True-rms Digital Multimeters

Users Manual

June 2007, Rev. 2, 3/09

All product names are trademarks of their respective companies.

Lifetime Limited Warranty

Each Fluke 20, 70, 80, 170, 180 and 280 Series DMM will be free from defects in material and workmanship for its lifetime. As used herein,

“lifetime” is defined as seven years after Fluke discontinues manufacturing the product, but the warranty period shall be at least ten years from

the date of purchase. This warranty does not cover fuses, disposable batteries, damage from neglect, misuse, contamination, alteration, acci-

dent or abnormal conditions of operation or handling, including failures caused by use outside of the product’s specifications, or normal wear

and tear of mechanical components. This warranty covers the original purchaser only and is not transferable.

For ten years from the date of purchase, this warranty also covers the LCD. Thereafter, for the lifetime of the DMM, Fluke will replace the LCD

for a fee based on then current component acquisition costs.

To establish original ownership and prove date of purchase, please complete and return the registration card accompanying the product, or

register your product on http://www.fluke.com. Fluke will, at its option, repair at no charge, replace or refund the purchase price of a defective

product purchased through a Fluke authorized sales outlet and at t Fluke reserves the right to charge for he applicable international price.

importation costs of repair/replacement parts if the product purchased in one country is sent for repair elsewhere.

If the product is defective, contact your nearest Fluke authorized service center to obtain return authorization information, then send the

product to that service center, with a description of the difficulty, postage and insurance prepaid (FOB Destination). Fluke assumes no risk

for damage in transit. Fluke will pay return transportation for product repaired or replaced in-warranty. Before making any non-warranty

repair, Fluke will estimate cost and obtain authorization, then invoice you for repair and return transportation.

THIS WARRANTY IS YOUR ONLY REMEDY. NO OTHER WARRANTIES, SUCH AS FITNESS FOR A PARTICULAR PURPOSE, ARE

EXPRESSED OR IMPLIED. FLUKE SHALL NOT BE LIABLE FOR ANY SPECIAL, INDIRECT, INCIDENTAL OR CONSEQUENTIAL DAM-

AGES OR LOSSES, INCLUDING LOSS OF DATA, ARISING FROM ANY CAUSE OR THEORY. AUTHORIZED RESELLERS ARE NOT

AUTHORIZED TO EXTEND ANY DIFFERENT WARRANTY ON FLUKE’S BEHALF. Since some states do not allow the exclusion or limita-

tion of an implied warranty or of incidental or consequential damages, this limitation of liability may not apply to you. If any provision of this

warranty is held invalid or unenforceable by a court or other decision-maker of competent jurisdiction, such holding will not affect the validity

or enforceability of any other provision.

Fluke Corporation

P.O. Box 9090

Everett, WA 98206-9090

U.S.A.

Fluke Europe B.V.

P.O. Box 1186

5602 BD Eindhoven

The Netherlands

5/07

Table of Contents

Title Page

Lifetime Limited Warranty............................................................................................... ii

Introduction .................................................................................................................... 1

Contacting Fluke ............................................................................................................ 1

Safety Information .......................................................................................................... 1

Hazardous Voltage......................................................................................................... 3

Symbols ......................................................................................................................... 4

Features ......................................................................................................................... 5

Understanding the Push Buttons............................................................................... 5

Using Auto Repeat .................................................................................................... 6

Understanding the Display ........................................................................................ 7

Bar Graph ............................................................................................................. 8

Status Bar Elements............................................................................................. 8

Page Area............................................................................................................. 9

Softkey Labels ...................................................................................................... 9

Adjusting Display Contrast.................................................................................... 9

Understanding the Rotary Switch .............................................................................. 10

Using the Input Terminals.......................................................................................... 11

Controlling Meter Power................................................................................................. 12
