Subject to change without notice

HSB-E07 sensor barriers

Moderate

Standard unitsHSB-E07

Note: Description of single unit

Interlock height

37-3/16" (945)

Interlock length

65-3/8" (1660)

Passage width

25-9/16" (650)

Total width 42-1/8" (1070)

Housing, base columns,

guiding elements

AISI 304 Ø2-3/8"(Ø60) stainless steel tube with 3/8" (10)

toughened safety glass panel and AISI 304 stainless steel handrail

with integrated sensor system.

ADA compliance36" (915) width available.

Barrier elements

Two door leaves made of transparent polycarbonate,

upper edge 35-7/16" (900)

Swinging area monitored by separation sensors.

SecurityPassage area monitored by basic sensor system with a compact

installation length (basic level of single passage monitoring in

both directions).

FinishStainless steel semi-gloss smooth finish.

SafetyLow energy drive with energy content less than 1.18 lb/ft.

FunctionType 2–power assisted motion; two servo-positioning drives/

electrically controlled in both directions.

DrivesIntegrated in the swing tube.

Operating modesOptical.

Normally closed.

Normally opened. (Barriers close on tailgate event.)

Electrical equipmentControl system and power supply integrated in the unit.

Power supply110 – 230 VAC, 50/60 Hz. 368 VA

Standby power

consumption

17 VA

Standard adjustment in

case of power failure

Door leaves move freely.

InstallationDowelled on finished floor level, FFL.

Not suitable for outdoor installation.

Protection classesHousing IP32, components conducting supply voltage IP42.

65 -3/8"

()1660

35-7/16"

(900)

37-3/16"

(945)

HSB-E07

31-7/8"

(810)

5-1/8"

(130)

5-1/8"

(130)

42-1/18"

(1070)

25-9/16"

(650)

65-3/8"

()1660

Moderate units offer

tailgating monitoring.

Entrance systems
