Sida 1/2
FLIR Ariel
TM
CM-3508
4K Mini-Dome Camera with Edge AI Analytics
www.ir.com/products/ariel-4K-mini-dome
For technical or sales support, please visit: www.flir.com/about/general-inquiries
Key Features
• Provides high-resolution, 4K imaging with shutter WDR for superior
performance in low light environments
• Enables reliable intrusion detection and site surveillance using Edge
AI analytics
• Features strong H.265 built-in motion processing architecture for
sharp video in complex environments
• Offers simplied web interface and cybersecurity improvements to
help keep your facility safe
• Delivers predictable, efcient streaming and storage, reducing utility
costs and total cost of ownership
Main Applications
• Designed for low-light areas or situations where fast frame rates
are required
• Suited to critical infrastructure sites, commercial ofces, and large
campuses
SPECIFICATIONS
Product CM-3508-11-I
SoC InnoFusion C5-36GW
Memory 1 GB DDR3
Flash 256 MB SPI NAND
eMMC N/A
Image sensor CMOS 1/1.8", Sony IMX334
Sensor resolution 3840 × 2160
Scanning mode Progressive
Sensitivity Color 0.15 lux,
0 lux (with IR illuminator ON) B/W 0.01
Lens type Varifocal 4–10 mm, 110.4° ~45° HFOV, F/1.6, D/N,
motorized, P-Iris
Automatic electronic
shutter (AES)
1/3~1/32000
Digital slow shutter (DSS) 1/3~1/30 (NTSC); 1/3~1/25 (PAL)
Focus Push AF/Manual
White balance Auto/Manual
Automatic gain control Yes
Back light compensation ON/OFF
Shutter WDR 100 dB
Noise reduction Yes
Tamper detection Yes
Privacy zones Yes
Video motion detection Yes
Video analytics
*
• Basic: line and area, human/vehicle
• Object counting
• Line crossing
• Zone object counting
• Intrusion detection
• Loitering detection
Day/Night mode Yes
Mechanical IR cut lter Yes
Signal to noise ratio (SNR) 50 dB
Video
Compression H.265 / H.264 / MJPEG
Maximum performance
**
Up to 30 fps 8 MP (H.265/H.264) + 30 fps 1080p
(H.265/H.264) + 30 fps 360p (MJPEG)
Resolution range 3840 × 2160 to 640 × 360
Bandwidth 500 K–12000 K
Rate control CBR, CVBR (H.265/H.264)
Smart compression Dynamic GOP
SD card recording
¹
microSDXC up to 1 TB
²
IR Illuminator
Distance Up to 30 m (98 ft)
Angle of illumination 140°
LED type High efciency SMD
Peak emission wavelength (nm) 850
Day/Night switch Light sensor
Network
ONVIF ONVIF Prole G / T / S/ M
Ethernet 10/100 Mbps Ethernet, RJ45 x 1
Remote conguration Via web browser or supported video management
software
Firmware upgrade Flash memory for upgrade of camera rmware over
the network
Supported web browser Firefox, Chrome, Edge
*Only one type of analytics rule type can be enabled at any time.
**Motion and VA/WDR off: 30 fps 5 MP 8 MBps (H.265/H.264) + 30fps 1280 × 720 4 MBps (H.265/H.264) + 15 fps
640 × 480 (MJPEG)
1
SD card not included
² Refer to list of compatible SD cards; up to 1 TB
This product is subject to United States export regulations and may require US authorization prior to export,
reexport, or transfer to non-US persons or parties. Diversion contrary to US law is prohibited.
For assistance with conrming the Jurisdiction & Classication of Teledyne FLIR, LLC products, please contact
exportquestions@ir.com. ©2025 Teledyne FLIR, LLC. All rights reserved.
Revised 02/03/2025
FLIR_Ariel UHD MiniDome_Datasheet_en-US-LTR 24-0543-INS
For technical or sales support, please visit:
www.flir.com/about/general-inquiries
FLIR Ariel
TM
CM-3508
4K Mini-Dome Camera with Edge AI Analytics
www.ir.com/products/ariel-4K-mini-dome
SPECIFICATIONS
For more information about
FLIR Ariel 4K Mini-Dome please
scan or visit:
³ Max power consumption with video analytics
Specications subject to change. For the most up-to-date specications, please visit ir.com.
Audio
Bidirectional audio G.711 8 KHz/8 bits (a-law/μ-law) Line-in terminal block
Line-out terminal block
Alarm
Input Quantity 1, Digital input/Dry contact input
Output Quantity 1, Digital output/Dry contact
Physical
Enclosure Outdoor: IK10 rated vandal IP66
Dimensions 134 × 116 mm (5.27 × 4.56 in)
Unit Weight 0.86 kg (1.89 lbs)
Mechanical
Pan / Tilt / Rotation 3-axis gimbal 355°/80°/±90°
Electrical
Input voltage PoE IEEE 802.3af, Class 3
Power consumption³
12.95 W (PoE 48V ⎓ 0.23A)
Power connector RJ-45 PoE
Environmental
Operating temperature -40°C to 60°C (-40°F to 140°F) IR off
-40°C to 40°C (-40°F to 104°F) IR on
-20°C (-4°F) cold start
Storage temperature -40°C to 60°C (-40°F to 140°F)
Humidity 10% to 90% RH(non-condensing)
Shock and vibration Shipping box: ISTA 3A
Warranty and Regulator
Warranty According to FLIR RMA Policy and Process Notice
document
USA UL, FCC Part 15 (subpart B, class A)
International CE marked, EN61000-6-3, EN50130-4, RoHS, RCM,
WEEE, BIS, UKCA, ICES-003
Accessories
4S Electrical box adapter plate
