ESM-3712-CN 77x35 DIN Size Cooling Controller
Instruction Manual. ENG ESM-3712-CN 01 V08 04/22
- 4 Digits Display
- NTC Input or PTC Input (Must be determined in order.)
- 3 output for compressor, defrost and fan controls
- 2 sensor input for cabinet and evaporator
- Configurable digital input
- ON / OFF Control
- Separately adjustable 2 offset value for cabinet and evaporator sensor
- Set value boundaries
- Operation selection of compressor operate continuously, stops or
operates periodically in case of cabinet probe defect
- Compressor protection delays
- Selectable defrost function (hot gas or electric )
- Adjustable defrost time from front panel
- Manual defrost from front panel
- Defrost parameters
- Alarm parameters
- Fan can be operated depending on compressor and defrost
- Fan can be operated depending on evaporator temperature or
(cabinet - evaporator ) temperature
- Adjustable internal buzzer according to the defrost, cabinet prob
defect and alarm status
- Defrost time and/or manual defrost and/or temperature set value
protection
- Password protection for programming mode
- Installing parameters using Prokey
- Remote access, data collecting and controlling with Modbus RTU
- Having CE mark according to European Norms
ESM-3712-CN 77 x 35 DIN Size
Digital , ON / OFF Cooling Controller
ENGLISH
AEMKO
ENGLISH
Operating Temperature : -30 to 80 °C
Max. Operating Humidity : 90% Rh (non-condensing)
Altitude : Up to 2000 m.
Forbidden Conditions:
Corrosive atmosphere
Explosive atmosphere
Home applications (The unit is only for industrial applications)
c
1.2 General Specifications
1.Preface
ESM-3712-CN series cooling controllers are designed for controlling cooling process. They
can be used in many applications with their easy-use, On / Off control form and defrost
properties. Some application and application fields which they are used are below:
Application Fields
Food
Machine production industries
etc...
Applications
Refrigerators
Air Conditioning
Storages
Freezers
etc...
2
1.1 Environmental Ratings
ESM-3712-CN
Evaporator
Sensor Input
Power Supply
Input
Digital Input
Compressor Input
Fan Output
Defrost Output
NTC,PTC
Configurable Digital
Input
- Stopping fan
- Stopping compressor
- Stopping fan and
compressor
- Manual defrost
- Alarm
Cabinet
Sensor Input
NTC,PTC
Cooling Function
ON/OFF Operation
Defrost Function
ON/OFF Operation
Fan Control Output
ON/OFF Operation
230V ( %15) 50/60HzV ±
Standard
Optional Supply Voltage
100-240VV(
- 30 V Z
±%15) 50/60Hz,
115 V (±%15) 50/60Hz,
24 V (±%15) 50/60Hz,
24 V (±%15) 50/60Hz,
10
V
V
W
A visual inspection of this product for possible damage occurred during shipment is
recommended before installation.
It is your responsibility to ensure that qualified mechanical and electrical technicians install this
product.
If there is danger of serious accident resulting from a failure or defect in this unit, power off the
system and separate the electrical connection of the device from the system.
The unit is normally supplied without a power supply switch or a fuse. Use power switch and
fuse as required.
Be sure to use the rated power supply voltage to protect the unit against damage and to prevent
failure
Keep the power off until all of the wiring is completed so that electric shock and trouble with the
unit can be prevented.
Never attempt to disassemble, modify or repair this unit. Tampering with the unit may results in
malfunction, electric shock or fire.
Do not use the unit in combustible or explosive gaseous atmospheres.
During putting equipment in hole on the metal panel while mechanical installation some metal
burrs can cause injury on hands, you must be careful.
Montage of the product on a system must be done with it’s fixing clamps. Do not do the montage
of the device with inappropriate fixing clamp. Be sure that device will not fall while doing the
montage.
It is your responsibility if this equipment is used in a manner not specified in this instruction
manual.
EMKO Elektronik warrants that the equipment delivered is free from defects in material and
workmanship. This warranty is provided for a period of two years. The warranty period starts
from the delivery date. This warranty is in force if duty and responsibilities which are
determined in warranty document and instruction manual performs by the customer
completely.
Repairs should only be performed by trained and specialized personnel. Cut power to the
device before accessing internal parts.
Do not clean the case with hydrocarbon-based solvents (Petrol, Trichlorethylene etc.). Use of
these solvents can reduce the mechanical reliability of the device. Use a cloth dampened in
ethyl alcohol or water to clean the external plastic case.
1.3 Installation
1.4 Warranty
1.5 Maintenance
1.6 Manufacturer Company
3
ENGLISH
Manufacturer Information:
Emko Elektronik Sanayi ve Ticaret A.Ş.
Bursa Organize Sanayi Bölgesi, (Fethiye OSB Mah.) Ali Osman Sönmez Bulvarı,
2. Sokak, No:3 16215 BURSA - TÜRKİYE
Phone : +90 224 261 1900 Fax : +90 224 261 1912
Repair and maintenance service information:
Emko Elektronik Sanayi ve Ticaret A.Ş.
Bursa Organize Sanayi Bölgesi, (Fethiye OSB Mah.) Ali Osman Sönmez Bulvarı,
2. Sokak, No:3 16215 BURSA - TÜRKİYE
Phone : +90 224 261 1900 Fax : +90 224 261 1912
