Interior Glass Systems
HSW-DRS horizontal
sliding glass walls
SUB-STRUCTURE
(OPTIONAL)
G. D.H. = L.O – )6" (152
2-11/16"
(68)
2-11/16"
(68)
2-13/16"
(71)
3-5/8"
(92)
3-5/8"
(92)
2-15/16"
(75)
G.H. 3/8"
(10)
1/4"
(6)
D.L (FINISHED FLOOR BO.O. TO TTOM OF TR K)AC
Versatile HSW-DRS horizontal sliding glass walls offer easy installation & mainte-
nance, plus numerous options for matching the system to your requirements. You
can configure innovative HSW-DRS systems to meet the needs of most demand-
ing projects. With DRS rails top and bottom, this HSW system blends seamlessly
with fixed glass walls and glass sliding or pivoting doors that feature DRS rails.
Panel Limits
• Max height
118" (3000)
•
Max weight
330 lb (150 kg)
•
Min width
24" (600)
•
Max width
42" (1060)
Standard Finishes
• Clear anodized
• Black anodized
• Satin stainless
• Polished stainless
• Satin brass
• Polished brass
Lead Time: 5 weeks
• Suitable for both in line and
curved configurations (com-
prised of straight track
segments) with no floor track.
• Mechanical clamp-on system with
snap-on covers that are
interchangeable in the field.
• System available with vertical
stiles (3-5/8" & 4" rails only).
• All rail sizes available for 3/8"
(10) and 1/2" (12) tempered
monolithic glass.Bottom rail
available in 3-5/8" (92), 4" (102),
6" (152), and 10" (254) heights.
• Panic hardware can be used on
fixed-swing panels when located
opposite the stacking area.
• Can be used with tempered
laminated glass (TLG) using
dormakaba Clamp & Glue
Technology™.
• Panels can vary in width up to 15%.
• Doors can be pre pared for a full
range of dormakaba archi tectural
hardware.
Specifications
90 perpendicular
stack
90 parallel
stack
135 parallel
stack
NOTES
• Common HSW parking examples shown,
other parking options available.
• All measurements are shown in inches
(mm); for example, 3/8" (10)
