Sida 1/4
EN
Original Instructions
Version 3
May 2024
22230
COMBINED
LIVE WIRE,
METAL & STUD
DETECTOR
User Manual for: Combined Live Wire, Metal &
Stud Detector
Stock No: 22230
Part No: D389
Read this manual in full before using this product and
retain it for future use. Always use the latest version of
the manual. Please visit drapertools.com/manuals for
the latest version.
1. Intended Use
This detector is designed to nd hidden live AC wires,
metal, wooden studs through common wall materials.
Suitable for use indoors and outdoors.
Any other application beyond the conditions established
for use will be considered misuse. Draper Tools accepts
no responsibility for improper use of this product.
This product is suitable for use by enthusiasts and
radespersons alike.
– 2 –
EN
1.1 Specication
2. HealthandSafety
Information
Important: Read all the Health and Safety instructions
before attempting to operate, maintain or repair this
product. Failure to follow these instructions may result in
injury or damage to the user or the product.
• Use this product ONLY as instructed in this manual.
CAUTION! Depending on the proximity of
electrical wiring or pipes to the wall surface, the
sensor may detect them as studs. Always take care
when nailing, cutting or drilling into walls, oors
and ceilings as they may contain these items.
• Always turn o the power when nailing, cutting or
drilling near electrical wires.
CAUTION!
− The unit will not detect live wires inside metal
pipes or conduits, behind metallic wall coverings
or other dense materials. Use extra care in these
situations.
− Items that are shielded in some way or more than
38mm from the surface will not be detected.
• DO NOT use this device if the tester is damaged in any
way or if there is evidence of battery leakage.
• The battery must be replaced with one with the same
specication.
• When replacing the battery check that it is tted in
the correct +/- orientation.
• DO NOT dismantle or attempt to repair this unit.
3. ExplanationofSymbols
Read the
instruction manual
European
conformity
Caution!
UK Conformity
Assessed
Do not incinerate
or throw onto re
WEEE – Waste Electrical & Electronic Equipment
Do not dispose of this product with
domestic waste
4.Identication
Carefully remove the product from the packaging and
examine it for any signs of damage that may have
occurred during shipment. If any part is damaged or
missing, do not attempt to use the product.
Please contact the Draper Helpline; contact details can
be found at the back of this manual.
(1) LCD display screen
(2) Mode switch
(3) ON/OFF button
(4) Battery compartment (back of detector)
Stock No. 22230
Part No. D389
Detection distance:
Stud
19mm
Metal
60mm
AC Voltage
51mm
Power Supply:
1 X 9V/PP3 battery
(not supplied)
Dimensions: L 160 X W 69 X H 31mm
Net Weight: 196g
(4)
(1)
(2)
(3)
