IR /IR- E113 - 123E

Quick Installation Guide

01 201- 3 / v1.0

may be reproduced, transmied, transcribed, stored in a retrieval system, or translated

into any language or computer language, in any form or by any means, electronic,

mechanical, magnec, opcal, chemical, manual or otherwise, without the prior wrien

permission from Edimax Technology Co., Ltd.

Edimax Technology Co., Ltd. makes no representaons or warranes, either expressed or

implied, with respect to the contents hereof and specically disclaims any warranes,

merchantability, or tness for any parcular purpose. Any soware described in this

manual is sold or licensed as is. Should the programs prove defecve following their

purchase, the buyer (and not this company, its distributor, or its dealer) assumes the

enre cost of all necessary servicing, repair, and any incidental or consequenal damages

resulng from any defect in the soware. Edimax Technology Co., Ltd. reserves the right

to revise this publicaon and to make changes from me to me in the contents hereof

without the obligaon to nofy any person of such revision or changes.

The product you have purchased and the setup screen may appear slightly dierent from

those shown in this QIG. For more informaon about this product, please refer to the

user manual on the CD-ROM. The soware and specicaons are subject to change

without noce. Please visit our website www.edimax.com for updates. All brand and

product names menoned in this manual are trademarks and/or registered trademarks

of their respecve holders.

Noce According to GNU General Public License Version 2

This product includes soware that is subject to the GNU General Public License version

2. The program is free soware and distributed without any warranty of the author. We

oer, valid for at least three years, to give you, for a charge no more than the costs of

physically performing source distribuon, a complete machine-readable copy of the

corresponding source code.

The GNU GPL and GNU LGPL soware codes used in Edimax products are distributed

without any warranty and are subject to the copyrights of their respecve authors. The

rmware les for this product can be found under the “Download” page at the Edimax

website (www.edimax.com).

PRODUCT INTRODUCTION

Package Contents

Before you start using this product, please check there is anything missing if

from the package:

 1 x Network camera

 1 x Power adapter

 1 x Sun shield

 2 x Screw

 1 x (with ulity soware, user manual & multi-language QIG) CD

 1 x Quick installation guide

 1 x Bracket

Connecon Types

No.

Descripon

Blue, sensor in 1, for alarm input, 3.3 volt level allowed DV

Yellow, -485 D- RS

Orange, -485 RS D+

Black, GND

Green, alarm out 1, DV 3.3 volt level allowed

DC volt input 12 2A

Reset buon

Audio output

Audio input

RJ- network connector 45

LED indicators: power (orange), network (green)

TV output, BNC connector

Note: Please check the aached I/O cable index before inserng or

releasing any wire.

Produktspecifikationer

Varumärke:	Edimax
Kategori:	övervakningskamera
Modell:	IR-113E
LED-indikatorer:	LAN
Wi-Fi:	Nej
Videoformat som stöds:	H.264, M-JPEG, MPEG4
Videolägen som stöds:	1080p
Maximal upplösning:	2048 x 1536 pixlar
Diameter:	73 mm
Inbyggd hårddisk:	Nej
Fast brännvidd:	6 mm
Certifiering:	CE, FCC
Optisk sensorstorlek:	1/2.5 "
Bildsensortyp:	CMOS
Digital zoom:	10 x
Optisk zoom:	- x
Internminne:	128 MB
Grafikupplösningar som stöds:	320 x 240,720 x 480,1280 x 960,1280 x 720 (HD 720),1920 x 1080 (HD 1080),2048 x 1536 (QXGA),640 x 480 (VGA)
Modell:	IP-säkerhetskamera
Kabelteknik:	10/100Base-T(X)
Återställningsknapp:	Ja
Flashminne:	128 MB
RS-485-portar:	1
Typ av minneskort:	SD, SDHC
Produktens färg:	Vit
Inbyggd kortläsare:	Ja
LED typ:	IR
Skyddsfunktioner:	Vattentålig
Formfaktor:	Stifthylsa
mörkerseende avstånd:	25 m
Strömförsörjning via Ethernet (PoE) stöd:	Ja
Antal LAN (RJ-45) anslutningar:	1
Temperatur vid drift:	0 - 50 ° C
Intervall för relativ operativ luftfuktighet:	20 - 85 %
Hållbarhetscertifiering:	RoHS
Internationellt skydd (IP) kod:	IP67
Video rörelsedetektor:	Ja
Placeringar som kan användas:	Utomhus
Anslutningsteknologi:	Kabel
Monteringssätt:	Vägg
Minimibelysning:	1 lx
Mörkerseende:	Ja
Bildfrekvens:	30 fps
Nätverksansluten (Ethernet):	Ja
Stöd för nätverksprotokoll:	TCP/IP, IPv6, IPv4, UDP, ICMP, DHCP, NTP, DNS, DDNS, SMTP, FTP, HTTP, HTTPs, Samba, PPPoE, UPnP, Bonjour, RTP, RTSP, RTCP
Filtrering för IP-adress:	Ja
Strömkälla av typen:	PoE
DC-utgång volt:	+12V
Produktlängd:	175 mm
Efterlever industristandard:	IEEE 802.3, IEEE 802.3u, 802.3af
Strömlysdiod:	Ja
DC utgående ström:	2 A
Larm ingång / utgång:	Ja
Objektivets betraktningsvinkel, horisontell:	67.4 °
