INSTALLATION
RCI AH10 / AH20
ARMATURE HOLDER ACCESSORY FOR 8310 / 8320 ELECTROMAGNETIC LOCKS
© 2019 dormakaba Canada Inc
www.dormakaba.us • Phone: 1.800.265.6630 • Fax: 1.800.482.9795 • E-mail: sales_RCI@dormakaba.com
ARM URE BOLTAT
ARMATURE HOLDER
2X STEEL SHERS AND WA
RUBBER SHERWA
(INCLUDED WITH MAGLOCK)
ARM URE PL EAT AT
(INCLUDED WITH MAGLOCK)
TEK™ MOUNTING SCREW
ISAH10-20 PCN18041
R11-19GR-1
Read the Pre-Installation instructions provided with your RCI brand dormakaba Electromagnetic Lock.
Conformance is important.
This accessory provides secure surface mounting when it is not possible to secure the armature mounting bolt through the door.
Each armature holder is fastened to the door with the 8 TEK™ screws provided.
The armature bolt is positioned through the plate and 3 washers.
Thread locking compound is carefully applied to the exposed thread.
The bolt then threads into the armature holder.
NOTE: The 13/32” (10mm) thickness of the armature plate holder must be considered when drilling the frame head to mount the
electromagnetic lock
Instructions
NOTE: Not to scale. Specifications are subject to change without notice.
WARNING: Improper installation, maintenance, inspection or usage of the
product or any related accessories or parts may cause the electromagnetic
lock, armature plate and associated hardware to disengage and fall, causing
serious bodily injury and property damage. dormakaba Canada Inc.
and/or dormakaba USA Inc. will not be liable to the installer, purchaser,
end user or anyone else for damage or injury to person or property due
to improper installation, care, storage, handling, maintenance, inspection,
abuse, misuse or act of God or nature involving this product or any related
accessories or parts.
