Installation Manual

IP Video Door Station

D10x Series

Seite 20-39

Installationsanleitung

IP Video Türstation

D10x Serie

Page 40-58

Manuel d´installation

Interphone vidéo IP

Série D10x

D10X

INSTALLATION MANUAL

Read these instructions carefully before starting to use any components.

Keep the manual so you can refer to it at a later date if required. If you hand

over the device to other persons for use, please hand over the operating

manual as well.

You can always ﬁnd the most up-to-date version of the installation manual

on www.doorbird.com/support

To make things easier we use the term “device” for the product “IP Video

Door Station” and “mobile device” for a smartphone or tablet.

Liability

Every care has been taken in the preparation of this document.

Please inform Bird Home Automation GmbH of any inaccuracies or omissions.

Bird Home Automation GmbH cannot be held responsible for any technical

or typographical errors and reserves the right to make changes to the product

and manuals without prior notice. Bird Home Automation GmbH makes no

warranty of any kind with regard to the content of this document, including,

but not limited to, the implied warranties of merchantability and ﬁtness for

a particular purpose. Bird Home Automation GmbH shall neither be liable

nor responsible for incidental or consequential damages in connection with

the furnishing, performance or use of this material. This product is only to

be used for its intended purpose.

Equipment Modiﬁcations

This equipment must be installed and used in strict accordance with the

instructions given in the user documentation. This equipment contains no

components that require service by the user. Unauthorized equipment

changes or modiﬁcations will invalidate all applicable regulatory certiﬁcations

and approvals.

Symbols used

Caution: Indicates a hazardous situation which, if not avoided,

could result in minor or moderate injury.

Danger: Indicates a hazardous situation which, if not avoided,

will result in death or serious injury.

Warning: Indicates a hazardous situation which, if not avoided,

could result in death or serious injury.

ENGLISHENGLISH

Notice: Indicates a situation which, if not avoided, could result

in damage to property.

Note: Indicates useful information which helps in getting the

most out of the product.

NOTICE

Hazard information

• Mounting, installation and servicing work on electrical devices may

only be performed by a qualiﬁed eletrician. Failure to observe this

regulation could result in the risk of serious damage to health or fatal

injury due to electric shocks.

• Devices with 110-240 V connection: The device may only be connected

to an easily accessible power socket outlet. The mains adapter must

be pulled out if a hazard occurs.

• For power supply, only use the original plug-in mains adapter

delivered with the device or a recommended PoE-Switch/PoE-Injector

as speciﬁed in this manual.

• Because of electrostatic charging, direct contact with the circuit board

can result in destruction of the device. Direct contact with the circuit

board must therefore be avoided at any time.

• Observe the EN 60065 resp. EN 60950 resp. EN 62368 standard.

• Do not use the device if there are signs of damage to the housing,

control elements or connecting sockets, for example, or if it

demonstrates a malfunction. If you have any doubts, please have

the device checked by an authorized expert.

• Do not open the device. This voids the warranty of the device. The

device does not contain any parts that can be maintained by the

user. In the event of an error, please have the device checked by an

authorized expert.

• For safety, approval and licensing reasons (CE/FCC/IC etc.),

unauthorized change and/or modiﬁcation of the device is not

permitted.

• The device is not a toy; do not allow children to play with it. Do not

WARNING

Important: Indicates signiﬁcant information which is essential

for the product to function correctly.
