Thank you for purchasing the Erica Synths Echolocator FX unit!
A unique stereo delay with an algorithm developed by 112dB, the Echolocator is a hands-on precision
tool that lets you take manual and very musical control over small nuances. Like a bat navigating its
environment in the dark, you can feel your way through your live performances and shape the delay
response and character on the fly.
Featuring 12 parameters for detailed sound design, save/recall functions for all parameters, MIDI
control over all parameters and a sleek aluminium case to match our lineup of compact desktop
units, the Echolocator will let your setup take flight in any live show, studio or sonic experiment.
InGain
PingPan Shimmer
Stereo
OutGainMix
OutGainMixInGain
CompressorDel/Diff
Feedback
EQ
PongPan Shimmer CompressorDel/Diff EQ
A Signal Flow
0 100
F I LT E R Q
1000
-12 +12
0 50
P I T C H S H I F TM O D S P E E D
O 100
S H I M M E R
T I M E
R E V E R B
50%
0% 100%
-100
P I N G P O N G
0 100
50
O R B I T
0Hz 2Hz
L R
MIX
0dB +24dB
-∞dB 0dB
50
50
1Hz 50
F I LT E R C U T O F F
50
15Hz 22.5kHz
M O D D E P T H
TA P T E M P O
F R E E Z E
Adjusts input gain
of the Echolocator.
It ranges from
guitar to line levels.
Freezes the audio
buffer determined
by the TIME
potentiometer
setting. Pushing and
holding the BACK
button and pushing
the FREEZE button
bypasses the FX.
Sets the quality of
the filter. 0 is flat
(no filtering)
100 is narrow
band filtering.
Sets a center
frequency of
the filter.
Sets the LFO
speed of the LFO
from 0 to 2Hz
Sets the feedback
amount (number of
delay reflections)
Pans the input signal
to get a ping pong
effect.
Tap the button to sync a
delay time to the tempo.
Pushing and holding the
BACK button and
pushing the TAP TEMPO
button syncs the delay
time to the MIDI clock.
Controls the
output volume of
the Echolocator.
Brings the menu one
step back and acts as
the SHIFT button for
Bypass and Sync.
Selects and saves
the presets and
performs
configuration of
the unit.
OLED indicates
the presets and
configuration.
Sets the delay time from 4ms to 4 seconds.
When in SYNC mode the TIME knob becomes
time multiplier (CCW) and divider (CW).
The ratios are 1/8, 3/16, ¼, 1/3, ½, 1, 2, 3, 4, 16/3, 8.
Sets the LFO amount,
sent to the TIME
control.
Adds room reverb.
between delay and
reverb. Add some room
to your audio signal!
Controls the mix
between the
input signal and
the delayed
signal.
Sets the
shimmer pitch
-12 to +12
semitones.
Sets
amount of
shimmer.
Amount of jitter (higher
speed modulation).
ORBIT collerates to the
MOD SPEED setting.
