Sida 1/8

PN 2842344

June 2007

i310s

AC/DC Current Clamp

Instruction Sheet

Introduction

The i310s Current Clamp (“Clamp”) has been designed for use

with oscilloscopes and digital multimeters for accurate non-

intrusive measurement of ac, dc and complex waveform currents.

Using advanced Hall Effect technology, the Clamp can

accurately measure currents up to 450 A peak over the

frequency range of dc to 20 kHz. These features make it a

powerful tool for use in inverters, switch mode power supplies,

industrial controllers, automotive diagnostics, and other

applications requiring current measurements and/or waveform

analysis.

Symbols

The table below lists the symbols used on the Clamp and/or in

this manual.

Symbol Description

Do not dispose of this product as unsorted municipal

waste. Go to Fluke’s website for recycling information.

Important Information. See manual.

Hazardous Voltage. Risk of electric shock.

Double insulation.

Application around and removal from HAZARDOUS

LIVE conductors is permissible.

)

Conforms to Canadian Standards Association.

Complies with the relevant European standards.

;

Conforms to Australian standards.

i310s English Instruction Sheet

Page 2

Safety Instructions

Please read this section carefully. It will make you familiar with

the most important safety instructions for handling your product.

In this instruction sheet, a Warning identifies conditions and

actions that pose hazard(s) to the user. A Caution identifies

conditions and actions that may damage the calibrator or the test

instruments.

WX Warning

The Clamp may only be used and handled by

qualified personnel. To avoid personal injury, follow

these precautions:

• To avoid electric shock, use caution during

installation and use of this product; high

voltages and currents may be present in circuit

under test.

• Do not use the Clamp if damaged. Always

connect to display device before it is installed

around the conductor.

• Always ensure the Clamp is removed from any

live electric circuit, and leads are disconnected

before removing the battery cover.

• Use the Clamp only as specified in the

operating instructions; otherwise the safety

features may not protect you.

• Adhere to local and national safety codes.

Individual protective equipment must be used

to prevent the shock and arc blast injury where

hazardous live conductors are exposed.

• Do not hold the Clamp anywhere beyond the

tactile barrier.

• Before each use, inspect the Clamp. Look for

cracks or missing portions of the housing or

output cable insulation. Also look for loose or

weakened components. Pay particular attention

to the insulation surrounding the jaws.

• Use caution when working with voltages above

60 V dc, 30 V ac rms or 42 V ac peak. Such

voltages pose a shock hazard.

• Use of this equipment is designed to protect

against transients in equipment in fixed

equipment installations, such as distribution

panels, feeders and short branch circuits, and

lighting systems in large buildings.

Produktspecifikationer

Varumärke:	Fluke
Kategori:	Multimeter
Modell:	i310s
Produkttyp:	Testsond
Vikt:	250 g
Sladdlängd:	2 m
Produktens färg:	Black, Yellow
Antal per förpackning:	1 styck
Temperatur vid drift:	-10 - 50 ° C
Temperaturintervall (förvaring):	-20 - 85 ° C
Anslutning:	BNC
