9062

Motor and Phase Rotation Indicator

Users Manual

LIMITED WARRANTY AND LIMITATION OF LIABILITY

This Fluke product will be free from defects in material and workmanship for two

years from the date of purchase. This warranty does not cover fuses, disposable bat-

teries, or damage from accident, neglect, misuse, alteration, contamination, or ab-

normal conditions of operation or handling. Resellers are not authorized to extend

any other warranty on Fluke’s behalf. To obtain service during the warranty period,

contact your nearest Fluke authorized service center to obtain return authorization

information, then send the product to that Service Center with a description of the

problem.

THIS WARRANTY IS YOUR ONLY REMEDY. NO OTHER WARRANTIES, SUCH

AS FITNESS FOR A PARTICULAR PURPOSE, ARE EXPRESSED OR IMPLIED.

FLUKE IS NOT LIABLE FOR ANY SPECIAL, INDIRECT, INCIDENTAL OR CONSE-

QUENTIAL DAMAGES OR LOSSES, ARISING FROM ANY CAUSE OR THEORY.

Since some states or countries do not allow the exclusion or limitation of an implied

warranty or of incidental or consequential damages, this limitation of liability may not

apply to you.

Fluke Corporation

P.O. Box 9090

Everett, WA 98206-9090

U.S.A.

Fluke Europe B.V.

P.O. Box 1186

5602 BD Eindhoven

The Netherlands

11/99

Table of Contents

Title Page

Introduction.......................................................................................................... 1

Contacting Fluke ................................................................................................. 1

Unpacking the 9062 ............................................................................................ 2

Safety Information ............................................................................................... 2

Symbols............................................................................................................... 5

Elements of the 9062 .......................................................................................... 6

Using the Motor & Phase Rotation Indicator....................................................... 7

Determine Rotary Field Direction .................................................................... 7

Non-Contact Rotary Field Indication ............................................................... 9

Determine the Motor Connection .................................................................... 12

Magnetic Field Detection................................................................................. 13

Maintaining the 9062 ........................................................................................... 13

Cleaning........................................................................................................... 13

Replacing and Disposing of the Batteries ....................................................... 14

Specifications ...................................................................................................... 17
