User / Installation Manual
Marine Amplifier
FM-402
www.busse-yachtshop.de | info@busse-yachtshop.de
2010 Version 1.0
Feature Overview
• 2OhmStableMOSFETAmplierDesign
• VariableBassBoost0-+12dB
• VariableLPandHPElectronicsX-OVER@12dB/octave
• FUSIONRegulatedAmplierTechnology(F.R.A.T.)
• FUSIONIntercooledSemi-conductorTechnology(F.I.S.T.)
• GoldPlated4GaugePowerandGroundConnections
• GolsPlatedAudioInputandOutputConnections
• FUTRANZEcientHeatSinkTransferTechnology
• GoldPlatedRCAOutputformulti-ampInstallations
What sets FUSION apart?
TheFUSIONFMseriesamplierscomecompletewithFRATpowersupplies,FISTcoolingsystemandFUTRANZ.Also
allmarineampliersuseheat-temperedPCB’sformaximumproductlifeandperformance.Goldplatedconnectol-
ogy,ensuresyoursignalowsfromtheheadunitthroughtothespeakerswithaslittleinjecteddistortionand
noiseaspossible.Thisresultsisaverycleanandverypowerfulreproductionoftheinputsignal.Allthesefeatures
makeiteasiertoachievesonicperfectioninalmostanyinstallation.
FUTRANZ
Indevelopingextremelypowerfulampliers,itisessentialtokeepthingscoolsoFUSIONdevelopedaheatsink
thathasaheatdissipationabilitylikeneverbefore.Thiswasnotaneasytaskbutnonethelessitwasachieved,
anotherimportantfactorisecientlytransferringtheheatfromthesemi-conductorstotheheatsink,conven-
tionaldesignsuseawhitepasteastheinterfacebetweenthesedevicesandtheheatsink,thisisnotaperfect
solutionwhencompletesurfacecouplingisrequired.SoallMarineAmplierscomeequippedwithacompositeheat
transferringtape.Coreheatinsemi-conductorscausesdistortionandpoorcomponentperformancecharacteris-
tics.TestinghasshownamassivereductionincoreheathasbeenachievedbyusingtheFUTRANZheattransfer-
ringtechnology.Insimpliedtermsthismeansexcellentthermalstabilityandmaximumcomponentreliability.
F.I.S.T (fusion intercooled semi-conductor technology)
FISTisaninnovativemethodofclampingdownallinternalpowerswitchingandaudiooutputdeviceswithan
aluminiumextrusionthathasextremelylowtemperatureco-eciency.ByusingF.I.S.Titcreatestheperfectcool-
ingsolution,rapidlyremovingcoreheatfromallassociatedsemi-conductorsfrombothsidesofthedeviceatonce
resultinginextremelylowdistortionanexcellentthermalstability
F.R.A.T (fusion intercooled semi-conductor technology)
FRATisaregulatedamplierdesign,FUSIONregulatedampliersallowanenormousamountofoutputpowerat
thelowestvoltage(12.6Volts)andextremeoutputat14.4volts.
Contents
Feature Overview.........................................Pg 3
Control Descriptions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Pg 4
Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Pg 6
Connections .............................................Pg 6
Inputs and Gain Setup .................................... Pg 7
2 Channel Installation / Trouble Shooting ....................Pg 8
3 Channel Installation / Power Cable Calculator...............Pg 9
4 Channel Installation / Specifications......................Pg 10
003
FEATURE OVERVIEW
RECORD YOUR PRODUCT DETAILS HERE:
MODELNUMBER DATEOFPURCHASE
AFFIXRECEIPTHERE
www.busse-yachtshop.de | info@busse-yachtshop.de
Control Descriptions
004
CONTROLS
005
CONTROLS
10 11987654321
13 15 1612 14
1 Bass Remote Selector
 Usethisswitchtoactivateordeactivatethe(optional)FP-BASScontroller.
2 Bass Remote Connector
 Thisportallowsconnectionstothe(optional)FP-BASScontrol.
3 Power And Status LEDs:
 thisshowsiftheamplierhasbeencorrectlypoweredupandifanyfaultsarepresent.
4 Crossover Selector:
 Settheappropriatemodeofoperation.The3positionsavailableareOFF,LPandHP.Seepoints5and6below.
5 Low Pass:
 Setthecrossoverswitch2toLPwhenasubwooferisconnected.Ensurethecrossoverfrequencyissetat
100Hzorbelow,thisfeatureisdesignedtolterallmidtohighfrequenciesthatonlyFULLRANGEspeakers
shouldproduce.NOTE:Failuretodosocouldresultinspeakerdamage.
6 High Pass:
 Setthecrossoverswitch2toHPandturnthiscontrolto65Hzorabovewhenusingspeakerssmallerthan6
x6”,thisfeatureisdesignedtolteralllowbassfrequenciesthatonlySUBWOOFERSshouldproduce.NOTE:
Failuretodosocouldresultinspeakerdamage.
7 Bass Boost:
Thisisavariablecontroltoincreasethebassboostat45Hzfrom0-+18dBofgain,adjusttosuit.
8 Subsonic Filter:
 ThisisavariablecontrolltersoutallSubBassFrequenciesbelowthesetpointat18dB/octave.
9 Level:
 Thisallowsleveladjustmentoftheinputsignal.Usethiscontroltocorrectlymatchtheheadunittothe
amplier.Tosetthiscontrolcorrectly,turntheamplierleveltoMINandtheheadunitto3/4volume,with
theBASSandTREBLEonzero,thenslowlyturnupthisamplierlevelcontroltowardstheMAXendofthe
control.NOTE:Ifthesoundbecomesdistorted,turnthiscontroldown.
10 RCA Input:
 ConnecttheseRCAconnectorstotherearLOWLEVELoutputconnectionfromtheheadunit.
11 RCA Output:
 UsetheseRCAOutputconnectorstoconnecttoasecondaryamplier.ThisoutputisaPASS-THRUconnection
derivedfromtheRCAinputconnectorsothesignallevelandfrequencyresponsearethesameastheoriginal
inputsignal.
12 Ground Connection:
 Connectdirectlytoasuitablegroundpointviaa4gaugepowercable.NOTE:Thisistobetherstwireto
connectwhenwiringupampliers.Damagecouldresultofthisisnotdone.
13 +12V Connection:
 Thismustbeconnectedtothebatterypositive(+)terminalviaa4guagepowercableandwithaninlinefuse
orcircuitbreakeratthebatteryend.NOTE:Thisistobethelastwiretoconnectupduringinstallationas
damagecouldresult.
14 Remote Connection:
 Thisinputisforturningtheamplieronando.Thisrequiresaswitchedpositive(+12V)topower‘ON’the
amplier,thiscanbefoundontherearoftheheadunitintheformofanelectricantennaoutput,oraremote
onoutput.IfnotavailableyoucanwiretotheACCpositiononthekey.
15 Fuses:
 Pleaseensurethecorrecttypeoffuseistted,asspeciedinthismanual.PLEASENOTE:theFM-402has1x
25Afuses.
16 Speaker Output:
 See2/1channelinstallationdiagramsinthismanualforcorrectspeakerconnection.
www.busse-yachtshop.de | info@busse-yachtshop.de
