Sida 1/4



ContactDetails



Pleasenotethatsomeofthecontactdetailson

thisPDFdocumentmaynotbecurrent.



Pleaseusethefollowingdetailsifyouneedto

contactus:



Telephone:08448793588

Email:customer.services@gdcgroup.co.uk



Thecustomersupportsectionofourwebsitealsofeaturesawide

rangeofinformationwhichmaybeofusetoyouandisavailable

24hoursaday.Itincludes:



• Operatingandinstallationinstructions

• Easy‘Howtouse’guidesforstorageheaters

• Serviceandrepairs

• Where

tobuyourproducts

• Literaturedownloads

• Heatingrequirementcalculator



Visit‐www.dimplex.co.uk/support

A division of GDC Group Ltd

Millbrook House Grange Drive Hedge End Southampton SO30 2DF

www.dimplex.co.uk

istered No: 1313016 En

land

VAT GB 287 1315 50004

EEE Producer Registration Number –

WEE/GE0057TS

Paper from sustainable sources

Table1

Model Rails Watts Weight (kg)

TDTR 175C 12 120 6

TDTR 175W 12 175 6

TDTR 350C 18 250 11

TDTR 350W 18 350 11

Important Safety Advice

WARNING - THE SURFACE OF THIS RADIATOR CAN BE HOT.

In order to be effective the towel rail will get hot, however

momentary contact with any part of it should not cause

injury.

The heater is to be installed so that switches and other

controls cannot be touched by a person in the bath or

shower

CAUTION - This appliance is not intended for use by

chidren or other persons without assistance or

supervision if their physical, sensory or mental

capabilities prevent them from using it safely. Children

should be supervised to ensure that they do not play

with the appliance.

Precautions should be taken to ensure that prolonged

contact with the towel rail cannot occur. Particular

care should be taken in confined areas where

accidental prolonged contact with the rail could be

more likely to occur.

This appliance should only be used to dry fabrics washed

in water using commonly available detergents.

If the supply cord is damaged, it must be replaced by the

manufacturer, its service agent or similarly qualified

persons in order to avoid a hazard.

IMPORTANT - If the towel rail is to be installed in a place

used by the public, a warning notice should be placed

adjacent to the rail advising that the surface can be hot.

WARNING - the towel rail is a sealed unit and is filled and

sealed under controlled conditions. Under no

circumstances should the seal of the unit be

compromised

WARNING - In order to avoid a hazard for very young

children, this appliance should be installed so that the

lowest heated rail is at least 600mm above the floor.

General

The TDTR towel rail is designed to provide an all year round service

for airing towels and articles of clothing. It is not intended to provide

a sole heating service, but the larger model will take the chill off an

average size bathroom, lavatory or en suite. Your rail will be in one

of two sizes and will have either silver chromium plated or white

stove-enamel finish.

No routine maintenance is necessary apart from occasional cleaning.

Both models are splashproof to IPX5 standard.

Electrical

WARNING - This appliance must be earthed

The electrical installation of this towel rail must be carried out by a

competent electrician in accordance with the current I.E.E Regulations

for Electrical Equipment. The towel rail is suitable for use on an A.C.~

electrical supply. Before installation check that the supply voltage

corresponds with that marked on the rail.

IMPORTANT - The wires in the mains lead are coloured in

accordance with the following code:

BLUE - NEUTRAL

BROWN - LIVE

GREEN/ YELLOW - EARTH

As the colours of the wires in the mains lead of this

appliance may not correspond with the coloured markings identifying

the terminals in your plug, proceed as follows:

The wire which is coloured GREEN and YELLOW must be

connected to the terminal in the plug which is marked with the letter

E or by the earth symbol or coloured green or green and yellow.

The wire which is coloured BLUE must be connected to the terminal

which is marked with the letter N or coloured black.

The wire which is coloured BROWN must be connected to the terminal

which is marked with the letter L or coloured red.

This appliance must only be used on A.C. mains supply of 230/240

Volts~.

Installation

If fitted in a room containing a bath or shower, to comply with the

current I.E.E. Regulations, a cable outlet will be

necessary with the supply to the heater controlled by a

double-pole pull-cord switch having a contact separation of 3mm in

each pole. The body of the switch should be situated as to be

normally inaccessible to a person using a bath or shower.

IMPORTANT - Protect the electrical connection whilst

handling the towel rail.

The towel rail must be permanently fixed to the wall using the wall

brackets supplied. The rail must be mounted vertically as shown

observing the minimum clearances stated.

WARNING - The towel rail is heavy. Care must be taken when lifting

and fitting the towel rail.

IMPORTANT : THESE INSTRUCTIONS SHOULD BE READ CAREFULLY AND RETAINED FOR FUTURE REFERENCE

Dimensions

(millimetres)

Installation and Operating Instructions

TDTR Towel Rails

Models : TDTR175C, TDTR175W, TDTR350C & TDTR350W

Fig. 1

08/51397/5 (UK) Issue 5

100 min.

shelf

150

min.

Mode l A B

TDTR 175

610 453

TDTR 350

843

602

Wall mounting

The wall mounting accessory pack contains:

TDTR175 & (a) 4 mounting brackets

TDTR350 Models: (c) 4 wall mounting screws/washers/wall plugs

(d) 4 depth adjusting screws

Procedure for wall mounting

Note: TDTR 175 can be fitted in arrangement (1) or (2) from below

Fig. 2, using either three or four wall mounting brackets. Four brackets

must be used on the TDTR350 models

Step 1

Mark suitable mounting hole positions for the fixing brackets (ensuring

they are horizontal) - see Fig. 2, ensure to allow enough room above

and below to maintain the minimum clearance stated.

Step 2

Drill and plug the wall to suit - see Fig. 3.

Step 3

Secure the outer wall bracket sleeves (a) to the wall using the

screws provided - see Fig. 3.

Step 4

Attach the inner wall bracket sleeves (b) to the towel rail with the

clamping pieces (c & d) and screw (e) as shown in Fig. 4.

Ensure the clamping pieces are aligned correctly as shown (x & y).

The screw should be left loose enough to allow horizontal adjustment.

Step 5

Align the wall bracket sleeves on the towel rail according to the

dimensions shown in Fig. 2.

Step 6

Lift the towel rail complete with the inner sleeve assembly and align

with the outer sleeve previously fixed to the wall. When all the inner

sleeves are inserted correctly into the outer sleeves, determine the

desired distance of the rail from the wall and secure in place using

the fixing screw (f) - see Fig. 5.

Step 7

Tighten the clamping screws (e) and install the end cap (g) on the

front clamping piece.

Note: to assist with the alignment, the outer sleeve position may be

adjusted using the slot provided.

Drying and Airing Towels

It is recommended that for efficient drying, no more than two layers

of towels or similar fabric should be draped over the rail. Items

should be placed evenly over the whole surface of the rail where

possible.

It is not advisable to leave very damp towels or clothes on the towel

rail when not in use, as this may in time, affect the paint finish.

The rail, although hot to the touch is not hot enough to scorch or burn

fabrics. However, soap and detergents remaining in articles after

washing can cause discoloration. Therefore care should be taken

to thoroughly rinse articles before airing.

Fig. 2

Fig. 3

Fig. 4

A B

TDTR 175 250 390

TDTR 350 380 625

TDTR 175

TDTR 350

(1)

(2)

20mm Max.

Fig. 5
