Sida 1/8
Pressure sensor SDE3
Festo SE & Co. KG
Ruiter Straße 82
73734 Esslingen
Germany
+49 711 347-0
www.festo.com
Operating instructions
Original instructions
8078143
2017-09f
[8078145]
English............................................................
For all available product documentation è www.festo.com/pk
1 Operating elements and connections
123
4
789
aJ
aA
aB
aC
aD
5
6
1 SDE3 for mounting onto a wall or
H-rail
2 Adapter plate for wall mounting
3 Electrical connection
4 SDE3 for front panel mounting
5 Clamping plate for front panel
mounting
6 Mounting slide (rear)
7 Compressed air or vacuum
connections (only SDE3-...D and
SDE3-...M)
8 Compressed air or vacuum
connection (only SDE3-...S)
9 Compressed air or vacuum
connections (only SDE3-...Z)
aJ Label holder
aA B pushbutton
aB A pushbutton
aC Edit button
aD Display
Fig. 1
Key feature Order
code
Type
Function SDE3 Pressure sensor
Pressure measuring range -V1 0 … –1
-B2 –1 … +1
-D2 0 … 2
-D6 0 … 6
-D10 0 … 10
-D12
1)
0 … 12
Supply port S 1x relative pressure
D 2x relative pressure
Z 1x differential pressure
M 2x relative pressure, 1x differential pressure analysis
Feature Order
code
Type
Display
-B Values in bar
-P Values in psi
-K
2)
Values in kPa
-H Values in inches of mercury
-W
3)
Values in inches of water
Mounting/pneumatic
connection
-HQ4 H-rail mounting, push-in connector 4 mm
-WQ4 Wall mounting, push-in connector 4 mm
-FQ4 Front panel mounting, push-in connector 4 mm
-HT532 H-rail mounting, push-in connector 5/32”
-WT532 Wall mounting, push-in connector 5/32”
-FT532 Front panel mounting, push-in connector 5/32”
Electrical output -2P 2 switching outputs PNP
-2N 2 switching outputs NPN
Electrical connection -M8 Plug connector M8x1
-M12 Plug connector M12, A-coded
-K Cable 2.5 m
Electrical accessories
4)
-G Connecting cable, straight socket, cable length 2.5 m
-W Connecting cable, angled plug socket, cable length
2.5 m
-G5 Connecting cable, straight socket, cable length 5 m
-W5 Connecting cable, angled plug socket, cable length 5 m
1) Key feature only on request
2) Not for SDE3-D12M
3) Not for SDE3-D6M, SDE3-D10M, SDE3-D12M
4) Only in combination with key feature -M8 or -M12
Fig. 2
2 Function and application
The SDE3 has been designed for monitoring changes in pressure in the
compressed air system or terminals. Variants for relative pressure measurement
and differential pressure measurement are available:
Type Description Input
values
1)
Switching
outputs
SDE3-...Z 1x differential pressure
p1 – p2
2)
In A Out A, Out B
SDE3-...S 1x relative pressure In A Out A, Out B
SDE3-...D 1x relative pressure pA In A Out A
1x relative pressure pB In B Out B
SDE3-...M 1x relative pressure pA In A Out A
1x relative pressure pB In B –
1x differential pressure
analysis pB
– pA
In C Out B
SDE3-…V1M 1x differential pressure
analysis pA – pB
In C Out B
1) In A/B: input value for sensor element A/B. In C: calculated
2) Measuring pressure p1 – reference pressure p2
Fig. 3
3 Requirements for product use
Warning
Depending on the functions of the machine/system, the manipulation of signal
statuses can cause serious injury to people or material damage.
Note that if the switching characteristics of the switching outputs is modified
in EDIT mode, the new status becomes effective immediately.
Enable the password protection option (security code) to prevent accidental
alteration by an unauthorised third party (è Chapter 5.3 section Set security
code).
Warning
The usage of the SDE3 in combination with impermissible media can lead to
personal injury or material damage.
Use the SDE3 only with compressed air
Observe the specified air quality class (è Chapter 11 Technical data).
