Sida 1/11

DRS Rail System

For 2-1/2”, 3-5/8”, 4”, 6”, and 10” DRS Rail Systems

Installation instructions

934806 – 04-2021

| | EN

2DRS Rail Systems 04-2021934806

dormakaba DRS Rail Systems Installation Instructions

Table of Contents

Table of contents

1 Technical specifications 3

1.1 Overview 3

1.1.1 General information 3

1.1.2 Intended use 3

1.1.3 Glass requirements/fittings/mounting 3

1.1.4 Requirements for glass panel 3

1.1.5 Safety instructions 3

1.1.6 Symbols used - Safety/Installation 3

1.1.7 Maintenance, care, repair 3

1.1.8 Disposal 3

1.2 Tempered laminate glass (TLG) and

adhesive specifications 4

1.3 Tools recommended 4

1.4 Preparing the glass and rails 4

1.5 System setup 5

2 Installation instructions 6

2.1 Install rails onto glass panel 6

2.2 Install glass door panels and rails into frame:

For use with: RTS88 header and 8852 bottom

pivot 7

2.3 Install glass door panels and rails into frame:

For use with: PT21 (walking beam pivot) and

BTS80 with 7422 bottom arm 8

2.4 Install glass door panels and rails into frame:

For use with: PT21 (walking beam pivot) and

BTS80 with 355.1 insert 9

2.5 Install rail covers and end caps 10

dormakaba DRS Rail Systems Installation Instructions

934806 04-2021DRS Rail Systems 3

Technical specifications

1 Technical specifications

1.1 Overview

These instructions are for installation of the DRS Rail

System for the following mounting and style versions:

1. Glass mounting

1.1.1 General information

• dormakaba requires use of tempered laminated or

tempered monolithic glass.

• dormakaba glass hardware is not suitable for harsh

environment; for example, applications where

chemicals (e.g. chlorine) are used such as indoor

swimming pools, saunas, or salt-water pools.

• Do not swing doors with excessive force. Install

limiting stop to prevent door from opening too far.

• If an impenetrable door panel material is chosen to

be used for additional security purposes, then the

two outermost bolts on each rail can be also be

reversed, to hinder attempted disassembly after

installation.

1.1.2 Intended use

• For pivoting doors in indoor or covered areas only.

• For automatic or manual slow opening and closing.

1.1.3 Glass requirements/fittings/mounting

• The substructure/wall must be able to bear

permanent loads, be level (max. tolerance: 1/16”

[2] per 39” [1m]).

• Fasteners must be sufficiently dimensioned for the

substructure/wall and weight of the door.

• When adjusting glass components, always stick to

the required clearance for the respective hardware.

Adjust clearance so glass does not come in contact

with any hard surfaces such as glass, metal or

concrete.

• Do not use excessive force when installing the glass

(avoid over tightening screws.)

1.1.4 Requirements for glass panel

• dormakaba requires use of fully tempered glass,

which complies with ASTM C 1036 and ASTM C

1048. Secondary heat soaking processes are

optional but not required. This applies to both

tempered monolithic and tempered laminated

glass.

• Clamping area must be flat and uncoated (no

self-cleaning coating!)

• Never use glass with conchoidal fractures and/or

damaged edges.

1.1.5 Safety instructions

• Installation requires two people.

• Always wear protective clothing.

• Only properly qualified and specially trained staff is

authorized to mount dormakaba glass hardware.

• Due to crushing hazards and possible injury caused

by breakage of glass during mounting,

corresponding protective clothing (especially gloves

and protective goggles) is required.

• Never clamp metal fitting hardware directly to

glass surface.

1.1.6 Symbols used - Safety/Installation

CAUTION

Mounting components must meet the

requirements of substructure/wall and door

weight. Please read the technical information

for fittings.

WARNING

Risk of breaking glass. When installing the

door, support the door panel with a block of

wood or similar object.

1.1.7 Maintenance, care, repair

• Immediately replace damaged parts.

• Always use original dormakaba parts.

• Clean clamping area with alcohol-based standard

commercial cleaning agent before mounting the

glass hardware.

• Use a damp cloth for occasional cleaning.

• Always use silicone - and oil-free cleaners (e.g.

acetone).

• Check glass hardware at regular intervals for

proper positioning, smooth operation and correct

adjustment.

• High traffic door systems require inspection by

properly qualified staff (specialized companies or

installation firms.)

• Function of fittings is recommended to be

inspected every 500,000 movements by a specialist.

1.1.8 Disposal

Disposal in accordance with local, state and national

regulations.
