Zenmuse Z15-5D III (HD)
2015.09
V1.4
User Manual
2
©2014 DJI. All Rights Reserved.
Warning & Disclaimer
Do not modify or adjust the Z15-5D III (HD).
The Z15-5D III (HD) gimbal has been calibrated specically for the designated camera and lens before it
leaves the factory. Please mount only the designated camera and lens to the Z15-5D III (HD). No adjustments
or modications are needed. Do not add any other component/device (such as lters, lens hood, etc.) to
the camera. Please use the original camera battery, otherwise performance may be hindered and internal
malfunctions or damage may occur.
Only use the Z15-5D III (HD) gimbal with Flight Control Systems developed by DJI (such as the A2 or
WooKong-M, and for the greatest stability and precision. Please please upgrade to the latest firmware)
download the corresponding Assistant software and upgrade your Flight Control System’s Main Controller
firmware, otherwise the Z15-5D III (HD) may not function properly. When the main battery power is
connected, please be careful and operate the Flight Control System in the safest way possible. It is strongly
recommended that you remove all propellers, use the R/C or ight pack battery power system, and keep
children away during gimbal calibration and parameter setup. Carefully follow the appropriate steps to mount
and connect the gimbal to your aircraft. Use this manual as well as the related Assistant software. Please
respect the AMA’s National Model Aircraft Safety Code.
As DJI has no control over the use, setup, final assembly, modification (including use of non-specified
DJI parts i.e. motors, ESCs, propellers, etc.) or misuse, no liability shall be assumed nor accepted for any
resulting damage or injury. By the act of use, setup or assembly, the user accepts all resulting liability. DJI
assumes no liability for damage(s) or injuries incurred directly or indirectly from the use of this product.
DJI and Zenmuse are registered trademarks of DJI. Names of products, brands, etc., appearing in this
manual are trademarks or registered trademarks of their respective owner companies. This product and
manual are copyrighted by DJI with all rights reserved. No part of this product or manual shall be reproduced
in any form without the prior written consent or authorization of DJI.
Manual Tips
Legend
Important Tips
Designated Camera and Lens Type for the Z15-5D III (HD) Gimbal
Camera Type：Canon 5D Mark III
Lens Type：Canon EF 24mm f/2.8 IS USM
Firmware versions of supporting DJI Flight Control Systems
WooKong-M： V5.26 A2: V2.1 or above
©2014 DJI. All Rights Reserved.
3
Product Prole
The Z15-5D III (HD) is a sophisticated gimbal specifically designed for aerial creativity. It has a built-in
independent IMU module, special servo drive module, HDMI-HD/AV module, and more. The Z15-5D III (HD)
performs well in all modes, including Orientation-locked, Non orientation-locked, and FPV (Reset).
Working Modes
Orientation-locked Non orientation-locked FPV (Reset)
Gimbal Direction Gimbal pans with aircraft
nose.
Gimbal pan and aircraft
nose move separately.
Gimbal pan and
aircraft nose are
synchronized.
Gimbal and Aircraft
Nose Relative
Angle
The gimbal direction
maintains the same relative
angle to the aircraft nose.
The relative angle
between the gimbal
direction and aircraft
nose is controllable.
The relative angle
between the gimbal
direction and aircraft
nose is 0°.
TX Control Controllable Controllable Uncontrollable
Attitude Stability* YES YES YES
Vibration Reduction YES YES YES
Stick Movement
Denition
The command stick controls
gimbal rotation velocity.
The stick center position
is 0°/s, and its endpoint is
maximum velocity.
Stick commands for
gimbal rotation velocity
are relative to total stick
movement. The stick’s
center position velocity
is 0°/s. Its endpoint is the
maximum velocity.
——
Command Linearity YES YES ——
Note*: Attitude stability means that the gimbal’s ROLL/TILT will not follow the aircraft’s ROLL/PITCH
movement.
Product Prole
