PIXEL NET 4™

SKU# PIX013

The Pixel Net 4™ is an ArtNet to DMX driver and is compatible

with all of Elation’s Pixel Bar™ products, includes ArtNet

CAT5 input/output, (4) RJ45 CAT5e outputs, supports up to

(4) DMX universes, 350W max power consumption, and

a multi voltage universal power supply (90-120v 60Hz).

FEATURES

ArtNet to DMX Driver

(4) DMX Universes

CONTROL / CONNECTIONS

(2) RJ45 CAT5 ArtNet Ports (Input/Output)

Unique Device ID For Each Unit

(4) RJ45 CAT5e Outputs

powerCON In/Out

Multiple Unit Linkable: 6 units @120V

SIZE / WEIGHT

Length: 12.2” (310mm)

Width: 10.0” (255mm)

Vertical Height: 3.4” (86.2mm)

Weight: 8.0 lbs. (3.6kg)

ELECTRICAL / THERMAL

AC 90-120V - 60Hz

350W Max Power Consumption

32°F to 104°F (0°C to 40°C)

APPROVALS / RATINGS

Specifications are subject to change without notice ©Elation Professional 10/31/15

Elation Professional USA | 6122 S. Eastern Ave. | Los Angeles, CA. 90040

323-582-3322 | 323-832-9142 fax | www.elationlighting.com | [email protected]

Elation Professional B.V. | Junostraat 2 | 6468 EW Kerkrade, The Netherlands

+31 45 546 85 66 | +31 45 546 85 96 fax | www.elationlighting.eu | [email protected]

ELATION I PIXEL NET 4™ IProduct Specification Sheet

6.3”

(160mm)

10.0”

(255mm)

12.2”

(310mm)

11.4”

(290mm)

11.0”

(280mm)

10.0”

(255mm)

3.4”

(87mm)

ORDER CODEITEM

NARROW CLAMPPro Clamp with 2-inch Wrap-Around

PLC33 ft (1m) powerCON Link Cable

Additional cable lengths available

RoHs

COMPLIANT

DIMENSIONAL DIAGRAMS

OPTIONAL ACCESSORIES
