Sida 1/10
E / 1
ENGLISH
INDEX
FOREWORD ....................................................................... Page
How to use this instructions manual .................................... E/2
Symbols used in this manual ............................................... E/2
Service and spare parts ........................................................ E/2
Product identification ............................................................. E/2
1 MAIN INFORMATION
1.1 Description .................................................................... E/3
1.2 Expected use ................................................................. E/3
1.3 Standard accessories supplied .................................... E/3
1.4 Safety general warnings................................................ E/4
1.4.1 What you MUST DO .............................................. E/4
1.4.2 What you MUST NOT DO ...................................... E/4
2 TRANSPORT AND HANDLING
2.1 Unpacking ..................................................................... E/5
2.2 Packing disposal ........................................................... E/5
3 SETTING UP
3.1 Positioning ..................................................................... E/6
3.2 Installation ..................................................................... E/6
3.3 Starting ........................................................................... E/6
3.4 Overload cutout .............................................................. E/7
3.5 How to adjust working pressure ................................... E/7
4 MAINTENANCE
4.1 Warning ......................................................................... E/8
4.2 Operations (after first 50 w.h.) ....................................... E/8
4.3 Weekly operations ......................................................... E/8
4.4 Monthly operations ........................................................ E/8
4.5 Operations every 6 months
or 500 hours .................................................................. E/9
4.6 Operations every 2 years
2000 hours .................................................................... E/9
4.7 Scheduled maintenance table ...................................... E/9
4.8 Recommended oils ...................................................... E/9
5 TROUBLESHOOTING ........................................................ E/10
E / 2
How to use this instructions manual
This manual is an integral part of your compressor, and shall be kept with it for future
reference.
Retain this manual in a suitable place and when consulting it, take care of not spoiling it.
Should your compressor be resold, entrust it to the new owner who will obviously need
the information contained.
Before starting the compressor read this manual carefully so as to understand the contents
clearly; consult it whenever any doubt arise.
This manual contains information useful for your safety. Follow the indications contained
in it and perform the recommended procedures which, if not properly observed, could
result in damage to equipment or could cause personal injury.
Moreover, you will find useful information which will make the use and maintenance of
your compressor easier.
Should the manual be lost, ask for a new copy.
This manual does not include the spare parts list, which is available by our Authorized
Resellers.
Symbols used in this manual
In order to make evident same special information, the following symbols are used:
WARNING
It refers to safety instructions to be complied with in order to ensure maximum safety
conditions to the operator as well as to people in the working area.
NOTE
Recommended instructions or precautionary measures to facilitate maintenance
operations or to clarify special operations.
SPECIALIZED PERSONNEL
Symbols indicating operations to be carried out by specialized personnel only.
Service and Spare Parts
In case of replacement of any part of your compressor, use only ORIGINAL SPARE PARTS.
Contact any Authorized Service Centre which, having its own stock, will supply you at its
best.
Imitation spare parts hide potential risks including the risk of injuries to people. In order
to grant you efficient service or to remove any doubt, when asking for information always
quote model, type and serial number of your compressor, which are printed on the cover
of this manual and on the compressor's nameplate.
Product identification
The compressor Your have purchased has its own CE plate showing the following data:
1) Manufacturers data
2) CE mark year of manufacture
3) TYPE = name of the compressor
CODE = compressor code
SERIAL NO. = serial number of the compressor
You have purchased (to be always mentioned when
calling for technical assistance)
4) air delivered by the compressor expressed in (l/
min) and (cfm)
5) max. operating pressure (bar and PSI)
compressor noise level in dB(A)
FOREWORD
E / 3
ENGLISH
1.MAIN INFORMATION
1.1 Description
All compressors described in this manual are specially designed and manufactured for
any use requiring easiness, solidity, handiness, and proper power for universal use.
They are thought for hobbysts and craftsmen, who need a source of compressed air
anywhere.
The max. pressure allowed for this type of compressors ranges from max. 8÷10 bar,
while power gets up to 2 HP.
All UE compressors are equipped with receivers according to EEC 87/404 Specifications.
Compressors equipped with bare pump units FD2000, FD2500, OL185, OL195, OL230,
MK6, FD9200, FD9300 and SF2500, have been designed and built for intermittent duty
applications. Compressors are equipped with an overload cut-out which trips
automatically and cuts off power when safety limits are reached. However, we recommend
that compressor duty cycle never exceed 50% and continuous operation never exceed 15
minutes.
1.2 Expected use
In addition to pneumatic tools, your compressor may be connected to several accessories
suitable for blowing, washing and spraying.
For technical specifications and detailed instructions, please see the instructions provided
for each accessory equipment.
1.3 Standard Accessories Supplied (Fig. 1)
Manual for Use and Maintenance
Oil Dipstick
Wheels, Vibration-damping Pad, Suction Filter (if not
already fitted)
Technical Data Sheet (size and weight).
1
6) electric data: voltage (V/ph), frequency (Hz), absorption (A) - power (HP and kW), rotations
per minute (Rpm).
7) other approvals
