Sida 1/6
• Do not use Wet/Dry Vacuum as a sprayer.
• Do not direct air at bystanders.
• Keep children away when blowing.
• Wear safety goggles.
DOUBLE INSULATION INSTRUCTIONS
This Wet/Dry Vacuum is double insulated,
eliminating the need for a separate grounding
system. Use only identical replacement parts.
Read the instructions for Servicing Double-
Insulated Wet/Dry Vacuums before servicing. Use
this vacuum as described in this manual. Observe
the following warnings that appear on the motor
housing of your vacuum.
DOUBLE INSULATED–Grounding not
required–When servicing use only identical
replacement parts.
WARNING: To reduce the risk of
electric shock–Do not expose to rain. Store
indoors.
WARNING: For your own safety,
read and understand the operator’s manual.
Do not run unattended. Do not pick up hot
ashes, coals, toxic, flammable, or other
hazardous materials. Do not use around
explosive liquids or vapors.
CAUTION: Do not vacuum drywall
dust, fireplace soot, or ash with standard wet/
dry filter. This type of dust is very fine which
may not be captured by the filter and cause
damage to motor.
WARNING: Servicing of double-
insulated wet/dry vacuum–With a double-
insulated wet/dry vacuum, two systems of
insulation are provided instead of grounding.
No grounding means is provided on a double-
insulated appliance, nor should a means
for grounding be added. Servicing a double
insulated wet/dry vacuum requires extreme
care and knowledge of the system and should
be done only by qualified service personnel.
Replacement parts for a double-insulated
wet/dry vacuum must be identical to the parts
they replace. Your double-insulated wet/
dry vac is marked with the words ‘DOUBLE
INSULATED’ and the symbol
(square
within a square) may also be marked on the
appliance.
5 GALLON
WET/DRY VACUUM
USER MANUAL
IMPORTANT: READ ALL INSTRUCTIONS CAREFULLY BEFORE ASSEMBLY AND USE.
This product is intended for Household use only. If used Commercially warranty is VOID.
©2024 Techtronic Floor Care Technology Limited. Distributed by, Royal Appliance Mfg. Co. Charlotte, NC 28262. 961152311-R0
IMPORTANT SAFETY INSTRUCTIONS
SAVE THESE INSTRUCTIONS
READ ALL SAFETY WARNINGS AND INSTRUCTIONS BEFORE USING THIS PRODUCT.
WARNING: To reduce the risk of fire,
electric shock, or injury:
• Do not run vacuum unattended.
• Do not use to pick up flammable or combustible
liquids, such as gasoline, or use in areas where
they may be present.
• Do not vacuum, or use this vacuum near
flammable liquids, gases, or explosive vapors
like gasoline or other fuels, lighter fluids,
cleaners, oil-based paints, natural gas,
hydrogen, or explosive dusts like coal dust,
magnesium dust, grain dust, or gun powder.
Sparks inside the motor can ignite flammable
vapors or dust.
• To reduce the risk of health hazards from vapors
or dusts, do not vacuum toxic materials.
• Do not use or store near hazardous materials.
• Do not pick up anything that is burning or smoking,
such as cigarettes, matches, or hot ashes.
• Do not expose to rain. Store indoors.
• If vacuum is not working as it should, has been
dropped, damaged, left outdoors, or dropped
into water, return it to a service center.
• Do not unplug by pulling on cord. To unplug,
grasp the plug, not the cord.
• Do not use with damaged cord or plug.
• Do not pull or carry by cord, use cord as a
handle, close a door on cord, or pull cord around
sharp edges or corners.
• Keep cord away from heated surfaces.
• Do not run the vacuum over cord.
• Do not handle plug or vacuum with wet hands.
• Do not use without dust bag and/or filters in
place.
• Do not allow to be used as a toy. Close attention
is necessary when used by or near children.
• To reduce the risk of injury from accidental
starting, unplug power cord before changing or
cleaning filter.
• Do not leave vacuum when plugged in. Unplug
from outlet when not in use and before
servicing.
• Turn o all controls before unplugging.
• Unplug before connecting or disconnecting
hose, or any other accessories.
• Do not put any object into openings. Do not use
with any opening blocked; keep free of dust,
lint, hair, and anything that may reduce air flow.
• Keep hair, loose clothing, fingers, and all parts
of body away from openings and moving parts.
• Use extra care when cleaning on stairs.
• Use only as described in this manual. Use only
manufacturer’s recommended attachments.
• This vacuum is provided with double insulation.
Use only identical replacement parts.
DOUBLE INSULATION INSTRUCTIONS.
• Local regulations or bylaws may determine the
minimum age for using the device.
• Children must be supervised in order to ensure
that they do not play with the equipment.
• Do not lift or transport the tool while the motor
is running. Turn the tool o and wait for the
tines to stop moving, then disconnect the tool
from the mains before changing the area you
are working on.
• If the connecting cable to this equipment
is damaged, it must be replaced by the
manufacturer, the customer service of the
same, or a similarly qualified person in order to
avoid hazards.
CAUTION: To reduce the risk of injury
from moving parts–Unplug before servicing.
WARNING: To reduce the risk of electric
shock–Unplug before cleaning or servicing.
WHEN USING AS BLOWER:
• Direct air discharge only at work area.
Contact Dirt Devil
®
Support for
assistance with your pressure washer
.
DO NOT
RETURN TO STORE
Chat with us!
dirtdevil.com/pages/ddcontact
Every day 8am-8pm EST
GENERAL ASSEMBLY
INSTRUCTIONS
A Philips head screw driver is required.
WARNING: DO NOT PLUG THE POWER
CORD INTO A POWER OUTLET. MAKE SURE THE
PLUG IS DISCONNECTED BEFORE ASSEMBLING
THE WET/DRY VACUUM. TO REDUCE THE RISK OF
ELECTRIC SHOCK, DO NOT EXPOSE TO RAIN.
7
8
9
10
6
5
1
2
1.
Verify that the power cord is disconnected from
the outlet.
7
8
9
10
6
5
1
2
2.
Undo the latches.
7
8
9
10
6
5
1
2
3.
Lift the power head o the collection tank.
7
8
9
10
6
5
1
2
4.
Remove the contents from inside the collection
tank. Make sure you have all contents.
7
8
9
10
6
5
1
2
5.
Turn the collection tank upside down and insert
the four casters into the slots on the bottom
of the collection tank. Ensure each caster is
aligned straight into the collection tank and apply
pressure until the casters snap into place.
6
6.
Insert the handle into the slots located on the top
of the power head and secure it with the screws
provided. Do not over-tighten the screws.
7.
Your vacuum comes ready for dry vacuum
cleaning. If the reusable cloth filter is not
installed.
7
8
9
10
6
5
1
2
8.
For wet vacuum cleaning, remove the reusable
cloth filter, and install the supplied foam wet
filter. Refer to the foam wet filter installation
instructions.
7
8
9
10
6
5
1
2
9.
Place the power head back on the collection tank,
aligning the top section with the latches, and
snap into place.
SYMBOLS
The following signal words and meanings are intended to explain the levels of risk associated with this product.
SYMBOL SIGNAL MEANING
DANGER:
Indicates a hazardous situation, which, if not avoided, will result in death or serious
injury.
WARNING:
Indicates a hazardous situation, which, if not avoided, could result in death or
serious injury.
CAUTION:
Indicates a hazardous situation, that, if not avoided, may result in minor or
moderate injury.
NOTICE:
(Without Safety Alert Symbol) Indicates information considered important, but not
related to a potential injury (e.g. messages relating to property damage).
EXTENSION CORDS
When using an extension cord with your Wet/Dry Vacuum refer to the following table to determine the
required A.W.G. wire size. Before using the vacuum make sure the power cord and extension cord are
in good working condition. Make repairs or replacements before using the vacuum cleaner. Only use
extension cords that are rated for outdoor use.
Length of Extension Cord
120V 25ft (7.62m) 50ft (15.24m) 100ft (30.48m) 150ft (45.72m)
Ampere rating
A.W.G. Wire Size
More than Not more than
0 6 18 16 16 14
6 10 18 16 14 12
10 12 16 16 14 12
12 16 14 12 Not recommended
UNPACKING & CHECKING
CARTON CONTENTS
Fully assemble product prior to use.
Remove all contents from the box. Remove the
power head and take out any contents inside
the collection tank. Check each item against the
carton contents list.
CARTON CONTENTS LIST:
Key Description ......................................... Qty
A Vacuum Assembly..........................................1
B Handle ............................................................. 1
C Hose .................................................................4
D 2-in-1 Utility Nozzle ...................................... 1
E Caster ..............................................................2
F Extension Wand ..............................................1
G Floor Brush/Squeegee Nozzle ...................... 1
H Noise Diuser .................................................1
I Reusable Cloth Filter ..................................... 1
J Foam Wet Filter .............................................. 1
K 2 Screws (Bag) ...............................................1
L Operator’s Manual ..........................................1
NOTE: The hose and accessories for this vacuum
are 1-1/4’’ (3.2 cm) diameter.
C
B
E
D
G
K
H
I
J
F
A
L
Blower Port
Accessory
Storage
Latch
Caster
Power Head
Handle
On-Off Switch
Vacuum Port
Collection Tank
