delivery is complete before beginning with the installation

of your dLAN duo:

dLAN duo

Ethernet cable (3 m)

USB cable (5 m)

Printed information leaflet

CD with drivers, online documentation and application software

devolo reserves the right to change the package contents without prior notice.

Introduction |

| devolo dLAN duo |

1.2 What does the dLAN duo offer you?

Powerful and flexible

Ethernet or USB? This question no longer arises with the dLAN duo. Featuring

both Ethernet and USB ports, the dLAN duo combines the features of dLAN Eth-

ernet and dLAN USB devices. The result is new freedom and flexibility: it's no

longer necessary to settle on one or the other connection technology. For exam-

ple, PCs or laptops can be integrated into a dLAN network using either of the

ports—depending on which one is available.

You can find examples of possible networks and general information in the

chapter 'All about the home network'.

Simple installation

Connect the dLAN duo to the computer or the device with the Ethernet or

USB cable

The dLAN duo can be connected either via Ethernet or USB ports. If both are

installed, USB has priority.

Connect the dLAN duo to the power outlet

Install the devolo drivers (for USB connection)

Install the devolo dLAN Software

Done!

Ethernet and USB port

The dLAN duo has

an Ethernet port for connecting to a device in the home network (e.g. PC,

notebook, modem, router, switch etc.),

a USB port for connection to a computer in the home network with a USB

port,

a standard power plug for connection to a power outlet.

Status display

The indicator lights (LEDs) of your dLAN duo show the connection status and

allow the data transmission to be checked. The dLAN duo has 6 indicator lights.

| Connection and installation 9

| devolo dLAN duo |

2 Connection and installation

This chapter shows you how to connect the devolo dLAN duo. It also contains a

brief description of the installation procedure under Windows 98, Windows Me,

Windows 2000 and Windows XP.

2.1 System requirements

Your computer must meet the following requirements to operate with your dLAN

duo:

Operating systems: Windows 98, Windows Me, Windows 2000, Win-

dows XP, Linux, Mac OS X (only for Ethernet connection) or any other oper-

ating system with network support

Ethernet port

Note that your computer or the device to which you want to connect the dLAN

duo must have an Ethernet port, i.e. a network card or a network adapter

USB port

Note that the computer to which the dLAN duo is to be connected must have a

USB port.

Connection and installation |

| devolo dLAN duo |

2.2 Connection and display elements

The dLAN duo adapter has six indicator lights (LEDs) as well as an Ethernet and

a USB port:

ETH/USB

100/Act: Lit while 100 Mbps data transfer rate is active.

10/Act: Lit while 10 Mbps data transfer rate is active.

USB: Steady when connected to USB.

dLAN

Power: Steady when connected to power.

Act: Flashes when data is being sent or received over the electrical

lines.

Link: Steady when connected to the dLAN network.

Ethernet port: This is the connection point on the dLAN duo adapter for

connecting it to a computer or another device with the network cable

(included).

USB port: This is the connection point on the dLAN duo adapter for con-

necting it to a computer with the USB cable (included).

Make sure that all of the dLAN adapter that you want to add to your network

are also connected to the power supply grid. If no active device is connected to

the Ethernet or USB port, a dLAN adapter will go into standby mode after about

15 minutes. It cannot be configured while in standby mode.

| All about the home network 15

| devolo dLAN duo |

3.3 Home networking—option 3

Networking several workstations with one Internet connection over a dLAN DSL

router

3.4 Home networking—option 4

Networking several workstations with one Internet connection over a dLAN

ISDN router

devolo dLAN ADSL Modem Router

devolo dLAN ISDN Router

All about the home network |

| devolo dLAN duo |

3.5 Worth knowing

Network traffic – The maximum number of dLAN adapters that can partici-

pate in a network at the same time is theoretically much higher than the 10

devices recommended for practical reasons.

Compatibility – The dLAN adapters by devolo are compatible to all other

devolo LAN products, to all devices conforming to the IEEE 802.3 standard and

to other HomePlug devices.

Network security – dLAN adapters use internal DESpro encryption to guaran-

tee the security of the network. Individual security settings are managed by the

dLAN configuration wizard. For more information, refer to the chapter on

'devolo dLAN software'.

You can find more answers to frequently asked questions (FAQs) at our home

page www.devolo.com.
