Sida 1/11
DVDO-AudioE-1
4K HDMI 2.0b Audio Extractor
User Manual
Version 2 .0
DVDO +1.408.213.6680 │ │ support@dvdo.com www.dvdo.com │
Thank you purchasing -AudioE-1 for DVDO
For optimum performance and safety, please read
these instructions carefully before connecting, operating
or adjusting this product. Please keep this manual for
future reference.
Surge protection device recommended
This product contains sensitive electrical components
that may be damaged by electrical spikes, surges,
electric etc. of shock, strikes, lighting Use surge
protection systems is highly recommended in order
to extend protect and the life of your equipment.
Table of Contents
1. Introduction. ........................................................... 1
2. Features. ................................................................. 2
3. Package Contents. ................................................ 3
4. Specifications. ........................................................ 3
5. Operation Controls and Functions. ...................... 5
5.1. Front Panel. .................................................... 5
5.2. Rear Panel. .................................................... 6
6. Application Example............................................. 7
1/7
1. Introduction
DVDO- -1 is an HDMI 18Gbps Audio AudioE
Extractor that can extract audio signals from any
HDMI compliant source to digital optical or analog
stereo L/R audio outputs. For maximum flexibility,
this audio extractor also supports bitstream audio
down-mix to analog stereo output and keeps optical
and HDMI out audio pass- through. Further, both
input and output HDMI support video resolution up to
4K2K@50/60Hz (YUV444). supports 10bits HDR It
(High Dynamic Range) pass through and HDMI high
resolution digital audio formats bypass, LPCM 2CH,
Dolby TrueHD, Dolby Digital Plus, Dolby Atmos and
DTS-HD Master Audio, audio sampling rate up to
192 kHz. HDCP 2.2 and CEC are bypass
supported.
Manufactured under license from Dolby Laboratories.
Dolby and the double-D symbol are trademarks of
Dolby Laboratories.
