Eaton 3S700D Bruksanvisning

Eaton avbrottsfri strömförsörjning (UPS) 3S700D

Läs gratis den bruksanvisning för Eaton 3S700D (16 sidor) i kategorin avbrottsfri strömförsörjning (UPS). Guiden har ansetts hjälpsam av 6 personer och har ett genomsnittsbetyg på 4.7 stjärnor baserat på 3.5 recensioner. Har du en fråga om Eaton 3S700D eller vill du ställa frågor till andra användare av produkten? Ställ en fråga

Ladda ner PDF

Sida 1/16

ENGLISH

Eaton 3S

Advanced User Guide

614-09406-00_EN

3S ANZ

Page 2

614-09406-00 - 3S ANZ_EN

Special symbols

The following are examples of symbols used on the UPS or accessories to alert you to important

information:

DANGEROUS VOLTAGE - Observe the warning associated with the risk of electric shock symbol.

Important instructions that must always be followed.

Information, advice, help.

Read the documentation provided.

Disconnect input plug.

This equipment should only be used in a dry indoor environment.

+ 40 °C

0 °C

Operating range of temperature.

85%

Operating range of humidity.

The UPS and their batteries must be kept in a ventilated place.

Page 3

614-09406-00 - 3S ANZ_EN

ENGLISH

Contents

1. Introduction 4 .......................................................................................

2. Presentation 5 ......................................................................................

3. Installation 6 ........................................................................................

3.1 Package contents...........................................................................................................6

3.2 Recommended positions 6 ...............................................................................................

4. Connection 7 ........................................................................................

4.1 Power supply cord 7 .........................................................................................................

4.2 Protected outlets / Backup & Protected outlets 7 ...........................................................

4.3 Tel / xDSL surge protection (optional) 7 ............................................................................

4.4 USB COM port 8 ...............................................................................................................

4.5 USB charging port (optional) 8 ..........................................................................................

4.6 ON/OFF button 8 ..............................................................................................................

4.7 Register warranty 8 ...........................................................................................................

5. Operation........................................................................................... 9

5.1 Battery charge 9 ...............................................................................................................

5.2 AC-power disturbance 9 ...................................................................................................

5.3 Protected outlets 9 ...........................................................................................................

5.4 Equipment Care 9 .............................................................................................................

5.5 Battery replacement 9 .....................................................................................................

6. Troubleshooting ...............................................................................11

7. Service and support 12 ........................................................................

8. Specication and technical characteristics .................................. 13

9. Glossary 14 ...........................................................................................

Produktspecifikationer

Varumärke:	Eaton
Kategori:	avbrottsfri strömförsörjning (UPS)
Modell:	3S700D
Vikt:	4000 g
Bredd:	335 mm
Djup:	170 mm
Höjd:	86 mm
LED-indikatorer:	Ja
Certifiering:	CE/EAC/Ukr/Cm/CB report
Uteffekt:	420 W
Säkerhet:	IEC 62040-1; IEC 62040-2 C2; IEC 62040-3; IEC 62040-4; IEC 61643-11
Batteriteknik:	Slutna blybatterier (VRLA)
Överspänningsskydd:	Ja
UPS-topologi:	Vänteläge (offline)
Automatiskt batteritest:	Ja
Kabellängd:	1.5 m
Produktens färg:	Black, White
Ingångsfrekvens:	50/60 hz
Effekt skyddsfunktioner:	Överladdning
Temperatur vid drift:	0 - 40 ° C
Antal USB 2.0 anslutningar:	2
USB-port:	Ja
Harmonized System (HS)-kod:	85078000
Högsta strömstyrka:	10 A
Antal uttag AC:	8 AC-utgångar
Altitud vid drift:	0 - 3000 m
Uteffekt kapacitet (VA):	0.7 kVA
Inmatning spänning (min):	161 V
Inmatning spänning (max):	284 V
Utgång, driftspänning (min):	220 V
Utgång, driftspänning (max):	240 V
Utfrekvens:	50 hz
Kallstart:	Ja
Hot-swap batteri:	Nej
Ingångsspänning (Volt):	230 V
