Easypix EasyGuard IP200 Bruksanvisning

Easypix Webbkamera EasyGuard IP200

Läs gratis den bruksanvisning för Easypix EasyGuard IP200 (1 sidor) i kategorin Webbkamera. Guiden har ansetts hjälpsam av 17 personer och har ett genomsnittsbetyg på 5.0 stjärnor baserat på 9 recensioner. Har du en fråga om Easypix EasyGuard IP200 eller vill du ställa frågor till andra användare av produkten? Ställ en fråga

Ladda ner PDF

Sida 1/1

Day & Night IP Camera

001015181

Inter net

NAT/Router

IP Cam

Package and Product View

Step

Power Adapter

LAN

WAN

Lens

Ethernet Indication LED

Status Indication LED

Microphone

IR LED

Light Sensor

Reset Button

Power Jack

Antenna Jack

Bracket screw

Ethernet Jack

NET

IP Camera

Automatic day and night mode switch : the IP cam automatically turns on/off the IR LEDs according to the

status of the built-in light sensor.

Scheduled time of night mode : the IP Cam c an also be scheduled to turn on/off the IR LED s.

Manual night mode control : the IP Cam can b e manually forced to night mode( IR LEDs on ) or day mode(

IR LEDs off ).

There are three ways to control the night mode( IR

LEDs )(On the web page of the IP Cam) :

Make sure you correctly plug in the power adapter and the Ethernet cable. IP Cam will get the IP

address from the NAT/ Router automatically. The diagram above shows you how to connect the

devices correctly.

Check the status indication LED of IP Cam to see if IP Cam is correctly connected. Constant red

light means that IP Cam is working fine. Then, you can move forward to install the CamView ( video

management software). Otherwise, go back to and check it again carefully. If the status

indication LED is still blinking, contact your retailer then.

Step

CamView Software Installation

Before installing CamView on your PC or laptop, please make sure you have correctly installed the

IP Cam. It's highly recommended to close other Windows applications to prevent the installation

from any possible confliction.

Insert the installation CD into your CD-ROM drive and find the CamViewInstaller-xxx.exe.Double

click on it and press “Next” button till the end of the installation.

Note: xxx of CamViewInstaller-xxx.exe is the version number.

The right page “Installation Successful” should be displayed if

everything is correct. If not, re-install it again. Contact your

retailer if it is not working.

Start the CamView application from either

Start->Programs->CamView->CamView or the shortcut on the desktop of the Microsoft windows.

Once the CamView started, it will search all the IP Cam in your

Local Area Network automatically and shows the Cam ID of each of

the found IP Cam in the tree menu-“Auto Search” folder of the

“Cam List” page.

CamView Software Usage

To view the video, simply double-click on the Cam ID which you

want to see or drag the Cam ID to one of the video play windows.

To save the found Cam ID on your PC, simply drag it from “Auto Search” folder to “CameraList”. By doing

so, you can easily play the video without memorizing the Cam ID.

Note:

If the Cam you want to see is outside of your LAN and the Cam ID is not stored in the “CameraList”,

please right-click on the “CameraList”, choose “New Camera” and enter the Cam ID and password.

Note1:

For further operation, please refer to the full-version user manual of CamView.Note2:

Please make sure the Ethernet cable is

connected to the IP Cam.

Start the CamView. In the “Auto Search” folder,

right-click on the Cam ID of the IP Cam that you

want to configure. Click the “Web Configure …”

to open the browser.

Key in the admin account and password,

respectively, to enter the web page of IP Cam.

Click “Save & Apply” to save the configuration.

Click “WiFi Security” in the menu items to see

the current settings of the WiFi.

Click the “WiFi Scan” button, all the available

wireless AP will be listed. Click the AP you want

to use, then key in the encryption key of the

wireless AP.

adm in

Note

Default admin

account is “admin”

and the password

is empty.

Note

You can check the settings to see if they are

correct, go to “WiFi security” page and click the

“WiFi test ” button in bottom right corner. Wait

for about 15 seconds, the result will be

displayed.If it’s failed, please double check the

settings you have entered.

Now you are ready to activate the wireless

connection by plugging off the Ethernet cable

from the IP Cam.

DO NOT plug off the Ethernet

cable during the WiFi testing!

If the Ethernet cable is not

plugged off from the IP Cam,

the wireless function will not

be activated even if you have

enabled it.

Warning

This device complies with part 15 of FCC Rules. Operation is Subject to the following two conditions: (1) this device may not

cause harmful interference, and (2) this device must accept any interference

FCC Compliance Statement:

This equipment has been tested and found to comply with limits for a Class B digital device ,pursuant to Part 15 of the FCC rules.

These limits are designed to provide reasonable protection against harmful interference in residential installations. This equipment

generates, uses, and can radiate radio frequency energy, and if not installed and used in accordance with the instructions, may cause

harmful interference to radio communications.

However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause interference to

radio or television equipment reception, which can be determined by turning the equipment off and on, the user is encouraged to try to

correct the interference by one or more of the following measures:

-Reorient or relocate the receiving antenna -Move the equipment away from the receiver-Plug the equipment into an outlet on a circuit

different from that to which the receiver is connected.

-Consult the dealer or an experienced radio/television technician for additional suggestions You are cautioned that any change or

modifications to the equipment not expressly approve by the party responsible for compliance could void Your authority to operate

such equipment.

This device complies with Part 15 of the FCC Rules. Operation is subjected to the following two conditions

1) this device may not cause harmful interference and

2) this device must accept any interference received, including interference that may cause undesired operation.

CamViewInstaller-xxx.exe

Quick Installation Guide

Seeing the video from anywhere

IP Cam Installation CD

QIG

Bracket

Ethernet Cable Power Adapter

Anchors

and Screws

Account Card

IP Cam Installation

Wireless Setting of IP Cam

Night mode control

Step

Please search the software name “mcamview” on the App Store for iPhone/iPad or on Android

Market for Android mobiles

Software for iPhone/iPad and Android mbiles
