MG-10G Series

Maximum performance and actual data rates will vary depending network conditions and environmental factors. Product specifications and design are subject change without notice. on to

www.edimax.com

10GBase-SX LX SFP+ Modules

The MG-10G series Small Form-Factor (SFP) Pluggable 10 Gigabit Modules serve the purpose of extending network

transfer distances. Attached to switches, the modules have the ability to extend distances to several kilometers or even

tens of kilometers based on network demand, which in turn lowers costs. The MG-10G series SFP modules are also

compatible with a large range of 10 Gigabit Ethernet connectivity options for enterprise, data center and service

provider applications .

KEY FEATURES

•Compliant with IEEE and Fibre Channel Standard 802.3ae 10 Gigabit Ethernet

•Supports full-duplex

•Plug- -Play & Hot Pluggable and

•Supports Pull- -Plug with power on switches or

•Power: Internal power from switches

•Compliant with Small Form Factor Pluggable MSA

•Compliant with Class 1 Laser International Safety Standard IEC 825

•Complies with EN60825-1 and FDA 21 CFR 1040.10 and 1040.11

Hot

Pluggable

10Gbps

Plug &

Play

Type

PRODUCT INFORMATION

Model Number Wavelength

Connector

Type

Media

Power

(dBm)

Sensitivity

Power

Budget

Distance Application

MG-10GAMA 850 nm -1 to -7 -9.9 dBm 8.2 dB Multi-Mode Fiber LC MMF 300m

MG-10GAS1 1310 nm SMF 0 to - -10 dBm 10.0 dB 10km Single-Mode Fiber LC 10

SPECIFICATIONS

MG-10G Series

10GBase- LX SFP+ Modules SX

Hardware

Wave Length

•850nm for -10GAMA MG

•1310nm for -10GAS1 MG

Power Supply

3.3V

Cable

•Multi-mode Fiber for -10GAMA MG

•Single-mode Fiber for -10GAS1 MG

Fiber Type

•50/125μ μm or 62.5/125 m Multi-Mode Fiber

•9/125 μm Single-Mode Fiber

Max. Cable Length

•300m for -10GAMA MG

•10km for -10GAS1 MG

Data Rate

10Gbps

LC/UPC

Environment

Temperature

Operating: 0 - 70℃

Storage: - - 40 85℃

Humidity (Non-condensing)

Operating: 10 - 90%

Storage: 5 - 90%

Standards Compliance

Standards and Protocols

IEEE 802.3ae

CSMA/CD

TCP/IP

Certications

FCC, CE

APPLICATION DIAGRAM
