Sida 1/6
This document is to be used in conjunction with the original manufacturer’s manual.
The symbols correspond with the numbered drawings of the original manual
Contents
GB
05/2024
Fault nding 4
Maintenance 5
Conformity with regulations 6
Introduction 1
Installation 1
Use, safety 2
Cleaning, hygiene and storage 4
1.1
Introduction
1.1 DESCRIPTION
• The automatic French fries cutter is a machine for profesisonal
use that allows obtaining fresh fries of excellent quality and to cut
potatoes in slices.
A Cutter block
B Mobile stainless steel stand (option)
C Polished aluminium body
D Stainless steel feed hopper
E Hopper locking lever
F START button
G STOP button
H Outlet chute
• Thanks to its high output and adapted cutting equipment, the
machine satises the requirements of restaurants, catering
kitchens and food industries.
Installation
2.1
2.1 DIMENSIONS - WEIGHT (For information only)
• Dimensions of packaging:
- machine L x W x H (mm): 755 x 410 x 680
- stand L x W x H (mm): 750 x 500 x 200
• Dimensions of the machine:
- without stand: L x W x H (mm): 670 x 360 x 556
2.2
- with stand: L x W x H (mm): 736 x 458 x 1264
• Weight :
- gross when packaged: 45 kg
- net equipped (with rotor and without cutting equipment): 37 kg
- net of stand: 15 kg
2.2 LOCATION AND LAYOUT
• The machine (whether packed or not) is meant to be lifted
using a forklift truck. If manual handling is going to be used for
the machine on its own, two people are needed (for all machines
weighing more than 25 Kg)
• On a table of between 600 and 750 mm maximum in height.
• On a stand (available as an option) which can hold large capacity
collection tubs.
• To block and level the stand:
- Unscrew the lock screw on the two adjustable feet (10 mm
socket spanner).
- Adjust the foot then lock in position.
- Check that the machine is stable.
• If necessary, anchor the stand in position:
- Counter drill the attachment holes of the feet (5 mm dia.
screws x 40 mm long and rawl plugs not supplied).
Introduction
The User Manual contains useful information for the user on how
to work correctly and in complete safety, and is designed to make
it easier to use the machine (called «machine» or «appliance»
below).
What follows is in no case intended to be a long list of warnings and
constraints, but rather a series of instructions meant to improve the
service provided by the machine in every respect, and particularly
to avoid a series of injuries or damage to equipment that might
result from inappropriate procedures for use and management.
It is essential that all the people responsible for transporting,
installing, commissioning, using, maintaining, repairing or dis-
mantling the machine should consult this manual and read it
carefully before proceeding with the various operations, in order
to avoid any incorrect or inappropriate handling that might be
result in damage to the machine or put people’s safety at risk.
It is just as important that the Manual should always be available
to the operator and it should be kept carefully where the machine
is used ready for easy and immediate consultation in case of any
doubt, or in any case, whenever the need arises.
If after reading the Manual, there are still any doubts concerning
how to use the machine, please do not hesitate to contact the
Manufacturer or approved After Sales Service provider, who is
constantly available to ensure quick and careful service for im-
proved machine operation and optimum eciency.
Note that the safety, hygiene and environmental protection stan-
dards currently applicable in the country where the machine is
installed must always be applied during all phases of machine
operation. Consequently it is the user’s responsibility to ensure
that the machine is operated and used solely under the optimum
safety conditions laid down for people, animals and property.
1 RC14 GB 02 2016
The reference language for these instructions is French.
