Sida 1/1
Audio
Codec
OPUS 48 kHz, MP3 44.1 kHz, G.722 ADPCM 16 kHz,
G.711 PCMU 8 kHz, G.711 PCMA 8 kHz
MIC
Built-in microphone Yes
Speaker
Max SPL 120dB
Frequency response 350Hz ~ 8KHz
Frequency range
500-2KHZ +-10dB
400-12KHZ +-20dB
Harmonic distortion 0.1@1kHz
Signal to noise ratio 91dB
Amplifier Built-in 30W amplifier
Network
Security
Password protection, IP address filtering, digest
authentication, user access log
Network protocol
SIP, ONVIF, HTTP/HTTPS, IPv4, DHCP, RTSP, RTP,
RTCP, TCP, UDP, ARP, FTP, TFTP, NFS, NTP
Network interface 10/100 Base-TX, RJ45
VoIP
Support SIP protocol for integration with VoIP
systems, integrated with SIP/PBX
Support SIP features: secondary/backend
SIP server, IPv4
Supported codecs:
OPUS, G711U, G711A, GSM, MP3, WAV
General
Operating temperature -22°F ~ 140°F (-30°C ~ 60°C)
Operating humility 5%-85%
Material ABS (IP66-rated)
Power supply PoE or DC 12V/24V
Interface GPIO alarm in, audio in
Installation Wall mounted
Dimensions
11.22” x 8.07” x 11.22”
(285 x 205 x 285mm)
Weight 4.4 lbs (2 kg)
Warranty 2 years
30-Watt IP-enabled horn speaker
DW-SWSP30AM
Dimensions
Unit: Inch (mm)
Summary
This standalone, 30-Watt, IP-enabled smart audio IP horn speaker helps to
proactively deter crime by responding to real-time events with automated
and manual voice alerts. The IP66-rated housing has a built-in microphone
for two-way communication, alarm input and is ideal for challenging outdoor
environmental conditions with high ambient noise. The speaker supports
digital signal processing (DSP) for clearer sound, has a built-in memory to
support pre-recorded messages, and can play music, loud ringing, voice
paging, and notifications with live speech. The speaker is fully integrated with
DW Spectrum IPVMS and supported IP cameras and can integrate easily
with 3rd party access control, analytics, and VoIP (supporting SIP) via open
standards. The DW smart audio speaker is an ideal, scalable, and flexible
approach to system design and comes with DW’s 2-year warranty.
Features
• All-in-one IP speaker system
• Built-in microphone
• Compatible with IP cameras via DW Spectrum IPVMS
• Compatible with VoIP devices (IPPBX, IP Phone) via SIP
• Built-in 30W output
• Support pre-recorded messages, live responses, alarms and
background music
• Alarm input
• Schedule audio alerts
• Support HTTP API for alarm-in transmit
• Web server built-in
• Simple installation with PoE
• ONVIF conformant
• PoE Class 3 and DC12V-24V
• Wall mount bracket included
• IP66 environmental-rated dust-tight and water-resistant
• 2 year warranty
Specifications
Copyright © DW. All rights reserved. Specifications and pricing subject to change without notice.REV. 05/24
: 866.446.3595
: sales@digital-watchdog.com
: www.digital-watchdog.com
