ELECTRONIC THEATRE CONTROLS

Ellipsoidal lighting xture

PHYSICALDie cast and extruded aluminium construction

One-handed focus mechanism with positive lock

(patents pending)

Rotating shutter assembly ±25°

20 gauge stainless steel shutters in a tri-plane assembly

Lens tube door provides easy access for lens cleaning

Positive locking double-clutch yoke

Scale markings for eld angle and focus settings

Integral die cast color frame holders with two accessory

slots, and a top mounted, color frame retainer

Insulated rear handle

High impact, thermally insulated knobs and shutter

handles

Steel yoke with two mounting positions

Slot for glass or stainless steel patterns

Slot with sliding cover for motorized pattern devices or

optional iris

UL and cUL listed

ELECTRICAL115-240V, 50/60Hz

High temperature 3–conductor 36” leads in a glass ber

outer sleeve

Supports ETC Dimmer Doubling™ technology

LAMP750W Maximum

HPL - compact tungsten lament contained in a

krypton/xenon lled quartz envelope (see table for

suitable lamp types)

Integral die cast aluminium heat sink lamp base

OPTICALThe 25°–50°uses a plano–convex front lens with a

bi–convex rear lens

Faceted borosilicate reector with multi-layer

dichroic coating

95% of visible light reected through the optical train

90% of infrared radiation (heat) passes through the

reector

Reector secured with anti-vibration shock mounts

Low gate and beam temperature, shutters will not

warp or distort

Tool free lamp centering (X/Y) and peak/at (Z)

adjustment knobs

Positive locking X, Y and Z adjustments, unaected

by relamping

Lenses have anti-reective coatings

Lenses secured with anti-vibration shock mounts

15°-30°version is available

SourceFourZoom25°-50°™

42550 Series

SPECIFICATIONS

Note:Available in black only

Source Four Zoom Accessories

Model#Description

407CFColor Frame(included)

400CCC-clamp (included)

400SCSafety Cable

400PH–APattern holder (A size)

400PH–BPattern holder (B size)

400PH–GGlass pattern holder

400BYBalanced yoke assembly kit

400RSDrop–in Iris

400PTH3Top Hat (3” tube)

400PTH6Top Hat (6” tube)

400PHHHalf Hat

400PGE3Gel Extender (3” tube)

400PGE6Gel Extender (6” tube)

Source Four Zoom

Model#Description

4255025°–50°Source Four Zoom ellipsoidal (black)

ETC Source Four Zooms are supplied with color frame,

C–clamp and 36” (90cm) leads as standard

Connector Designation

UseSuffixesbelowtospecify Factory–Fitted Connector type

Model#Description

AParallel-blade U-ground connector

BTwo-pin and ground, 20 amp connector

CGrounded, 20 amp, twistlock connector

MDimmer Doubling™ connector (NEMA L515P)

ORDERING INFORMATION

4-11.1

45

30

38

50
