Sida 1/68

Preface

This publication, including all photographs, illustrations and software, is protected

any of the material contained herein, may be reproduced without written consent of

the author.

Version 1.0

Disclaimer

The information in this document is subject to change without notice. The manufac-

turer makes no representations or warranties with respect to the contents hereof and

specifically disclaims any implied warranties of merchantability or fitness for any

particular purpose. The manufacturer reserves the right to revise this publication and

to make changes from time to time in the content hereof without obligation of the

manufacturer to notify any person of such revision or changes.

Federal Communications Commission (FCC)

This equipment has been tested and found to comply with the limits for a Class B

digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to

provide reasonable protection against harmful interference in a residential installa-

tion. This equipment generates, uses, and can radiate radio frequency energy and, if

not installed and used in accordance with the instructions, may cause harmful inter-

ference to radio communications. However, there is no guarantee that interference

will not occur in a particular installation. If this equipment does cause harmful

interference to radio or television reception, which can be determined by turning the

equipment off and on, the user is encouraged to try to correct the interference by one

or more of the following measures:

• Reorient or relocate the receiving antenna.

• Increase the separation between the equipment and the receiver.

• Connect the equipment onto an outlet on a circuit different from that to

which the receiver is connected.

• Consult the dealer or an experienced radio/TV technician for help.

Shielded interconnect cables and a shielded AC power cable must be employed with

this equipment to ensure compliance with the pertinent RF emission limits govern-

ing this device. Changes or modifications not expressly approved by the system’s

manufacturer could void the user’s authority to operate the equipment.

Trademark Recognition

Microsoft, MS-DOS and Windows are registered trademarks of Microsoft Corp.

AMD, Phenom, Athlon, Sempron and Duron are registered trademarks of AMD

Corporation.

Other product names used in this manual are the properties of their respective

owners and are acknowledged.

Preface

Declaration of Conformity

This device complies with part 15 of the FCC rules. Operation is subject to the

following conditions:

• This device may not cause harmful interference, and

• This device must accept any interference received, including interfer-

ence that may cause undesired operation.

Canadian Department of Communications

This class B digital apparatus meets all requirements of the Canadian Interference-

causing Equipment Regulations.

Cet appareil numérique de la classe B respecte toutes les exigences du Réglement sur

le matériel brouilieur du Canada.

About the Manual

The manual consists of the following:

Chapter 1

Introducing the Motherboard

Chapter 2

Installing the Motherboard

Chapter 3

Using BIOS

Describes features of the motherboard

Go to

page 1

Describes installation of motherboard

components

Go to

page 7

Provides information on using the BIOS

Setup Utility

Go to

page 25

Describes the motherboard software

Go to

page 49

Chapter 6

Trouble Shooting

Provides basic troubleshooting tips

page 61

Go to

Chapter 5

Setting Up AMD SB710 RAID

Configuration

Describes the AMD SB710 RAID Configu-

ration

Go to

page 53

Chapter 4

Using the Motherboard Soft-

ware

iii

ABLE OF CONTENTSABLE OF CONTENTS

ABLE OF CONTENTS

Preface i

Chapter 1 1

Introducing the Motherboard 1

Introduction............................................................................................1

Feature.....................................................................................................2

Specifications.........................................................................................4

Motherboard Components...................................................................5

Chapter 2

Installing the Motherboard 7

Safety Precautions...............................................................................7

Choosing a Computer Case................................................................7

Installing the Motherboard in a Case.................................................7

Checking Jumper Settings....................................................................8

Setting Jumpers................................................................................8

Checking Jumper Settings................................................................9

Jumper Settings...............................................................................9

Installing Hardware..........................................................................10

Installing the Processor.................................................................10

Installing Memory Modules...........................................................12

Expansion Slots..............................................................................13

Connecting Optional Devices.........................................................15

Installing a Hard Disk Drive/CD-ROM/SATA Hard Drive..........18

Connecting I/O Devices......................................................................20

Connecting Case Components...........................................................21

Front Panel Header.................................................................23

Chapter 3

25 25

Using BIOS 25

About the Setup Utility....................................................................25

The Standard Configuration..........................................................25

Entering the Setup Utility................................................................25

Resetting the Default CMOS Values..................................................26

Using BIOS........................................................................................26

BIOS Navigation Keys...................................................................27

Main Menu.....................................................................................27

Advanced Menu..............................................................................28

Produktspecifikationer

Varumärke:	ECS
Kategori:	moderkort
Modell:	A960M-M2 (V1.0)
Bredd:	244 mm
Djup:	210 mm
Hörlursutgångar:	1
Certifiering:	EuP, RoHS
Maximalt internminne:	16 GB
Ljudutgångskanaler:	6.1 kanaler
Snabbinstallationsguide:	Ja
Komponent för:	PC
Kompatibla processorer:	AMD Phenom FX, AMD Phenom II X6
Minnestyper som stöds:	DDR3-SDRAM
Antal minnesplatser:	2
BIOS-typ:	AMI
processortillverkare:	AMD
DirectX-version:	10
Typ av ethernet-gränssnitt:	Gigabit Ethernet
Antal LAN (RJ-45) anslutningar:	1
processorsockel:	Socket AM3+
Antal PS/2-portar:	2
Nätverksansluten (Ethernet):	Ja
Strömkälla av typen:	ATX
Antal USB 2.0 anslutningar:	4
RAID-nivåer:	0, 1,10
Minnesplatser, typ:	DIMM
Minneskanaler:	Dubbla kanaler
Minnets hastigheter:	1066,1333,1866 MHz
Max antal processorer:	1
USB 2.0 anslutning:	2
ATX strömkontakt (24-pin):	Ja
EPS strömkontakt (8-polig):	Ja
Fläktanslutning:	Ja
BIOS minnesstorlek:	64 mbit
LAN-styrenhet:	Realtek RTL8111E
Wake-on-LAN förberedd:	Ja
Moderkort, chipsetfamilj:	AMD
Moderkortets chipset:	AMD 770
Moderkort formfaktor:	micro ATX
Video adapter:	Radeon HD 3000
Kvalitet på VGA (D-Sub) porten:	1
PCI Express-kortplatser version:	2.0
Grafikadapterfamilj:	AMD
Ombord grafikkort:	Ja
Uttag för mikrofon/linje in:	Ja
Lagringsenhetsgränssnitt som stöds:	Parallel ATA, SATA II
Ljudchipp:	VIA VT1705
CPU-fläktsanslutning:	Ja
Ljudanslutning på framsidan:	Ja
S/PDIF ut anslutning:	Ja
Antal COM portar:	1
Antal SATA II kontakter:	6
Chassits genomgångsanslutning:	Ja
PCI-kortplatser:	2
Moderkort southbridge:	AMD SB710
Antalet parallella ATA-anslutningar:	1
PCI Express x16 platser:	1
PCI Express x1 kortplatser:	1
Diskret grafik stöd:	Ja
